Pigeon Hole - Shelf Unit
Assembly Instructions
- Please keep for future reference
Dimensions
Width - 90.5cm
Depth - 24cm
Height - 151cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts please email us.
Advertisement
Related Manuals for Watsons Pigeon Hole MS0652
Summary of Contents for Watsons Pigeon Hole MS0652
- Page 1 Pigeon Hole - Shelf Unit Assembly Instructions - Please keep for future reference Dimensions Width - 90.5cm Depth - 24cm Height - 151cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts please email us.
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • We do not components and tools listed on the product, this could cause recommend the pages 2 and 3.
- Page 3 If you have damaged or missing components, Components - Panels email us. Please check you have all the panels listed below (90.1 x 16.9 cm) Base (90.1 x 23.9 cm) Middle shelf (87 x 16.5 cm) Left side Right side (147.5 x 16.7 cm) (147.5 x 16.7 cm) Shelf x 15...
- Page 4 If you have damaged or missing components, Components - Fittings email us Please check you have all the fi ttings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fi ttings may be supplied than are required. Camlock screw x 4 Double ended camlock x 2 Camlock nut x 8...
- Page 5 Assembly Instructions Step 1 Preparation Insert four 2cm wooden dowels into shelf . (using a dab of glue on the ends) Repeat for all 15 shelves. Insert two 3cm wooden dowels into centre top upright (using a dab of glue the ends) Insert two 5cm wooden dowels...
- Page 6 Assembly Instructions Step 1 cont. Preparation Align the arrow on the camlock nut with the edge of centre bottom upright (towards the closest edge where the double ended camlock will be inserted) Repeat for second centre bottom upright Insert 2 x 3cm wooden dowels into centre top upright...
- Page 7 Assembly Instructions Step 2 Main assembly Insert the shelves into the centre bottom upright slotting the wooden dowels into the holes as shown (using a dab of glue on the ends) You have now created the bottom shelf section. Insert the shelves into the centre top upright slotting the...
- Page 8 Assembly Instructions Step 2 cont. Main assembly Slot the two double ended camlocks into BOTTOM the centre shelf shown. Slot the assembled top shelf section (containing part - using the end with the 5cm wooden dowels ) onto centre shelf as shown.
- Page 9 Assembly Instructions Step 2 Main assembly Slide the three bottom BOTTOM back panels into the grooves in the sides until they slot into the centre shelf Repeat for the three top back panels Add screw caps over the screws in the sides (using a dab of glue if desired)
- Page 10 Assembly Instructions Step 3 Securing back panel Lift the unit into an upright position, this should take two persons to do safely. Make sure the item is square - that all corner are 90 degrees. slot the Insert twelve back fi xings plastic lip onto each of the six on part 11...
-
Page 11: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your product: tradesperson if you are unsure.
