TERMA SCANTER 1002 User Manual

Radar system
Hide thumbs
Table of Contents

Advertisement

Quick Links

SCANTER 1002 Radar System
User's Manual
© Terma, Denmark. Proprietary and intellectual rights of Terma A/S and/or its subsidiaries are involved in the subject-matter of this material and all
manufacturing, reproduction, use, disclosure, and sales rights pertaining to such subject-matter are expressly reserved. This material is submitted for
a specific purpose as agreed in writing, and the recipient by accepting this material agrees that this material will not be used, copied, or reproduced in
whole or in part nor its contents (or any part thereof) revealed in any manner or to any third party, except own staff, to meet the purpose for which it was
submitted and subject to the terms of the written agreement.
This document is released for use only if signed by
relevant staff or stamped "EDM Release Controlled".
CM:
.
M
L
.
T
.
.
1255194-HO Rev. A

Advertisement

Table of Contents
loading

Related Manuals for TERMA SCANTER 1002

Summary of Contents for TERMA SCANTER 1002

  • Page 1 User’s Manual © Terma, Denmark. Proprietary and intellectual rights of Terma A/S and/or its subsidiaries are involved in the subject-matter of this material and all manufacturing, reproduction, use, disclosure, and sales rights pertaining to such subject-matter are expressly reserved. This material is submitted for...
  • Page 3 Record of changes Description Date Released 2017-12-04 SCANTER 1002 Radar System Page 3/62 User’s Manual Rev. A 1255194-HO 2017-12-04...
  • Page 4 (Intentionally left blank) Page 4/62 SCANTER 1002 Radar System Rev. A User’s Manual 2017-12-04 1255194-HO...

  • Page 5: Table Of Contents

    SCANTER 1002 Radar System ........
  • Page 6 Annex A - Acknowledgement ........57 Page 6/62 SCANTER 1002 Radar System Rev. A User’s Manual...

  • Page 7: Introduction

    Introduction Purpose The SCANTER 1002 Radar System is optimized to ensure a high level of situation- al awareness on land platforms in all weather conditions. The purpose of this manual is to provide a functional description of the radar sys- tem and the transceiver hardware interface.
  • Page 8 Equipment weighs about 35 kilograms and to avoid injury, use proper lifting technique, 2 person lifting or lifting aids. In no event, Terma A/S shall be held liable for any direct, indirect, punitive, incidental or consequential damages what- so-ever arising out of or connected with the use or misuse of its products.

  • Page 9: Microwave Radiation Safety Margins

    10 W/m in the frequency band from 1-300 GHz and over any 6 minute period. The SCANTER 1002 radar operates within this frequency range. The corresponding level for occupational expo- sure is 50 W/m Furthermore, sector transmission is normally implemented, stopping transmission for the parts of the antenna rotation not covering the ground surface.
  • Page 10 (Intentionally left blank) Page 10/62 SCANTER 1002 Radar System Rev. A User’s Manual 2017-12-04 1255194-HO...

  • Page 11: Scanter 1002 Radar System

    The SCANTER 1002 Ground Surveillance Radar (GSR) is designed to perform ground surveillance of high-sensitivity areas and critical infrastructure. The SCANTER 1002 radar is a Ku-band, 2D, fully coherent pulse compression radar, based on Solid State transmitter technology with digital software-defined functionality.

  • Page 12: System Components

    Built-in Test Equipment (BITE). It also provides access to powerful radar imaging and tracking information. System components The SCANTER 1002 Radar System is mounted in an enclosure consisting of a radome and a sun cover (see Fig. 2.2 (p. 12)). The system consists of the following main assemblies and modules: •...

  • Page 13: Scanter 1002 Product Features

    SCANTER 1002 product features The SCANTER 1002 technology and product features are listed in the tables below. • Software-defined functionality • Frequency diversity • Full coherency and pulse compression • Transmitter power level control in sectors • Environment adaptation •...

  • Page 14: Physical Appearance Of Scanter 1002

    The tracker combines the information from the different Doppler filter channels with the scan-to-scan movements in the normal video to achieve separation of small moving targets from ground clutter. 2.2.2 Physical appearance of SCANTER 1002 Fig. 2.4 Transceiver dimensions (model) Weight: 35 kg installed...

  • Page 15: Functional Description

    Functional Description The SCANTER 1002 Radar System is an integrated unit containing both the radar transceiver, power supply, embedded computer and antenna with motor and encoder. The system is enclosed in a radome and a sun cover, which provide envi- ronmental protection and passive cooling.

