Lifejacket light assembly instructions on iso & soLas lifejackets
72349
LALIZAS Lifejacket LED Flashing light "Safelite IV"
ON-OFF water activated, USCG, SOLAS/MED
FoR LiFEJaCKETs:
SIGMA:
(71094, 71096, 71097, 72081, 720811, 72154,
72560, 725601, 72561, 725611, 73580, 73581, 73650)
LAMDA:
(73584, 73629, 71107, 71216, 72114, 72115)
ALPHA:
(71098, 71100, 71101, 71102)
DELTA:
(71108, 71109, 71201)
OMEGA:
(71103, 71105)
ZETA:
(72399, 72400)
step 1:
Put the black clip underneath the
fabric which holds the whistle.
The assembly steps are the same for product 72348.
Αpplicable for:
72348
LALIZAS Lifejacket LED flashing light
"Alkalite II" ON-OFF water activated, L.S.A. Code
step 2:
Place the light at an angle and press
it down so that the two pieces lock
together.
instructions
Product 72349
Check that the light has been
placed as in the above picture
and that it cannot be removed
from the fabric by pulling it.
step 3:
