TW-289

Instructions for

XL-65 and XL-65HP

with Dual Regulator

Do not attempt to use or maintain this

unit until you read and understand these

instructions. Do not permit untrained

persons to use or maintain this unit. If

you do not fully understand these

instructions, contact your supplier for

further information.

Table of Contents

Need help?

Do you have a question about the Taylor-Wharton XL-65 and is the answer not in the manual?

Questions and answers

Summary of Contents for Harsco Taylor-Wharton XL-65

Page 1 TW-289 Instructions for XL-65 and XL-65HP with Dual Regulator Do not attempt to use or maintain this unit until you read and understand these instructions. Do not permit untrained persons to use or maintain this unit. If you do not fully understand these instructions, contact your supplier for further information.
Page 2: General Information
CONTAINER Pressure Hazard – The containers covered by this literature may contain pressures up to 350 psig (24 bar/2412 kPa). Sudden release of this pressure may cause personal injury SAFETY by issuing cold gas or liquid, or by expelling parts during servicing. Do not attempt any repairs on these containers until all pressure is released, and the contents have been allowed to vaporize to ensure no pressure buildup can occur.
Page 3: Specifications
SPECIFICATIONS XL-65 XL-65HP Dimensions Diameter 26 in. (660 mm) 26 in. (660 mm) Height* 59 1/4 (1505 mm) 59 1/4 (1505 mm) Weight, Empty 5 Caster Base 375 lb. (170 kg) 465 lb. (211 kg) 4 Caster Base 445 lb. (202 kg) 535 lb.
Page 4 CAUTION: Handling the Container When using a hoist, always insert hooks The XL Series containers are very rugged liquid cylinders. All cryogenic liquid containers into both lifting lugs. have an inner container and an outer container with an insulated vacuum space between Failure to do so could them.
Page 5: Operation
The XL-65/65HP will store up to 240 liters of product. The two cylinders can deliver either OPERATION liquid or gas. The following component and circuit descriptions are pertinent to the opera- tion of all the containers and should be read before attempting operation. The components may be identified on the Component Location Illustration.
Page 6: Flow Diagram
Pressure Building is not normally required unless container pressure drops below the gas output pressure desired. If, for example, the container pressure gauge reads 250 psig (17.2 bar/1724 kPa), and your gas pressure requirement is 270 psig (19 bar/1860 kPa), and the pressure building valve may be opened to build container pressure to 300 psig (20.7 bar/2068 kPa).
Page 7 RELIEF VALVES AND RECOMMENDED REGULATOR SETTINGS Relief Pressure Normal Valve Building Economizer Operating Setting Setting Setting Range 22 psig 0-22 psig 1.5 bar 0-1.5 bar 152 kPa 0-152 kPa 230 psig 125 psig 145 psig 125-230 psig 16 bar 8.6 bar 10 bar 8.6-16 bar 1586 kPa...
Page 8 WITHDRAWING GAS FROM THE CONTAINER To withdraw gas from the XL-65/65HP connect a suitable pressure regulator to the USE connection, and the output of the regulator to your external equipment. Then open the USE and the PRESSURE BUILDING valves. When the container pressure reaches 125 psig (8.6 bar/862 kPa) for the XL-65, —or 300 psig (20.7 bar/2069 kPa) for the XL-65HP –...
Page 9: Filling The Container
FILLING THE CONTAINER Cryogenic liquid containers must always be filled by weight to ensure there is enough gas head space (usage) for liquid to expand as it warms. Using the procedure below, first determine the proper filled weight of each container. The weight derived is then used in either the Pump Transfer of Pressure Transfer filling procedures that follow.
Page 10 Pressure Transfer Filling Procedure (Low Pressure Source) – Once you have deter- mined the proper full weight for a container, connect a transfer hose to the LIQUID fitting from a low pressure source of liquid. 1. Open the supply valve. Then, on the XL-65/65HP, open the LIQUID and VENT valves to begin the fill.
Page 11 Fill Hose Kits In use, the CGA Tailpiece couples to the fill connection on the container being filled. The Relief Valve vents pressure over 350 psig (24 bar/2413 kPa) that builds up in the fill line due to trapped liquid. The Dump Valve is used to allow the operator to blow-don the receiving container during a pump fill, or to relieve residual pressure from expanding liquid trapped in the line before disconnecting the fill line.
Page 12: Maintenance Procedures
VENT TEE CHART The vent tee connects to a transfer hose to complete a fill line kit. Each assembly in- cludes a 3/8 in. pipe connector to CGA fitting with a a 350 psig (24 bar/2413 kPa) relief valve, and a ball-type dump valve. WARNING: Never put any liquid Service...