  • Page 16: Software-Defined Functionality

    SSPA - Solid State Power Amplifier The SSPA - Solid State Power Amplifier - for SCANTER 1002 is part of the TR Module in the transceiver. It is designed using state-of-the-art MMIC (Monolithic Microwave Integrated Circuit) GaAs high-power amplifiers (HPA).

  • Page 17: Full Coherency

    In order to illuminate a target with sufficient energy for detec- tion, it has to transmit long pulses. Unless some clever processing is used, this would lead to a significant loss of range resolution. The SCANTER 1002 transceiv- er utilizes frequency modulation (chirping or frequency sweeping) and pulse com- pression to increase the range resolution as well as the signal-to-noise ratio.

  • Page 18: Power Sector Transmission

    CFAR – Constant False Alarm Rate – and other adaptation techniques provide automatic adjustments such as false alarm rate. CFAR provides a flat noise floor - also based on proprietary algorithms. Page 18/62 SCANTER 1002 Radar System Rev. A User’s Manual 2017-12-04...

  • Page 19: Controlling And Using The Radar

    Built In Test Equipment (BITE) BITE Errors & Warnings BITE Status BITE Measurements Fig. 3.4 Built-In Test Equipment (BITE) At power up, the following diagnostic tests are performed: SCANTER 1002 Radar System Page 19/62 User’s Manual Rev. A 1255194-HO 2017-12-04...
  • Page 20 Displays transceiver components status BITE measurements: Temperatures Internal power supplies. If parameters exceed specifications, warnings or error messages are automatically issued to the various human user interfaces available. Page 20/62 SCANTER 1002 Radar System Rev. A User’s Manual 2017-12-04 1255194-HO...

  • Page 21: Bite - Errors/Warnings

    Logging of BITE errors and warnings, BITE status and BITE measurements is per- formed and data is stored in an allocated area of the hard disc on the embedded computer. See Fig. 3.5 (p. 22). SCANTER 1002 Radar System Page 21/62 User’s Manual Rev. A 1255194-HO...
  • Page 22 Fig. 3.5 System and performance logs Page 22/62 SCANTER 1002 Radar System Rev. A User’s Manual 2017-12-04 1255194-HO...

  • Page 23: Hardware Interface

    Hardware interface Bottom plate Conn. Function Mains, power in Ground (protective earth) Fig. 4.1 Bottom plate, connections SCANTER 1002 Radar System Page 23/62 User’s Manual Rev. A 1255194-HO 2017-12-04...

  • Page 24: X1, Mains

    Phase 1 Neutral Earth X2, Aux The AUX interface is used for debugging by Terma personnel. It includes an IP reset feature that may be applicable for end users. For details on IP reset, refer to section 6.1 (p. 43).

  • Page 25: Gnd

    Function Terminal Function BI_DA+ BI_DB- BI_DA- BI_DD+ BI_DB+ BI_DD- BI_DC+ SHELL Shield BI_DC- The ground stud is for connection to Protective Earth. Fig. 4.2 Bottom plate, ground stud SCANTER 1002 Radar System Page 25/62 User’s Manual Rev. A 1255194-HO 2017-12-04...
  • Page 26 (Intentionally left blank) Page 26/62 SCANTER 1002 Radar System Rev. A User’s Manual 2017-12-04 1255194-HO...

  • Page 27: Radar Service Tool

    To operate or to change parameters in the radar it is necessary to connect to the radar using one of the three access levels available: • Operational access level. • Service access level. • Debug access level. SCANTER 1002 Radar System Page 27/62 User’s Manual Rev. A 1255194-HO 2017-12-04...

  • Page 28: User Documentation

    The situation display is one of five default perspectives, all described in the follow- ing. RST screen layout The Radar Service Tool screen layout is shown in Fig. 5.1 (p. 29) with definitions of the different operation areas. Page 28/62 SCANTER 1002 Radar System Rev. A User’s Manual 2017-12-04 1255194-HO...
  • Page 29 The help topics can also be displayed by pressing the F1 key any- where in the RST user interface. SCANTER 1002 Radar System Page 29/62 User’s Manual Rev.

  • Page 30: Rst Keyboard And Mouse Actions

    Ctrl - right-drag - up - right Zoom out Ctrl - right-drag - down - left Reset zoom and re-center to own Ctrl - right-drag - up - left unit position Page 30/62 SCANTER 1002 Radar System Rev. A User’s Manual 2017-12-04 1255194-HO...

