Summary of Contents for Tisch Environmental TE-5200
- Page 1 OPERATIONS MANUAL TE-5200 TSP Tri-Pod High Volume Air Sampler Tisch Environmental, Inc. 145 South Miami Avenue Village of Cleves, Ohio 45002 Toll Free: (877) 263 -7610 (TSP AND-PM10) Direct: (513) 467-9000 FAX: (513) 467-9009 sales@tisch-env.com www.tisch-env.com...
- Page 2 TE-5200 TE-5200 Operations Manual...
-
Page 3: Welcome
Assistance If you encounter problems or require detailed explanations, do not hesitate to contact Tisch Environmental offices by e-mail or phone. Toll Free: (877) 263 -7610 (TSP AND-PM10) Direct: (513) 467-9000 FAX: (513) 467-9009 sales@tisch-env.com... -
Page 4: Table Of Contents
Assembly ___________________________________________________________________ 11 Operations _________________________________________________________________ 12 Calibration Worksheets ____________________________________________________________ 12 Calibration Procedure _____________________________________________________________ 12 Example Problems ________________________________________________________________ 16 Sampler Operation ________________________________________________________________ 23 Troubleshooting _____________________________________________________________ 24 Maintenance and Care ________________________________________________________ 26 Motor Brush Replacement _____________________________________________________ 27 Warranty __________________________________________________________________ 30 TE-5200 Operations Manual... - Page 5 Assembly Drawings __________________________________________________________ 31 TE-5005 Blower Motor _____________________________________________________________ 31 TE-5003 Filter Holder ______________________________________________________________ 32 Calibration Worksheet Sample _________________________________________________ 33 Calibration Certificate ________________________________________________________ 34 TE-5200 Operations Manual...
-
Page 6: Introduction
Before using Tisch Environmental products, always be sure to review the corresponding operations manuals and take all necessary safety precautions. Tisch Environmental products are to be used only for the purposes specified by operations manuals and by Tisch Environmental personnel. Tisch... -
Page 7: Electrical Installation
Always ensure that extension cords are properly wired and in good electrical condition. Always replace damaged extension cords immediately, or seek repair from qualified electricians before further use. Remember to protect extension cords from sharp objects, excessive heat, and damp or wet conditions. TE-5200 Operations Manual... -
Page 8: Product Description
The physical design of the sampler is based on aerodynamic principles which result in the collection of particles of 100 microns (Stokes Equivalent Diameter) and less. The TE-5200 TSP Tripod consists of a TE-5002 Anodized Aluminum Tri-Pod Shelter, TE-5005 Aluminum Blower Motor Assembly, TE- 5003 8”x10”... -
Page 9: Calibration Kits
Calibration Kits The TE-5028 is the preferred method to calibrate the TE-5200 TSP Tripod High Volume Air Sampler. It simulates change in the resistance by merely rotating the knob on the top of the calibrator. The infinite resolution lets the technician select the desired flow resistance. - Page 10 TE-5010 110volt, 60hz TE-5010X 220volt, 50hz TE-5010XZ 220volt, 60hz 2. Leg Box - 49" x 3" x 3" 7 lbs 3 pcs – Anodized Aluminum Legs TE-5200-10 *** Save the shipping containers and packing material for future use. TE-5200 Operations Manual...
-
Page 11: Assembly
8. The motor voltage control/elapsed time indicator male cord set plugs into line voltage outlet. The motor will come on depending on what the voltage control pot is set at on front panel. To adjust voltage, take screwdriver and turn screw on control pot. TE-5200 Operations Manual... -
Page 12: Operations
We recommend that you download the worksheet before following the procedure below. Calibration Procedure The following is a step by step process of the calibration of a Model TE-5200 Tripod Total Suspended Particulate High Volume Sampling System. Following these steps are example calculations determining the calibration flow rates, and resulting slope and intercept for the sampler. - Page 13 This includes the transfer standard orifice calibration relationship which was taken from the Orifice Calibration Certificate that accompanies the calibration orifice. Since this calibration is for a TSP sampler, the slope and intercept for this orifice uses TE-5200 Operations Manual...
- Page 14 FLOW (corrected) = [Sqrt((H O)(Pa/760)(298/Ta))] where: flow (corrected) = sampler manometer readings corrected to current Ta and Pa O = sampler manometer readings during calibration Pa = ambient barometric pressure during calibration, mm Hg. TE-5200 Operations Manual...
- Page 15 where: n = number of observations TE-5200 Operations Manual...
