1. Instruction
1.1 Summary
Plugging into your computer's USB port, you can make and
receive Skype calls. It's Commercial speakerphone in high grade
of quality having large LCD with backlight. Phone rings for all
incoming calls. You can dial Skype numbers on the phone.
1.2 Features
1. Commercial speakerphone in high grade of quality, ideal for
conference calls
2. Large LCD with backlight
3. Phone rings for incoming calls, ring style and volume selectable
4. Dial Skype contacts and skypeout number by phone keypads
5. Caller ID function of Skype incoming calls
6. Echo cancellation, noise reduction, full duplex communication
1.3 System Requirements
1. Windows 2000 or XP
2. 400MHz processor and free USB1.1 or USB2.0 port
3. 128MB RAM and 15MB free disk space
4. Any broadband connection or minimum 33.6 Kbps dialup
1.4 Package Contents
1. one USB Speaker Phone
2. one User Manual
3. one USB Cable
4. one Installation CD
1
Advertisement
Table of Contents
Related Manuals for 3J USB-P4K
Summary of Contents for 3J USB-P4K
- Page 1 1. Instruction 1.1 Summary Plugging into your computer’s USB port, you can make and receive Skype calls. It’s Commercial speakerphone in high grade of quality having large LCD with backlight. Phone rings for all incoming calls. You can dial Skype numbers on the phone. 1.2 Features 1.
- Page 2 2 Using the USB Speaker Phone 2.1 Keypad Instruction VOL+ VOL- DOWN HELP FLASH SEND HANDFREE IN/OUT Press to scroll the caller or dialed number. Up/Down Scroll to the contacts. (1) Press to scroll the Skype tab at the ready state. (2) Delete the input wrong number while dialing.
- Page 3 2.3 Connect USB Speaker Phone to PC When USB Speaker Phone is connected to PC, the LCD shows "VOIP Phone". 2.4 Run SkypeMate Insert SkypeMate installation CD or download SkypeMate software, then install it. Run SkypeMate Double-click the icon on the desktop, the Skype program will pop up the window as shown below: Select the first option “Allow this program to use Skype”, click “OK”...
- Page 4 Input number and call out: Press digital "11" on USB Speaker Phone, this number will be shown on Skype window, then press SEND key to call out. 2.6 Call to normal phone Press "00"+"country number" + "phone number", then press SEND key to call out. Example: Call to China, Beijing, press 00861012345678, then press SEND key.
- Page 5 Set “Audio In” and “Audio Out” to “USB Audio Device”. Problem 3 Skype has been started, but the icon of SkypeMate still shown as (the phone is green and the outside is grey)? Resolution Maybe you have selected the wrong option. You can execute “Tools->...
