Safety Information For GMRS UNIT
Your wireless handheld portable transceiver contains a low power transmitter.
When the Push-to Talk(PTT) button is pushed it sends out radio frequency (RF) signals. T
his device is authorized to operate at a duty factor not to exceed 50%.
In August 1996, the Federal Communications Commission (FCC) adopted RF exposure gui
delines with safety levels for hand-held wireless devices.
FEATURES
Congratulations on your selection of a quality BellSouth product. With proper care and adherence to the set-up and user
instructions in this Owner's Manual, this unit will provide you with years of trouble-free service.
BellSouth is committed to providing quality products that fit your needs. We would like to have any comments or
suggestions you might have on this product. You may mail your comments to:
The FW13 is the newest generation in personal two-way communications. The FW13 is a lightweight, compact two-way
communication device that can be used to communicate with family or friends at parks, shopping malls, sporting events,
concerts – any indoor or outdoor activity.
Here are some of the features of this new two-way communicator:
•
Wrist Watch Style with Adjustable Band
•
22 GMRS Channels
•
Up to 1.5 Mile Range
•
Auto Squelch
•
Auto Battery Saving
•
Internal VOX
•
Channel Scan
•
12 Hour AM/PM Time Clock
•
Backlit LCD Display
•
Lithium Ion Battery Power Source
Please read this Owner's Manual carefully to get the most out of your TWO-WAY COMMUNICATOR.
NOTE : The maximum range will vary depending on terrain and environment. Range will be greater in open fields. While
range is shorter within and around buildings or large structures. This unit may not ensure privacy of communication.
DISPLAYS
1
4
8
U.S. Electronics
105 Madison Avenue
New York, NY 10016
3
1.
Channel Number (1~22)
2.
2
Transmit Indicator (TX)
3.
Receive Indicator (RX)
4.
5
Volume Selection (8 Bars)
5.
Call Tone Transmission (CALL)
6.
6
Low Battery Level indicator
7.
VOX –
7
8.
12 Hour Time Clock (12:00)
–
Shows the current channel
–
Indicates when the unit is transmitting
–
Indicates when the unit is receiving a transmission
–
Shows the current volume setting
–
-
Indicates when battery level is low or during
charging the battery
Indicates when unit is in VOX mode
Indicates when the unit is paging