  • Page 31: Rst Menu Navigation And Search

    The “All parameters” in the navigation tree must be selected to enable the search in the entire navigation tree. In case a parameter cannot be found, pay attention to the log-on access level. SCANTER 1002 Radar System Page 31/62 User’s Manual Rev.

  • Page 32: Preferences

    Initial Connection Manager Connection Status Recordings Fig. 5.6 “Initial” perspective, default The “Low Level” perspective provides parameter and profile views for configuring profile content and editing profile names. Page 32/62 SCANTER 1002 Radar System Rev. A User’s Manual 2017-12-04 1255194-HO...
  • Page 33 The “Zone Edit” perspective provides views for creating and editing zones and zone parameters. See Fig. 5.10 (p. 33). Zone Edit Zones Legacy NAAZ Zones Legacy NTZ Zones Parameters Fig. 5.10 “Zone Edit” perspective - default SCANTER 1002 Radar System Page 33/62 User’s Manual Rev. A 1255194-HO 2017-12-04...
  • Page 34 To move a view within the view area, select the view tab with the left mouse button while holding down the button. Move the view to another location or inside a frame already containing one or more views. Page 34/62 SCANTER 1002 Radar System Rev. A User’s Manual 2017-12-04...

  • Page 35: Radar Control

    Fig. 5.12 Radar Control view - Radar To change transceiver configuration, the "Profile" drop down menu, see Fig. 5.12 (p. 35), gives the possibility to select one of sixteen predefined profiles. SCANTER 1002 Radar System Page 35/62 User’s Manual Rev. A...
  • Page 36 "Sector Tx" switches on and off the sector transmission and will affect all sectors enabled. “Force Active” is for use in redundant systems only, i.e. in SCANTER 1002 this but- ton is dimmed. “Exclusive Access” is used for requesting ‘master control mode’ of the radar. This mode allows the user to gain exclusive access to the radar, i.e.

  • Page 37: Starting Transceiver

    A prohibit sector is a non-transmission sector. Selecting reduced power sector, it is possible to transmit with reduced power. Pow- er attenuation is selectable in the interval 0..15.5 dB. Fig. 5.14 Sector Bearing and Width SCANTER 1002 Radar System Page 37/62 User’s Manual Rev. A...

  • Page 38: Creating Et2 Tracking Zones

    5.6.5 Backup/restore The backup and restore functions in the RST provide backup and restore facilities for the SCANTER 1002 radar system. The transceiver contains the application SW, factory default data, transceiver con- figuration data and site default data. Furthermore, some space is allocated for log files (i.e. performance and measure- ment data) and temporary files.

  • Page 39: Creating/Restoring Backup Of Configuration Data

    This is the type of restore to be used when exchanging the LRU containing the transceiver hard drive or if a com- plete re-initialization of the transceiver to a previously backed up state is required. SCANTER 1002 Radar System Page 39/62 User’s Manual Rev.
  • Page 40 Display computer and transceiver) Create/restore Site Deafult Restore Factory Default configuration file. (Files are stored configuration file in the transceiver) Fig. 5.17 Menu: Window / Show View / Backup/Restore Page 40/62 SCANTER 1002 Radar System Rev. A User’s Manual 2017-12-04 1255194-HO...
  • Page 41 Restoring the “Factory Default” data will delete the “transceiver configura- tion” area. The transceiver will then be out of service, unless a backup has been created on the RST that can be restored. SCANTER 1002 Radar System Page 41/62 User’s Manual Rev.
  • Page 42 (Intentionally left blank) Page 42/62 SCANTER 1002 Radar System Rev. A User’s Manual 2017-12-04 1255194-HO...

  • Page 43: Software Installation

    Set “Store Network Configuration” to ‘Store’ for changes to take effect. According to the CIDR notation, ‘/24’ means that netmask must be set to 255.255.255.0 (24 bit set, 8 bit not set). SCANTER 1002 Radar System Page 43/62 User’s Manual Rev.

  • Page 44: Replacing Transceiver Software

    The transceiver will automatically reboot into the newly installed software. According to the CIDR notation, ‘/24’ means that netmask must be set to 255.255.255.0 (24 bit set, 8 bit not set). Page 44/62 SCANTER 1002 Radar System Rev. A User’s Manual 2017-12-04...

