Holtkamp DUO 8600 XL Operating Instructions Manual

Coin and chip card system
Hide thumbs
Table of Contents

Advertisement

Quick Links

DUO 8600 XL
Coin and chip card system
Operating instruction

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DUO 8600 XL and is the answer not in the manual?

Questions and answers

Summary of Contents for Holtkamp DUO 8600 XL

  • Page 1 DUO 8600 XL Coin and chip card system Operating instruction...
  • Page 2 Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 S ü d s t r a ß e 4 0 / D- 4 9 0 8 4 O s n a b r ü c k info@holtkamp.de / www.holtkamp.de EU-Konformitätserklärung / European Union conformity explanation Für das nachfolgend bezeichnete Erzeugnis / For the following designated product...

  • Page 3: Table Of Contents

    Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 Content 1 Legal information ..................................4 2 Warranty ....................................4 3 Safety notices ..................................... 4 4 Device specific data ..................................4 5 Specifications ..................................... 4 6 General details ..................................... 5 7 Illustrations ....................................5 Illustration of the devices ..............................

  • Page 4: Legal Information

    After switching on the electricity on the display appears for approx. 2 seconds: Holtkamp XXL X.x, below in the second Do observe the in the user manual specified or prescribed row: T-Timer. This is information about the used software version deadlines for recurring maintenance intervals! Do provide for the safe and environmentally friendly disposal of plastic parts (XX.x) as well as the operating type of the DUO (T-Timer).

  • Page 5: General Details

    Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 General details Casing material galvanised steel plate 2 mm Casing color powder coated white RAL 9016 Dimensions h 300 mm x w 218 mm x d 141 mm Power supply 230 V or 24 V, 50 / 60 Hz Switched power 6,3 A by cos phi = 1 Power absorption 10 VA Cable entrance from behind (3 drilled holes) Temperature range 0°C - 50°C Protection class I by 230V~ and/or III by 24V~ Protection type IP 20 Weight (with empty coin-bag) app. 7,5 kg Weight (with full coin-bag) app.

  • Page 6: Illustration Of Electronic

    Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 Illustration of electronic Jumper remote start (FS): Jp FS = 0 Jp FS = without function standard Serial interface Connection for multiple coin tester Battery Connection for serial remote display Connection for bridge switch 6a Additional relay for 110%-dis connection 6b Main relay 6c Run-out relay 7a Fuse main relay 7b Fuse lead relay Power connection...

  • Page 7: Mounting Notes

    Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 Mounting notes Mounting instructions ● This device may only be mounted on a suitable surface. ● Shut down the power input, by activating the immobilising switch, the fuse or even the main safety fuse. ● The device must be sufficiently secured, take into consi- deration the weight of the inserted coins. There are 6 holes ● Unlock and remove the coin box. in the back of the casing to accomplish the mounting pro- ● Loosen the two screws of the fuse plate, remove the fuse cess. Screws and dowels are included by delivery. plate and raise the casing so that it is possible to pull out ●...

  • Page 8: Operating The First Time

    Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 Operating the first time If the DUO is installed completely, you can take into operation by 8.5.1 LED operating light switching on the circuit. As soon as the circuit is activated, appe- ars in the display an information about the operation mode of you With the LED operating light one can see, at a glance, the opera- DUO and about the used software. (e.g. Holtkamp XL Soft X.x ting stand of the DUO. During the lead time: quick blinking; main T-Timer Free). The DUO is now ready for operation and can now time: permanent light; run-out time: slow blinking. be programmed as you like. To ensure, that the programming has been correct, you should make a detailed test run. After this test run all counters should be deleted to receive a correct account. Please make sure that your adjusted main time is appropriated to the sun bed. Do not choose the main time too long, because of the danger of the sun bed customer. Use the adjustment setting, to limit the maximum time and therefore limiting the maximum account of buyable main time to reduce to a minimum the danger to the customer.

  • Page 9: Specifications

    Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 Specifications DUO 8600 XL controls 1 device (e.g. Sun bed) Electronic multiple coin tester Chip card contact unit without reject magnet Chip card revaluation via keyboard by the owner/personnel or per cash insert by the customer Lead time Main time (1 min. – 4 hours 15 min.) Maximum time Overrun time LCD display (time a. info text indication) Programming with chip card Time memory Price setting coin and chip card amount Minimum payment / debit Happy Hour Skin type distinction UV-Control tanning management Electronic cash counter...

  • Page 10: Operating Types

    Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 Operating types By DUO you can select two operating types in the configuration menu: 1. Timer operating: - for all time-depending processes 2. Revaluation operating: - for revaluing of chip cards by coins or by revaluation chip card type 73 - in this operating mode the DUO is exclusively as revaluati- on device to use - an unintentional buy of time is not possible The revaluation operating mode can be configured in three different types: Revaluation by inserting of coins: Revaluation by both possibilities - In t ime/price m enu t he p oint " revaluation-step c ard” m ust b e s et - In the time/price menu the point “revaluation-step card” must...

