- Page 1 Star Manufacturing Installation International Inc. Operating 10 Sunnen Drive Instructions St. Louis, MO 63143 Phone: (314) 678-6303 Fax: (314) 781-2714 2M-Z4051 Rev. P 8/14/13 HOT FOOD HUMIDITY CABINET MODEL HFD-1CRPL...
-
Page 2: Safety Symbol
RETAIN THIS MANUAL FOR FUTURE REFERENCE NOTICE Using any part other than genuine Star factory supplied parts relieves the manufacturer of all liability. Star reserves the right to change specifications and product design without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment. - Page 3 SPECIFICATIONS HFD-1CRPL120 Capacity: Four 12" (30cm) Pizza Shelves Electrical: 120 volt, 50/60 hertz, single phase, 1200 watts, 10 amps Dimensions: 15" W x 15" D x 28-1/4" H (38.1 cm W x 38.1 cm D x 71.7 cm H) Weight: Approximately 62 lbs.
-
Page 4: Operating Controls
OPERATING CONTROLS The temperature controls are located at the top of the unit above the door and the humidity controls are located on the bottom of the unit below the door (see Figures 1 and 2). Figure 1 Temperature Dial - Adjusts cabinet temperature Figure 2 ON/OFF Switch Activates cabinet light, and air circulation system. -
Page 5: Installation
This equipment is designed and sold for commercial use only by personnel trained and experienced in its operation and is not sold for consumer use in and around the home nor for use directly by the general public in food service locations. CAUTION All shipping containers should be checked for freight damage both visible and concealed. -
Page 6: Cleaning Instructions
CLEANING INSTRUCTIONS 1. Disconnect the electrical cord before cleaning the cabinet. 2. To maintain the finish and shine of the unit, wipe it daily with a damp cloth and mild soap. Do not use harsh detergents or scouring pads. 3. Daily cleaning of the inside glass, bottom pan and racking system with a damp cloth is recommended. - Page 7 LIMITED EQUIPMENT WARRANTY All workmanship and material in Star products have a one (1) year limited warranty on parts & labor in the United States and Canada. Such warranty is limited to the original purchaser only and shall be effective from the date the equipment is placed in service. Star's obligation under this warranty is limited to the repair of defects without charge, by the factory authorized service agency or one of its sub-agencies.
- Page 10 PIZZA RACK PRETZEL RACK (OPTIONAL) STAR MANUFACTURING INTERNATIONAL, INC. MODEL HFD-1CRPL 120V/240V SK1823 REV.- 11-14-00...
- Page 11 THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC. NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED. MODEL: HFD-1CRPL 120V STAR MANUFACTURING INTERNATIONAL INC. SK1825 Rev - 11/14/2000...
- Page 12 THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC. NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED. MODEL: HFD-1CRPL 120V STAR MANUFACTURING INTERNATIONAL INC. SK1826 Rev - 11/14/2000...
-
Page 13: Parts List
D5-220105 PIZZA-HOLDER ASSEMBLY IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE INCLUDE MODEL AND SERIAL NUMBER OF 2 Some items are included for illustrative purposes only and in certain instances may not be available. Star Manufacturing International, Inc. - Page 14 INSULATION B9-04-WB-0140 SPACER IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE INCLUDE MODEL AND SERIAL NUMBER OF 2 Some items are included for illustrative purposes only and in certain instances may not be available. Star Manufacturing International, Inc.
- Page 16 STAR INTERNATIONAL HOLDINGS INC. COMPANY Star - Holman - Lang - Wells - Bloomfield - Toastmaster 10 Sunnen Drive, St. Louis, MO 63143 U.S.A. (314) 678-6303 www.star-mfg.com...
