DARTSLIVE DARTSLIVE2 Owner's Manual

Ex type
Hide thumbs
Table of Contents

Advertisement

Quick Links

DL2-7112
EX TYPE
OWNER'S MANUAL
IMPORTANT
Before using this product, read this manual carefully to understand the
contents.
After reading this manual, be sure to keep it near the product or in a
convenient place for easy reference when necessary.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DARTSLIVE2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DARTSLIVE DARTSLIVE2

  • Page 1 DL2-7112 EX TYPE OWNER’S MANUAL IMPORTANT Before using this product, read this manual carefully to understand the contents. After reading this manual, be sure to keep it near the product or in a convenient place for easy reference when necessary.
  • Page 2 WEEE Statement The WEEE (Waste of Electrical and Electronic Equipment) directive places an obligation on all EU based manufacturers and importers of Electrical and Electronic Equipment to take back products at the end of their useful life. Sega WEEE in The following symbol will be on all products manufactured from 13th August 2005, which indicates this product must NOT be disposed of with other normal waste.
  • Page 4 Microsoft Software License Terms for: Windows® XP Embedded Runtime These license terms are an agreement between you and DARTSLIVE Co., Ltd. Please read them. They apply to the software included on this device. The software also includes any separate media on which you received the software.
  • Page 5 You are responsible for obtaining any licenses required for use of these protocols to access other software. • Remote Boot Feature. If the DARTSLIVE Co., Ltd. enabled the device Remote Boot feature of the software, you may (i) use the Remote Boot Installation Service (RBIS) tool only to install one copy of the software on your server and to deploy the software on licensed devices as part of the Remote Boot process;...
  • Page 6 6. Proof of License. to the device, or included on or in DARTSLIVE’s software packaging. If you receive the label separately, it is not valid. You should keep the label on the device or packaging to prove that you are licensed to use the software.
  • Page 7 11. Liability Limitations. You can recover from Microsoft and its only direct damages up to two hundred U.S. Dollars (U.S. $250.00). You cannot recover any other damages, including consequential, lost special, indirect or incidental damages. This limitation applies to: • Anything related to the software, services, content (including code) on third party internet sites, or third party programs;...
  • Page 8 DARTSLIVE Co., Ltd. INSPECTIONS THE PRODUCT IMMEDIATELY AFTER TRANSPORTING TO THE LOCATION Normally, DARTSLIVE Co., Ltd. products are despatched in a status allowing for immediate usage after transporting to the location. Nevertheless, an irregular situation may occur during transportation.

  • Page 10: Table Of Contents

    DURING OPERATION (PAY ATTENTION TO CUSTOMERS) ........9 PART DESCRIPTIONS ................10 ACCESSORIES ...................11 PLAYING THE GAME .................14 OUTLINE ........................14 COMPONENTS ......................15 6-2-1 DARTSLIVE Members Card (IC Card) ............15 6-2-2 Rankings ......................16 HOW TO PLAY ......................17 6-3-1 How to Start the Game ................17 6-3-2 Shortcut Functions ..................17...

  • Page 11: Introduction

    This manual provides detailed descriptions together with all the necessary information covering the general operation of servicing control, spare parts, etc. for the product, “DARTSLIVE2.” This manual describes the DX (Deluxe) Type, so the format of the photographs and illustrations may differ.

  • Page 12: Handling Precautions

    - DARTSLIVE Co., Ltd. shall not be held responsible for damage and/or compensation for damage to a third party, caused by changes not...
  • Page 13 CONCERNING THE STICKER DISPLAY This DARTSLIVE Co., Ltd. product has stickers attached describing the product manufacture No. (Serial No.) and When making inquiries regarding repairs, mention the Serial No. and Name of Machine indicated on the Sticker.
  • Page 14 DL2-7010 UP CABI SERIAL STICKER FOR TAIWAN DL2-7009TW DL2-7031EG FOR OTHER DL2-7009EG DL2-7033EG STICKER D ELECTRIFICATION MEIBAN STICKER STICKER W COLLAPSE '.'%64+% 219'4 %1057/26+10 '.'%64+% %744'06 %1057/26+10 DL2-7034EG STICKER C OVERHEAD DL2-7004EG STICKER W FINGER DOOR DL2-7005EG STICKER W 4''LCD DL2-7008EG DL2-7006EG STICKER C EPILEPSY BBB...

  • Page 15: Installation Location Precautions

    INSTALLATION LOCATION PRECAUTIONS product is an indoor game machine. Do not install it outside, Even indoors, avoid installing in places mentioned below so as not to cause a electric shock, injury and/or malfunction. - Places subject to rain or water leakage, or places subject to high humidity such as indoor swimming pool and/or shower, etc., or places where a water jet (high pressure washing device) could be used.

  • Page 16: Limitation Of Usage

    2-1 LIMITATION OF USAGE sure to check the electrical Ensure that this product is compatible with the location's power supply, voltage, and frequency. A plate describing electrical is attached to the product. Non-compliance with the electrical can cause a and electric shock. product requires a breaker and earth mechanism as part of the location facilities.