-
Page 16: Example Problems
2. degrees Kelvin = [5/9 (degrees Fahrenheit - 32)] + 273 or degrees Kelvin = degrees Celsius + 273 3. millimeters of mercury = 25.4 * (inches of Hg) Inserting the numbers from the calibration worksheet run point number one we get: Qstd = 1/1.47574[Sqrt((5.7)(757/760)(298/293)) - (-.00613)] TE-5200 Operations Manual... - Page 17 298 = standard temperature, K Inserting the data from run point one on the calibration worksheet we get: FLOW (corrected) = [Sqrt(5.4)(757/760)(298/293)] FLOW (corrected) = Sqrt(5.47047) FLOW (corrected) = 2.3389035 This procedure should be completed for all five run points. TE-5200 Operations Manual...
- Page 18 x = 1.632 + 1.529 + 1.483 + 1.435 + 1.316 = 7.395 y = 2.34 + 2.21 + 2.15 + 2.07 + 1.94 = 10.71 x = (1.632) + (1.529) + (1.483) + (1.435) + (1.316) = 10.991635 TE-5200 Operations Manual...
- Page 19 ( 15.90991 ) − ( ���������� = 54.686025 10.991635 − ( 15.90991 − 15.84009 ���������� = 10.991635 − 10.937205 slope = 0.05443 slope = 1.2827484 intercept = 2.142 - (1.2827484)(1.479) 2.142 – 1.8971848 intercept = intercept = 0.2448152 TE-5200 Operations Manual...
- Page 20 36. correlation coeff. = 90991 991635 937205 0307 94082 90991 84009 37. correlation coeff. = 991635 937205 )][( 0307 94082 06982 38. correlation coeff. = 05443 08988 39. correlation coeff. = 40. correlation coeff. = 41. correlation coeff. = .998 TE-5200 Operations Manual...
- Page 21 .780701 (1.6377123) /min = 1.2785636 /min = 1.2785636 x 35.31 = 45.14608 Total ft = ft /min x 60 x hours that sampler ran Let's say our sampler ran 23.9 hours (end ETI reading - start ETI reading) TE-5200 Operations Manual...
- Page 22 ** Make sure ETI is in hours otherwise convert to hours ** Total ft = 45.145608 x 60 x 23.9 = 64,739.478 ft Total m = 1.2785636 x 60 x 23.9 = 1833.4602 m TE-5200 Operations Manual...
-
Page 23: Sampler Operation
5. Close shelter lid carefully and secure with the "S" hook. 6. To start TE-5200 TSP Tripod High Volume Air Sampler, plug male cord set from blower motor into female cord set of motor voltage control/elapsed time indicator. -
Page 24: Troubleshooting
-Check Motor -Check timer settings -Make sure current date and time are correct -Make sure power cords are properly connected Digital timer not working -Check fuse on main PC board (F3) -Check Power Supply -Check Motor TE-5200 Operations Manual... - Page 25 -Check Power Supply -Check motor -Make sure all gaskets are in place -Make sure all connections are secure Air Leaks -Makes sure connections are not over tightened -Check for damaged components: Filter holder screen, gaskets, motor flanges TE-5200 Operations Manual...
-
Page 26: Maintenance And Care
We recommend that the following cleaning and maintenance activities be observed until a stable operating history of the sampler has been established. TE-5200 TSP Tri-Pod 1. Make sure all gaskets (including motor cushion) are in good shape and that they seal properly. -
Page 27: Motor Brush Replacement
Try to pry the tabs as far as you can without damaging the armature. 4. With a screwdriver loosen and remove brush holder clamps and release brushes. Carefully, pull quick disconnect tabs from expended brushes. TE-5200 Operations Manual... - Page 28 9. Assemble motor after brush replacement by placing housing over and down on the motor (at same time pull power cord out of housing), being careful not to pinch any motor wires beneath the motor spacer ring. 10. Secure power cord with the cord retainer cap. TE-5200 Operations Manual...
- Page 29 Change brushes before brush shunt touches armature. Seat new brushes by applying 50% voltage for 10 to 15 minutes, the TE-5075 brush break in device allows for the 50% voltage. TE-33384(green) TE-116311 110v Motor for TE-5200 110v Motor Brush TE-116312 TE-33378(brown) 220v Motor for TE-5200...
-
Page 30: Warranty
Brush-type and brushless motors will carry a warranty as far as the original manufacture will pass through its warranty to Tisch Environmental, Inc. The right is reserved to make changes in construction, design specifications, and prices without prior notice. -
Page 31: Assembly Drawings
Assembly Drawings TE-5005 Blower Motor TE-5200 Operations Manual... -
Page 32: Te-5003 Filter Holder
TE-5003 Filter Holder TE-5200 Operations Manual... -
Page 33: Calibration Worksheet Sample
Calibration Worksheet Sample TE-5200 Operations Manual... -
Page 34: Calibration Certificate
Calibration Certificate TE-5200 Operations Manual...
