Summary of Contents for Vanguard Instruments CT-7500 S2
- Page 1 RESISTOR TRANSDUCER ADAPTER USER’S GUIDE Vanguard Instruments Company, Inc. 1520 S. Hellman Ave. Ontario, California 91761, USA TEL: (909) 923-9390 March 2011 FAX: (909) 923-9391 Revision 1...
- Page 2 CT-7500 S2 USER’S MANUAL REV 2 Calibrating the Resistor Transducer Adapter The Vanguard Resistor Transducer Adapter must be calibrated each time a different resistor transducer is connected to the adapter. Follow the steps below to calibrate the adapter: a. Connect the resistor transducer to the adapter.
- Page 3 REV 2 CT-7500 S2 USER’S MANUAL f. The following screen will be displayed: ↑/↓ TO SET DISTANCE 5.00 IN 12.70 CM “ENTER” WHEN DONE Press the [▲] or [▼] key to set the value to the known traveled distance (distance between the endpoints of the transducer) and then press the [ENTER] key.
- Page 4 CT-7500 S2 USER’S MANUAL REV 2 Adjusting the Screen Contrast Follow the steps below to adjust the adapter’s screen contrast a. From the “RUNNING” screen, press either the [▲] or [▼] key to access the Main Menu. The following screen will be displayed:...
- Page 5 REV 2 CT-7500 S2 USER’S MANUAL Performing Diagnostics Follow the steps below to perform diagnostics and confirm that the adapter is calibrated properly: a. Move the resistor transducer to one end of its travel. b. From the “RUNNING” screen, press either the [▲] or [▼] key to access the Main Menu.
- Page 6 CT-7500 S2 USER’S MANUAL REV 2 Connection Illustrations Figure 1. Typical Connection to ABB AHMB Transducer Figure 2. Typical Connection to a Resistor Transducer...
- Page 7 1520 S. Hellman Ave • Ontario, CA 91761 • USA Phone: 909-923-9390 • Fax: 909-923-9391 www.vanguard-instruments.com Copyright © 2011 by Vanguard Instruments Company, Inc. Resistor Transducer Adapter Calibration Procedure • Revision 1.0 • March 1, 2011 • TA...