Page 13 CAUTION: When changing gas service, install proper 3. Install new fittings for the USE, VENT and LIQUID connections form the Gas Service fittings – DO NOT use Change Kit. Leak test the fittings you just replaced, and change the gas service de- adapters.
Page 14 Regulator Removal or Replacement Procedure 1. Close manual Pressure Building Valve. 2. Vent the container to atmospheric pressure. 3. Loosen and remove both the tube connections on the pressure building and econo- mizer output sides on the regulator. 4. Remove the regulator from the container by unscrewing the valve body and elbow from the output of the Pressure Building Valve.
Page 15 CHECKING CONTAINER PERFORMANCE Cryogenic containers are two containers, one within the other. The space between the containers acts as a highly efficient thermal barrier including high technology insulation, a vacuum, and a vacuum maintenance system. Each serves a very important part in the useful life of the container.
Page 16 WARNING: FULL VIEW CONTENTS GAUGE MAINTENANCE Cold surfaces should never be handled The content of these containers is measured with the Full View Contents Gauge. The with bare skin. Use device consists of the gauge assembly beneath a clear plastic protective cover. When the gloves and other gauge is assembled, a level indicator ring is magnetically coupled to the top of a float rod protective clothing...
Page 17 NOTE: The yellow band will move approximately ¼ in. (6/4 mm) to each 10 turns on the rod. NOTE: Remember this procedure is performed with gauge in an upright (vertical) position. NOTE: Make sure that the Gauge Assembly is not bent or out of line before reinserting the gauge into the container.
Page 18 6. When you are satisfied that the float rod correctly installed, lower the assembly the CAUTION: rest of the way into the container until the top portion threads can be engaged. When installing the gauge assembly, care 7. Screw the gauge in place and hand torque to about 20 ft lbf (2.8 kgf m). Leak check the must be taken to connection of gauge body to the flange.
Page 19 HAND VALVE REPAIR Hand valves are an integral par of the container and the valve bodies rarely need replace- ment. However, the handwheel and internal part of the valves are renewable. The illustra- tion below are exploded views of the valves replaceable parts used on Taylor-Wharton liquid containers.
Page 20 Valve Replacement Instructions 1. Partially thread Seat Assembly (12) (seat disc first) into large end of Bushing (13) leaving tan of nipple assembly exposed about 1/8 in. beyond top of Bushing. 2. Insert Seat Assembly (seat disc first) with attached Bushing, into valve body until properly seated.
Page 21: Troubleshooting Chart
TROUBLESHOOTING The following chart is provided to give you some guidance in determining the probable cause and suggested corrective action for some problems that may occur with cryogenic liquid containers. This chart is specifically tailored to your XL-65 or XL-65HP. TROUBLESHOOTING CHART Symptom Possible Cause...
Page 22 TROUBLESHOOTING CHART Symptom Possible Cause Corrective Action Container is cold and 1. Vacuum loss. Check NER. 1. Consult with Taylor-Wharton may have ice or frost for course of action. Do not on outer casing. Will attempt to put additional not hold liquid over- liquid in container.
Page 23: Replacement Parts
REPLACEMENT This replacement parts list includes a recommended inventory quantity which allows you to order parts on a timely basis to keep all your XL-65/65HP containers in service. When PARTS placing orders, please use the nomenclature and part numbers in this section and send written orders to: Taylor-Wharton Fax: (334)443-2209...
Page 24 Component Locations for XL-65 and XL-65HP ACCESSORIES Accessories available for use with Taylor-Wharton XL Series containers are: - Manifolds, Automatic and Manual - Container Hand Trucks - Vaporizers adding up to 250 cfh - Cryogenic Phase Separators (6.6 cu.m/h) each - Transfer Hoses (O , AR, CO and N...
Page 25 Index Recommended Description Part No. For 10 Units Dual Regulator, Pressure Building/Economizer 6999-9018 2 Each 300 psig (20.9 bar/2068 kPa) Dual Regulator, Alternate, Pressure Building/Economizer 6999-9015 2 Each 125 psig (8.6 bar/862 kPa) - Not available for C0 service Gasket, Glass Filled Teflon, Contents Gauge (Not Shown) 7701-0083 5 Each Contents Gauge Assembly (Includes Gauge and Spring)
Page 26 Index Recommended Description Part No. For 10 Units - VENT (CGA 440) - oxygen 6514-8992 5 Each - VENT (CGA 295) - argon/nitrogen 7355-4712 5 Each - VENT (CGA 295) - carbon dioxide 7355-4712 5 Each - VENT (CGA 295) - nitrous oxide 7355-4712 5 Each Decal, Carbon Dioxide...
