PARTS LIST
Part
Rack Stand
Quantity
Step 1
1)Connect the left rack stand (A)
with the left bottom support(B) and
the Bar(C),by inserting screws (D)
from each side, through predrilled
holes in the left rack stand (A),
through predrilled holes in the
bar(C), into predrilled holes in the
ends of the left bottom supports(B).
and secure with spacers (E) and
nuts(F).
WARNING
Do not allow children to play with or around log rack.
CARE AND MAINTENANCE
Use a soft cloth to wipe the rack.
Store in a clean, dry place when not in use.
Distributed by:
Tractor Supply Company
200 Powell Place, Brentwood, TN 37027
For customer service department call: 1-888-376-9601
MADE IN CHINA
LOG RACK 8FT
SKU 3910123
TM
A
B
Bottom Support
2
4
1)Connect the left bottom
support(B) with the right bottom
support(B) and the Bar(C),by
inserting screws (D) from each side,
through predrilled holes in the ends
of the left bottom support(B),
through predrilled holes in the
bar(C), into predrilled holes in the
ends of the right bottom
supports(B). and secure with
spacers (E) and nuts(F).
C
C
Bar
3
Step 2
B
www.Tractorsupply.com
D
E
Spacer
Screw
Nuts
12
12
Step 3
1)Connect the right bottom
support(B) with the right rack stand
(A) and the Bar(C),by inserting
screws (D) from each side, through
predrilled holes in the right rack
stand (A), through predrilled holes
in the bar(C), into predrilled holes
in the ends of the right bottom
supports(B). and secure with
spacers (E) and nuts(F). Tighten
with screwdriver and wrench.
A
F
12
