- Page 1 SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM GAME OPERATION & INSTRUCTION MANUAL FOR ALL PARTS, SERVICE, AND TECHNICAL SUPPORT PHONE: 708-598-3720 FAX: 708-598-3720 WWW.FAMILYFUNCOMPANIES.COM STING INTERNATIONAL, © 2016 ALL RIGHTS RESERVED...
- Page 2 SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM THIS GAME IS INTENDED FOR INDOOR USE ONLY...
-
Page 3: Table Of Contents
SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM CONTENTS： 1. SPECIFICATION......................... 1 2. INTRODUCTION ......................... 2 2-1 OVERVIEW ........................2 2-2 IMPORTANT SAFETY INFORMATION ............... 3 2-3 SET UP ........................3 3. PACKAGE CONTENTS ...................... 4 4. INSTALLATION ........................4 4-1 LOCATIONS TO AVOID .................... -
Page 4: Specification
SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM 1. SPECIFICATION (1)Dimension: L1950mm，W1080mm，H1170mm W43” x D76” x H44” (2) Weight: 205 KG, 452 Lbs. (3) Voltage: AC 110V -120V, 220- 240V , 50Hz-60Hz； (4) Power: 68W-500W (5) Current：0.9A-10A (6) Environment: (indoor) temperature -10℃～+40℃;... -
Page 5: Introduction
SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM 2. INTRODUCTION 2-1 OVERVIEW Thank you for purchasing the “ALIEN BOOGEY PATROL” video game ride. This owner’s Manual is intended to provide detailed descriptions together with all the necessary information regarding the general operation of electronic assemblies, servicing control, spare parts, etc., pertaining to the game. -
Page 6: Important Safety Information
SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM 2-2 IMPORTANT SAFETY INFORMATION Unplug the game from the AC wall receptacle when servicing this product. Failure to do so could result in serious injury to yourself or others. ... -
Page 7: Package Contents
SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM PACKAGE CONTENTS Be sure to check that you have received all packages indicated below. Game Unit Accessories Name Specification Picture Qty. Remark Manual English version Ticket door、coin door、 GUO711 coin box、service door Power... -
Page 8: Locations To Avoid
SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM 4-1 LOCATIONS TO AVOID WARNING The machine is designed for indoor use only. Never install this machine outdoors or in any of the following: ● Locations exposed to direct sunlight ●... -
Page 9: Connecting The Power Cord
SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM WARNING Disconnect game power before moving. Make sure all wheels are intact. Replace any wheels that are damaged or broken before moving the game. When moving the game, DO NOT slide the game across the floor. ... -
Page 10: Parts Description
SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM 6. PARTS DESCRIPTION 6-1 GAME APPEARANCE AND FEATURES GAS PEDAL：Foot pedal accelerates the game vehicle speed on screen. TICKET/DBV DOOR：Ticket dispenser access or optional DBV connection. Key GUA71. 427 HEMI ENGINE：Molded PVC model engine decoration. AUDIO SPEAKERS (2): LED lighted speaker covers and speakers COIN AND CASHBOX DOOR: For coin mech, cashbox, game adj. -
Page 11: Ticket Mechanism
SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM 6-2 TICKET MECHANISM（ENTROPY） NOTE For Ticket version only! 。 How to fill the ticket Open the Ticket Door, place the Tickets into the TICKET HOLDER. Feed the Tickets into the TICKET MECH. ①... -
Page 12: Coin Mechanism
SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM 6-3 COIN MECHANISM（ELECTRONIC) 1 VR coin type sensitivity adjustment, clockwise adjustment（+），accept greater area of coin tolerance；anticlockwise adjustment（-），accept smaller area of coin tolerance, coin type filtration will be more restricted. 2 Power socket：connecting DC+12V power line、COIN signal. - Page 13 SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM Coin Mechanism Wiring： Grey Red -DC+12V White –COIN signal Code Table Black-Grounded Grey 6-4 TRUNK SERVICE DOOR MAIN PC MAIN BOARD MOTOR RELAY and I/O MAIN FRAME ...
- Page 14 SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM HOST COMPUTER CONNECTIONS 1 POWER INLET 2 CVI 3 VGA 4 NETWORK CONNECTION 5 USB（4PCS） 6 AUDIO CONNECTION...
-
Page 15: Control Signal And Instruction
SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM 7. CONTROL SIGNAL AND INSTRUCTION 7-1 PCB LAYOUT P1，P2，P3，P5， P6，P8，P13 are for signal input port，P7， P9， P10，P11 are signal output port，J1 is for USB，P12 is for power。... -
Page 16: How To Enter Into Menus
SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM 7-2 HOW TO ENTER INTO MENUS & ADJUSTMENTS Open the coin door and you will see the Game Setting/Meter Panel at the top of coin box; To enter the Menu state on screen-which can only be done during non-game play attract modes- Press: “MENU”... - Page 17 SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM Figure 1 After enter password, press “MENU”, move to ENTER, then press; “OPTION” to enter into next page（see figure 2 ） Pressing “Menu” again and again advances through all of the various Menus available. Pressing “OPTION”, when in any given Menu, will highlight the Option desired and step through the options of that Menu.
- Page 18 SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM Figure 2 Figure 3...
- Page 19 SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM CREDITS PER PLAY REQUIRED 1——8 AVERAGE GAME TIME 30 Sec——120 Sec TICKET OPTION ON/OFF TICKET MECHANISM ENABLE/ DISABLE MERCY TICKET OPTION 0——8 TICKET TYPE 1PT/ 2PT BONUS TIME OPTION ON/OFF BONUS TIME 5 Sec——30 Sec...
- Page 20 SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM TEST MENU Figure 5 EXIT THE MENU AND RETURN TO NORMAL GAME PLAY FROM ANY MENU SCREEN EXCEPT “TEST” BY PRESSING THE “JUMP” BUTTON.
-
Page 21: Introduction Of Game Play
SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM 8. INSTRUCTION OF GAME PLAY 8-1 GOAL ICONS GOAL IMAGE FUNCTION ACCUMULATE SCORE, 10 POINT Capturing (TOWARDS TICKET REWARDS IF Alien TICKET FUNCTION IS ENABLED) GAS CAN TURBO SPEED REWARD 8-2 HOW TO PLAY Insert the proper Credits and the game will begin at various points throughout the course;... - Page 22 SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM Gas Can Step on the “GAS PEDAL” to chase down and steer directly into running Aliens to capture and contain them for later disposal. By collecting Gas Cans which provide a Turbo speed bonus, Players can collect and capture more Aliens.
-
Page 23: General Troubleshooting
SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM 9. GENERAL TROUBLESHOOTING Symptom Possible Problem Solution POWER POWER Sound Problems Low Volume Check Volume Control and adjust as -No sound necessary -Low Sound Faulty speaker harnessing Check connections and/or repair -Intermittent harnessing Sound... -
Page 24: Part List
SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM PARTS LIST 10-1 BASE MECH ASSY PART CODE REMA FOR BASE DESCRIPTION SPECIFICATION FRAME ABP.01-01 BOTTOM FRAME Q235 ABP.01-02 MAIN MOTION FRAME Q235 ABP.01-03 UP MOTION FRAME Q235 ABP.01-04 PLATE FOR MOTOR Q235 AXIS OF ROTATION... - Page 25 SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM ABP.01-08 SLEEVE Q235 ABP.01-09 PULL ROD Q235 ABP.01-10 PLAIN BEARING INSIDE TEETH M20 ABP.01-11 PLAIN BEARING INSIDE TEETH M16 ABP.01-12 PLAIN BEARING OUTSIDE TEETH M16 CHAIN（5 CHAIN） 23 KNOB 2.5’’...
