CARNES VCDK040C Instructions

CARNES COMPANY, 448 S. Main St., P.O. Box 930040, VERONA, WI 53593-0040 • Phone: 608.845.6411 • Fax: 608.845.6470 • www.carnes.com • carnes@carnes.com
CEILING/WALL-MOUNT
VENTILATORS • 120V
READ AND SAVE THESE INSTRUCTIONS
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK, OR
INJURY TO PERSONS, OBSERVE THE FOLLOWING:
1. Use this unit only in the manner intended by the manufac-
turer. If you have questions, contact the manufacturer at the
address or telephone number listed.
2. Before servicing or cleaning unit, switch power off at service
panel and lock the service disconnecting means to prevent
power from being switched on accidentally. When the serv-
ice disconnecting means cannot be locked, securely fasten
a prominent warning device, such as a tag, to the service
panel.
3. Installation work and electrical wiring must be done by a
qualified person(s) in accordance with all applicable codes
and standards, including fire-rated construction codes and
standards.
4. Sufficient air is needed for proper combustion and exhaust-
ing of gases through the flue (chimney) of fuel burning
equipment to prevent backdrafting.
equipment manufacturer's guidelines and safety standards
such as those published by the American Society for
Heating, Refrigeration and Air Conditioning Engineers
(ASHRAE), and the local code authorities.
5.
When cutting or drilling into wall or ceiling, do not damage
electrical wiring and other hidden utilities.
6.
Ducted fans must always be vented to the outdoors.
7.
To reduce the risk of fire, use only metal ductwork.
8. If this unit is to be installed over a tub or shower, it must be
marked as appropriate for the application and be connected
to a GFCI (Ground Fault Interrupter) - protected branch cir-
cuit.
9. Never place a switch where it can be reached from a tub or
shower.
10. This unit must be grounded.
CAUTION
1. For general ventilating use only. Do not use to exhaust haz-
ardous or explosive materials and vapors.
2. To avoid motor bearing damage and noisy and/or unbal-
anced impellers, keep drywall spray, construction dust, etc.
off power unit.
3. Please read specification label on product for further infor-
mation and requirements.
TABLE OF CONTENTS
This manual is divided into sections as follows:
Follow the heating
VCDK040C • VCDK050C • VCDK070C
"TYPICAL INSTALLATION"
•
This sections shows a common installation in new and
existing, frame construction.
-Mounting (new construction)
-Mounting (existing construction)
-Wiring
-Ducting (straight-through blower discharge)
"DUCTING OPTIONS"
•
-Blower Discharge Positions
-Ducting (right-angle blower discharge)
• "USE AND CARE"
"WARRANTY"
•
"SERVICE PARTS"
•
MODELS
Form 11217-A
Page 1
FORM 11217-A, Page 1