  • Page 45: Bite Errors And Warnings

    Clutter Map Input Link Error Could not connect to data input source. Comm Error#Motor Controller Error Command Error#Motor Controller Error Communication Error#Motor Con- Error troller SCANTER 1002 Radar System Page 45/62 User’s Manual Rev. A 1255194-HO 2017-12-04...
  • Page 46 CPU Load Warning#TrackerPC Warning Indicates that the CPU is slightly overloaded Custom antenna pattern Error Error Drive I2T Protection Warn- Warning ing#Motor Controller Drive Over Temperature Er- Error ror#Motor Controller Page 46/62 SCANTER 1002 Radar System Rev. A User’s Manual 2017-12-04 1255194-HO...
  • Page 47 Missing frequency in PSAT Cali- PSAT calibration table not complete for this profile, rerun Error bration Table Error PSAT calibration for this profile Motor I2T Protection Warn- Warning SCANTER 1002 Radar System Page 47/62 User’s Manual Rev. A 1255194-HO 2017-12-04...
  • Page 48 Stored calibration data does not match installed SSPA, rerun Error ing SSPA Error PSAT calibration PSAT Calibration Failed Error Error PSAT calibration failed, rerun PSAT calibration for this profile Page 48/62 SCANTER 1002 Radar System Rev. A User’s Manual 2017-12-04 1255194-HO...
  • Page 49 Could not connect to data input source. Transceiver Configuration Restore Error Indicates that a restore operation has failed Error Under Voltage Error#Motor Con- Error troller Video Server Link Error Error SCANTER 1002 Radar System Page 49/62 User’s Manual Rev. A 1255194-HO 2017-12-04...
  • Page 50 (Intentionally left blank) Page 50/62 SCANTER 1002 Radar System Rev. A User’s Manual 2017-12-04 1255194-HO...

  • Page 51: Technical Terms And Definitions

    Antenna Polarization Antenna polarization is determined by the direction of the electrical field. SCANTER 1002 is horizontally polarized. Azimuth The angle between a horizontal reference direction (north or heading) and the horizontal projection of the direction of interest, measured clockwise.
  • Page 52 Equivalently, range resolution is ten times finer than an un-coded pulse of the same duration. Page 52/62 SCANTER 1002 Radar System Rev. A User’s Manual 2017-12-04...
  • Page 53 Trail Historic radar echoes, usually presented in a color differ- ent from the actual radar echoes and fading away within a user defined time interval. SCANTER 1002 Radar System Page 53/62 User’s Manual Rev. A 1255194-HO...
  • Page 54 Waveguide filter The waveguide filter functions as waveguide, i.e. a con- ductor within which RF energy can be efficiently transmit- ted. Page 54/62 SCANTER 1002 Radar System Rev. A User’s Manual 2017-12-04 1255194-HO...

  • Page 55: Abbreviations And Acronyms

    Monolithic Microwave Integrated Circuit Power Amplifier Processing & Control Radar Cross Section Radio Frequency Rotations per minute Recommended Standard Radar Service Tool Receive / Receiver Sea Clutter Discrimination SCANTER 1002 Radar System Page 55/62 User’s Manual Rev. A 1255194-HO 2017-12-04...
  • Page 56 T: direct connection with earth, independent of any other earth con- nection in the supply system; N: connection to earth via the supply network. See ‘TN’ Transmit / Transmitter Wide Area Network Page 56/62 SCANTER 1002 Radar System Rev. A User’s Manual 2017-12-04 1255194-HO...

  • Page 57: Annex A - Acknowledgement

    "SCANTER 1000 Series Transceiver Core Software Open Source Licenses", while the source code for these components are available in doc. no. 721089-SC: "SCANTER 1000 Series Transceiver Core Software GPL Source Code". SCANTER 1002 Radar System Page 57/62 User’s Manual Rev. A...
  • Page 58 (Intentionally left blank) Page 58/62 SCANTER 1002 Radar System Rev. A User’s Manual 2017-12-04 1255194-HO...
  • Page 59 Critical error ............39 ............28 ......13 ............7 Embedded tracker (ET2) Safety ......18 ..11 Environment adaptation SCANTER 1002 Radar System ........38 ..........28 ET2 tracking zones Screen layout ........38 Sector attenuation ..........38 Sector mode ......38 Factory Default ........36...
  • Page 60 ............29 Views ............28 ..........31 VRM-Scope ............. 7 Warnings ............37 Width ..........24 X1, Mains ............ 24 X2, AUX ............ 24 X3, LAN ............28 zoom Page 60/62 SCANTER 1002 Radar System Rev. A User’s Manual 2017-12-04 1255194-HO...
  • Page 62 Terma A/S Hovmarken 4 DK-8520 Lystrup, Denmark Telephone +45 87 43 70 00 Telefax +45 87 43 60 01 www.terma.com support@terma.com...
