Thermasol SEAT-S-GR Installation Instructions

ThermaSol™ 18" Wide Bamboo Shower Seat
Installation Instructions: SEAT-S-GR
Thank you for purchasing the ThermaSol™ Shower Seat. We are
confident that you will find the unique design and durable construction
of this product to be of great assistance in your daily routine.
To fully enjoy your ThermaSol™ Shower Seat, please take a few moments
to read these instructions. You should store these instructions in a safe
place for future reference.

SAFETY CONSIDERATIONS

CAUTION: It is your responsibility to see that your ThermaSol™
Shower Seat is properly assembled, installed, and cared for. Failure to
follow instructions in this manual could result in serious injury. Some
surfaces can be slippery when wet - use this product with caution.
THERMASOL™ SHOWER SEAT INSTALLATION / MAINTENANCE
The ThermaSol™ Shower Seat should only be installed in areas where
the mounting surface is structurally sound. Strengthening modifications
may be required (see page 3 for details). ThermaSol™ Shower Seat
should not be installed in fiberglass / acrylic shower enclosures with
insufficient stiffness and strength. Should not be installed into metal
studs. If you are not equipped to undertake the outlined work we
recommend that you have your ThermaSol™ Shower Seat installed by
a qualified contractor. Seat should only be used for sitting upon - not
to be used for other purposes. Do not install seat in locations where
seated user and seat are close to direct steam or hot water emissions.
Suggested maximum user weight 500lbs/227kg, however this rating
is conditional upon suitable fasteners and supporting surface. One
person maximum capacity. WOOD CONTACT SENSITIVITY -
some people may experience a skin rash or other reaction due to
contact with certain types of wood. If unsure, test first.
CLEANING & MAINTENANCE - Clean seat with water, and then
wipe dry using a soft cloth. Do not use abrasive cleaning products.
WARRANTY
This shower seat is covered by a one year limited warranty with the
exception of hand grips which are subject to normal wear. Buyer hereby
indemnifies, agrees to hold harmless and defend the manufacturer/
distributor of the ThermaSol™ shower seat from and against any and
all liabilities, claims, (founded and unfounded), losses, damages, costs
and expenses (including without limitation consequential damages and
reasonable professional fees) resulting from buyers specification, application,
or improper use of goods described hereon; buyers omission or neglect.
The manufacturer/ distributor of the ThermaSol™ shower seat does not
assume any liability for damage resulting from services performed by
others or faulty installation, misuse or misapplication of goods.
The manufacturer/ distributor of the ThermaSol™ shower seat
shall not be liable for prospective profits or special, indirect, or
consequential damages, or for the cost of any corrective work
done without prior approval. Manufacturer/ distributor of the
ThermaSol™ shower seat
event exceed the purchase price of the goods specified hereon.

TOOLS REQUIRED

• Level • Personal Protective Eyewear • Center Punch • Hammer • Carbide
tip drill suitable for tile • Stud Finder • Protective blanket

CLEANING AND MAINTENANCE

The back panels of the ThermaSol™ Shower Seat are removable to allow
for cleaning of the wall behind the seat. Clean seat with water, and then
wipe dry using a soft cloth. Do not use abrasive cleaning products.
Specifications subject to change without notice.
total liability hereunder shall in no

WOOD PANEL WARNING

In order to retain the natural beauty of the Bamboo, each slat is finished
with an extremely durable 2-part oil
finish that does not contain volatile organic compounds (VOCs) or
other harmful chemicals.
A light brown or red discoloration may be noticed in water exposed to
the wood, and is due to an excess of pigments (natural oils) in the wood
reacting with minerals present in certain types of water (well water,
hard water, etc.). This discoloration is a natural reaction often referred
to as leaching and should fade over time. The applied oil finish also
reduces the effects of leaching. If unsure, test wood in local water prior
to installation.

TIPS FOR DRILLING INTO TILE

• Use carbide tipped masonary drill on ceramic, or consider
a diamond tip drill for porcelain tile.
• If possible, drill a smaller pilot hole first.
• Be careful to prevent the drill from moving when you first start it
rotating - use duct tape or a wood guide on the surface of the tile to hold
the drill from walking sideways.
• A variable speed drill on slow is best to start the hole. Do not apply too
much pressure when drilling. Do not use a hammer drill.
• The screws listed as #10 typically use a hole diameter of 1/8"
(3mm) into the support structure (wood studs, blocking, etc.).
The clearance hole through tile, etc. would be a minimum of
13/64" (5mm).

MOUNTING LOCATION

We strongly recommend that you give some thought as to the
optimal location of
installation. The following
consideration, however, it is recommended to consider advice
from the appropriate healthcare professional for locating of any
support product. Also, consider the following when determining
the optimal mounting location:
1. Move mounting location to match structure behind the wall.
2. Avoid electrical / plumbing behind the wall.
3. Where possible, drill through tile - not through grout.
The ThermaSol™ Shower Seat is to be mounted on surfaces
perpendicular to each other (i.e. in a Shower). If the holes on the
bracket do not align with the wood studs, we recommend
strengthening modifications
recommendations).
consider the height
(NOTE: ADA guideline specifies seat height of 17-19" above the
finished floor).
Page 1
your ThermaSol™ Shower
suggestions are offered
to be done (see
When determining the
of the user and their
Seat before
for your
Page 3 for
seat height,
capabilities
81183 6/15