  • Page 17: Operation Area

    2-2 OPERATION AREA safe operation, use and operate this product in an area measuring at least 0.8 m in width and 4 m in depth. sure to provide space for ventilation in this manual. Do not block the ventilation ports. It can cause generation of heat and a Co., Ltd.

  • Page 18: Product Operation Precautions

    PRODUCT OPERATION PRECAUTIONS For safe operations of the product, follow the instructions below. 3-1 OPERATION PRECAUTIONS In order to avoid accidents, check the following before starting the operation: prevent accidents that can cause headaches and/or weaken health conditions, ensure that where the product is operated has lighting to allow any warnings to be read.
  • Page 19 cleaning the product daily, always check to make sure there are no scratches on the face door (dart board), or on the surface of the card reader where players touch them, and that the screws holding it in place are not loose. If a player uses the machine while it is damaged, cracked, or has a loose screw, the player may get injured.

  • Page 20: During Operation (Pay Attention To Customers)

    3-2 DURING OPERATION (PAY ATTENTION TO CUSTOMERS) To avoid accidents and trouble, pay attention to the behavior of visitors and players. safety reasons, do not allow any of the following people to play the game. - Those who need assistance when walking. - Those who have high blood pressure and/or a heart problem.

  • Page 21: Part Descriptions

    PART DESCRIPTIONS 24 TYPE WIDE LCD FACE DOOR CCD CAMERA BOARD (TARGET) MAIN CABINET CONTRO L PANEL CARD READER SPEAKER CHANGE BU TTON S TART BUTTON LOWER CABINET COIN CHUTE DOOR CASHBOX MAINTENANCE DOOR AC UNIT STEP 4 TABLE 01 Dimensions and Weights for major Parts ITEMS Width x Depth x Height Weight...

  • Page 22: Accessories

    ACCESSORIES “Spare” in the “Use etc.” column are expendable parts, and have therefore been included as spare parts. 5 TABLE 01 ACCESSORIES Part name: OWNER’S MANUAL Part no. (quantity): DL2-7112 (1) Use etc.: This manual Diagram Parts not labeled with part numbers are as yet unregistered or cannot be registered.
  • Page 23 LAN CABLE 10 m For installation LD-CT/BU10/RS(1) AC CABLE (Power Cord) For installation ACJ-3PS-02(1) (AC 110V,50Hz Area) For installation AT-PWC-015BS(1) (AC 220V,50Hz Area) HEXAGON BOLT M8×16(5) For installation SCREW M4×8(2) For installation FLANGE NUT(1) For groundng the earth wire EYE BOLT B -130-8(4) For installation...
  • Page 24 LOWER L BRACKET(1) For installation LCD CABLE COVER(1) For installation THROW LINE STICKER DL2-7011(1)

  • Page 25: Playing The Game

    PLAYING THE GAME 6-1 OUTLINE “DARTSLIVE2” is equipped with a network function to connect the shop (place where the DARTS machine is installed), DARTSLIVE members’ card (“IC card”), customers (PC, etc.) and “TouchLive” to each other. Through the use of a network, various gameplay elements are provided for a more engaging and enjoyable DARTS experience.

  • Page 26: Components

    6-2-1 DARTSLIVE Members Card (IC Card) Use of an IC card enables browsing and management of personal data stored on the “DARTSLIVE server” (the Player’s name and competition records can also be displayed on the machine. These IC cards can be used on “DARTSLIVE2”...

  • Page 27: Rankings

    6-2-2 Rankings When online, the machine can be set to always display the latest nation-wide rankings. The following games’ rankings can be viewed: - COUNT-UP - CRICKET COUNT-UP - EAGLE'S EYE The latest nation-wide and shop rankings are displayed during the advertising mode (standby mode). The window is brought up by placing the cursor over the name of the game on the submenu and tapping the board.

  • Page 28: How To Play

    6-3 HOW TO PLAY Basic operation: Select game Yellow Button When selecting category Set category. P1-P4 Button When selecting game Set number of players. Red Button When selecting category or game Move cursor. During game Go to next round. Change players. 6-3-1 How to Start the Game Insert the IC card into the card reader.

  • Page 29: Using Ic Cards

    Various data can be registered and authenticated by linking to other client machines (“machines”). - The various data can be easily accessed by connecting to the “DARTSLIVE” website’s members page (via PC, etc.) and entering the access code printed on the back of the IC card.
  • Page 30 Insert the card into the slot at the top of the card reader. There are Four(4) IC CARD slots. Two(2) IC cards can be inserted into each slot and a maximum of 8 cards can be processed simultaneously. In singles mode, it goes from left to right: P1, P2, P3 and P4.

