Checking Package Contents

• One OfficeConnect Internet Firewall
• This QuickStart Guide
• One OfficeConnect Internet Firewall User Guide
• One OfficeConnect Internet Firewall CD
• One OfficeConnect Network Assistant CD - Not Illustrated
• One Power Adapter (country specific)
• Two 10Base-T Ethernet cables
• One Stacking Clip
• One Accessory Pack (cable ties, rubber feet, and labels) - Not Illustrated
If any items are missing from your package, contact your reseller immediately.
OfficeConnect Internet Firewall
Power Adapter Ethernet Cables
Internet Firewall User Guide CD
Stacking Clip

Getting Started

Thank you for purchasing the OfficeConnect
secure barrier between the private LAN and the public Internet to protect your network from security
threats on the Internet.
This QuickStart guide assumes that you have an Ethernet network connected to the Internet.
Note: This guide covers initial installation setup instructions for
and OfficeConnect Internet Firewall DMZ. These instructions are the same for both models. Please
refer to your User Guide for comprehensive setup instructions and hardware specifications.
Below are rear panel descriptions for each OfficeConnect Internet Firewall. The
has LAN and WAN ports. The Internet Firewall DMZ
QuickStart Guide will only discuss the LAN and WAN ports. For information on using the DMZ
port of the Internet Firewall DMZ, please refer to your User Guide.
Power LAN
Adapter Port
Socket
Uplink/Normal
Switch
Power LAN DMZ
Adapter Port Port
Socket
Uplink/Normal
Switches
® Internet Firewall. The Internet Firewall acts as a
OfficeConnect Internet Firewall 25
Internet Firewall 25
has LAN, WAN and DMZ ports. This
OfficeConnect
Internet Firewall 25
WAN
Port
OfficeConnect
Internet Firewall DMZ
WAN
Port