-
Page 26: Hardware Component
SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM 10-2 HARDWARE COMPONENT SPECIFICATION/ DESCRIPTION IMAGES MATERIAL HOST COMPUTER POWER SUPPLY OUTPUT12V/12.5A POWER AMPLIFIER GC-2.2 BOARD MAIN BOARD Ver2.2 20100130-6A RELAY LJQX-38F/40A RELAY BASE LJQX-38F-11A FIXED PLATE BLACK WOOD “U”... -
Page 27: Machine Parts List
SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM 10-3 MACHINE PARTS LIST PART CODE DESCRIPTION IMAGES UNIT MAIN GAME HARD DRIVE ABP-US-001 MAIN CONTROL I/O PCB ABP-US-002 Ver2.2 20100130-6A MAIN POWER SUPPLY ABP-US-003 OUTPUT12V/12.5A ADAPTOR ABP-US-004 OUTPUT DC12V 5.0A POWER AMPLIFIER PCB ABP-US-005 GC-2.2... - Page 28 SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM ABP-US-016 GAS PEDAL ASSEMBLY ABP-US-017 POWER SIWTCH 250V/10A FRONT LAMP COVER ABP-US-018 LA8020B(CHROMING) SPEAKER LAMP PANEL ABP-US-019 LED RING LIGHT ABP-US-020 BACK LAMP PANEL RED ALIEN CHARACTER ABP-US-021 SPOTLIGHT - WHITE ABP-US-022 FRONT LAMP LED PCB SPEED METER ON DASH...
- Page 29 SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM LEFT AND RIGHT LAMP ABP-US-031 ORANGE ABP-US-032 POTENTIOMETER ABP-US-033 CHROME TURNCAP ABP-US-034 STEERING WHEEL STEERING WHEEL END ABP-US-035 ABP-US-036 BACK CAR LAMP COVER ABP-US-037 BACK CAR LAMPHOLDER FRONT CAR LED LAMP ABP-US-038 COVER PROTECTIVE SAFETY...
- Page 30 SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM MONITOR GLASS WITH ABP-US-046 GRAPHICS ;TEMPERED GLASS FRONT BUMPER BAR; ABP-US-047 STAINLESS STEEL ROLL BAR;STAINLESS ABP-US-048 STEEL ALIEN CHARACTER ABP-US-049 SPRING BASE Q235 PVC MOTOR INTERNAL ABP-US-050 FIXTURE PLATE Q235 TICKET/DBV OUTPUT ABP-US-051 DOOR Q235...
- Page 31 SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM DIRECTIONAL ABP-US-062 CASTER(2.5'') ABP-US-063 CASTER M16 ABP-US-064 CASTER PRIMER PLASTIC MOTION DRIVE MOTOR ABP-US-065 110V-220V 400W ABP-US-066 MOTOR CHAIN WHEEL ABP-US-067 DRIVEN CHAIN WHEEL ABP-US-068 MOTION BEARING ABP-US-069 ECCENTRIC BLOCK A ABP-US-070 ECCENTRIC BLOCK B ABP-US-071...
- Page 32 SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM ABP-US-079 CLIP ø15 DIRECTION PRESSURE ABP-US-080 SPRING ABP-US-081 BACK-MOVING BEARING ABP-US-082 DIRECTION SWITCH ABP-US-083 POWER CABLE ABP-US-084 TICKET MECH (OPTION) ABP-US-085 DBV (OPTION) ABP-US-086 LICENSE PLATE GRAPHIC ABP-US-087 TICKET DOOR GRAPHIC ELECTRIC SHOCK ABP-US-088 WARNING...
- Page 33 SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM ABP-US-094 ALIEN PATROL GRAPHIC ALIEN CHAMBER BOTTOM ABP-US-095 GRAPHIC LEFT SIDE MONITOR ABP-US-096 GRAPHIC RIGHT SIDE MONITOR ABP-US-097 GRAPHIC WHEEL CENTER ABP-US-098 GRAPHIC ALIEN MARK GRAPHIC A ABP-US-099 FENDER L-R ALIEN MARK GRAPHIC B ABP-US-100 GAS TANK...
- Page 34 ABP-US-116 Cover ABP-US-117 Join Bearing Small Cover STING INTERNATIONAL, P.O. BOX 455, ELK GROVE VILLAGE, IL 60007 USA E-mail: sting2 @ rcn.com. FOR ALL PARTS, SERVICE, AND TECHNICAL SUPPORT PHONE: 708-598-3720 FAX: 708-598-3720 WWW.FAMILYFUNCOMPANIES.COM STING INTERNATIONAL, © 2016 ALL RIGHTS RESERVED...