  • Page 31: Removing Ic Cards

    For gallon mode, insert Four(4) IC cards into card reader 1 and 2, and Four(4) IC cards into card reader 3 and 4. Insert the cards in the correct direction. Data may not be read if inserted incorrectly. 6-4-3 FIG. 04 6-4-4 Removing IC Cards Pull the IC cards straight up out of the card readers.

  • Page 32: Checking Data On Ic Cards

    6-4-5 Checking Data on IC Cards Insert the IC card and select CARD on the Main Menu to check the data on the card. The data includes the player 6-4-5 FIG. 01 6-4-6 Registering Home Shop Using IC Card Select CARD on the Main Menu and press the P3 Button to register the home shop, regardless of the number of cards inserted.

  • Page 33: Help

    6-5 HELP Game Explanations Bring up the option window by placing the cursor over the game name on the submenu and tapping the board. Select the Rule Menu to bring up the Rules screen. 6-5 FIG. 01...

  • Page 34: Playing Option

    6-6 PLAYING OPTION Press the yellow Button (Start Button) during the game to display the PLAYING OPTION screen for easy access to various game operations. There are 9 functions under PLAYING OPTION. SWITCH THE ORDER Switch between singles and doubles and change throwing order STAT RECALL View results and other data from previous game Various game settings...
  • Page 35 Select STAT RECALL to view results and scores from previous games. It can be useful for assigning handicaps or keeping track of tournament results. In GAME SETTING, various options can be set as listed below: - Increase the variation of game play - Set different handicaps for each player HARD MODE Condition settings for steel-tip darts (double-in, double-out, etc.)
  • Page 36 List of Settings by Game CRICKET COUNT UP HARD MODE IN OPTION OUT OPTION BULLSEYE SHANGHAI PARTY PLAY CUT THROAT 6-6 FIG. 02 The number of points and marks can be manually or automatically increased or decreased as a handicap under All manual settings can only be entered by directly tapping the board.
  • Page 37 How to Set AUTO HANDICAP Press the Start Button before starting the game to bring up the PLAYING OPTION menu. Select AUTO HANDICAP under HANDICAP. 6-6 FIG. 03 When the PLAYING OPTION menu is closed, the handicap will be displayed on the game screen. 6-6 FIG.

  • Page 38: Dartslive2" Simple Hierarchical Diagram

    6-7 “DARTSLIVE2” SIMPLE HIERARCHICAL DIAGRAM High Score Ranking: In-store Ranking Advertisements screen Nation-wide Ranking SUB MENU PLAYING OPTION MAIN MENU RANKING DISPLAY PLAYING OPTION (Varies depending on game.) COUNT-UP RECOMMENDED STANDARD CRICKET SWITCH THE ORDER STAT RECALL GAME SETTING HANDICAP...

  • Page 39: Game Rules

    6-8 GAME RULES Various new games are added to “DARTSLIVE2.” New and additional games are available via network distribution. For detailed contents, rules, information on additional games, etc., visit the following URL: <http://www.dartslive.com/> NOTE: The Century Gothic™ font used within the game is the property of Monotype Corporation.

  • Page 40: Periodic Inspection

    PERIODIC INSPECTION Inspect the following items and perform maintenance regularly to maintain product performance and ensure safe operation. every 6 month to ensure that power cords are not damaged, the plug is securely inserted, dust has not accumulated between the socket outlet and the power plug, etc.
  • Page 41 Cleaning the Cabinet Surfaces When the cabinet surfaces become dirty, remove stains with a soft cloth soaked in water or diluted (with water) chemical dust-cloth or solvents such as thinner, benzene, etc. Some general-purpose household, kitchen, and furniture cleaning products may contain strong solvents that degrade plastic parts, coatings, and print.

  • Page 42: Design Related Parts

    For the warning sticker explanation, refer to chapter 1. TARGET STICKER NUMBER UPPER DL2-7026 TARGET STICKER NUMBER R DL2-7027 TARGET STICKER NUMBER L DL2-7028 TARGET STICKER NUMBER LWR DL2-7029 CTRL PNL STICKER DL2-7002 FR STICKER L DL2-7018 FR STICKER R DL2-7017 LINE STICKER DL2-7015 DL2-7011  DARTSLIVE2 THROW LINE STICKER...
  • Page 43 This device complies with Industry Canada's licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device. This radio transmitter (identify the device by certification number, or model number if Category II) has been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain indicated.
  • Page 44 DARTSLIVE Co., Ltd. Ebisu Business Tower 18F, 1-19-19, Ebisu, Shibuya-ku, Tokyo 150-0013, Japan http://www.dartslive.com/ PRINTING 2010.7...
  • Page 45 Remark: We bear the risk of the declaration. Under the environment with electromagnetic interference such as electrostatic discharge, conductive interference (at power cord and LAN cable), electrical fast transient and surge, the performance of this machine will be degraded and it requires the user to power reset for resuming it to normal operation.
  • Page 46 For Canada, RSS and USA, FCC Caution This device complies with Industry Canada’s license-exempt RSSs and Part 15 of the FCC Rules.Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
