ADS Technologies USBH-604 Connection Manual

Usb ultra hub 4

PYRO 1394 6-Port Hub

1. Connect the power supply to your USB Ultra Hub 4 or

PYRO 1394 6-Port Hub.

2. Connect the hub to your computer.

For USB Ultra Hub 4

Connect the "B" plug of the USB cable to your

USB Ultra Hub 4 and connect the "A" plug to your com-

puter's USB port.

"B" plug -

to your USB Hub

For PYRO 1394 6-Port Hub

Connect one end of the IEEE-1394/FireWire cable to

any one of the 6 FireWire ports on the PYRO Hub then

connect the other end of the cable to your computer's

6-pin FireWire port.

North America Office

Cerritos, CA 90703

(562)926-1928 • (800)888-5244

Fax (562)926-0518

USB Ultra Hub 4 or

IEEE-1394/FireWire

6-pin connector

"A" plug -

to your computer

http://www.adstech.com

European Office

Shannon Industrial Estate

Shannon Co. Clare, Ireland

Phone: +353.61.702042