  • Page 11: Basic Programming For Operating Mode "Timer" (Factory Setting)

    Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 12.2 Basic programming for operating mode “Timer” (factory setting) Your DUO has been factory set with standard programming. The program values are written in the appropriate displays. 12.2.1 Time/price menu, cash = card “no” to call with: to quit with: insert chip card pull out chip card...
  • Page 12 Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 Display ad Factory setting Description Main time 0:03:00 min The main time card 2 is the operating time of the connected device, payable by card 2 chip card. It is always active on the second step of the various payment types. It is recallable and programmable if any adjustments have been made in the „Configuration menu”. It can be adjusted in 1 second steps, to a max of 99 min or 1 hr, 39 min Main time 0:04:00 min Main time card 3 analogue Main time card 2 card 3 Main time 0:01:00 min The main time cash 1 is the operating time of the connected device, payable cash 1 by cash. It is recallable and programmable, if any adjustments have been made in the „Configuration menu”. It can be adjusted in 1 second step, to max. of 99 min or 1 hr, 39 min. Main time 0:02:00 min...
  • Page 13 Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 Display ad Factory setting Description Cash price 2 4.0 EUR Analogue cash price 1, however the price which by the second step of the various payment types is active Cash price 3 5.0 EUR Analogue cash price 1, however the price which by the third step of the various payment types is active. Price step 1.0 EUR...
  • Page 14 Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 Display ad Factory setting Description Service interval 2 0 hrs The service interval 2 offers the possibility for further note operating hours. When the service hour counter 2 reaches the operating hours, an exclamation mark will be shown on the display and signals the need of service. By can- celling the service hour counter 2 the exclamation mark is also deleted. The...

  • Page 15: Clock Menu

    Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 12.2.2 Clock menu to call with: to quit with: insert chip card pull out chip card type 63 type 63 Is non-existing a chip card type 63 non-existing, you can start the menu also with change over the DIP switches no. 3 and 4 on "on".
  • Page 16 Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 Display ad Factory setting Description Switch time Mo-Fr 1 **:** First switching time (valid from Monday to Friday) Tariff Mo-Fr 1 First tariff (valid from Monday to Friday). The tariff is freely chosen between tariff 1, 2, 3 and blockage. (A payment is not possible during the activated blockage.) Switch time Mo-Fr 2 **:** Second switching time (valid from Monday to Friday) Tariff Mo-Fr 2 Second tariff (valid from Monday to Friday). The tariff is freely chosen between tariff 1, 2, 3 an blockage. (A payment is not possible during the activated blocka- ge). Switch time Mo-Fr 3 **:** Third switching time (valid from Monday to Friday) Tariff Mo-Fr 3 Third tariff (valid from Monday to Friday). The tariff is freely chosen between ta- riff 1, 2, 3 and blockage. (A payment is not possible during the activated blocka- Switch time Mo-Fr 4 **:** Fourth switching time (valid from Monday to Friday) Tariff Mo-Fr 4 Fourth tariff (valid from Monday to Friday). The tariff is freely chosen between tariff 1, 2, 3 and blockage. (A payment is not possible during the activated...

  • Page 17: Configuration Menu

    Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 12.2.3 Configuration menu to call with: to quit with: insert chip card pull out chip card type 83 type 83  By trespassing the configuration menu do not change Is a chip card type 83 non-existing, you can start the menu also with change over the DIP switches no. 1, 2 and 3 on "on". any values! Uncontrolled programming can´t be follow- If the programming is finished, you must change only DIP switch ed by your wished functions. In the worst case the de- vice can be put out of function totally.
  • Page 18 Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 The recognition and evaluation runs as following … ...in the electronic multiple coin acceptor (EMP) … in DUO 1. coin was thrown in 2. coin is assigned the 3. "Exit channel" of EMP is as- 4. the "entrance" of DUO is channel in the EMP signed the "Entrance" of assigned (by the factory DUO or individually) the programs...
  • Page 19 Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 Notes for the electronic multi coin acceptor Your DUO is equipped with an electronic multiple coin acceptor. Please consider the following noticing: ● Well worn, dirty, damaged, false and foreign currency coins ● Strong temperatures fluctuations and magnetic fields could will not be accepted. affect the acceptance behaviour of the coin acceptor. ● If an apparently good coin is not accepted, please use an- ● The r emoving o r i nstalling o f a n e lectronic m ulti c oin a cceptor other coin.
  • Page 20 Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 Display ad Factory setting Description Token impulse c. 5 ● If “yes” is set up, in the statistic menu will be shown the daily token counter and total token counter. The value of token has to be set up under the menu item "Coin tester valuing channel 5”. Factory setting is value “0”. ● If “no” I set, the token counter is deactivated. Token impulse c. 6 ● If “yes” is set up, in the statistic menu will be shown the daily token counter and total token counter. The value of the token is on “3,5” factory set up and is put out to channel 6 on EMP. If you want to change the value of the Holtkamp token, you will have to set it up from menu item “Coin tester valuing”. ● If “no” I set, the token counter is deactivated. Daily counters The daily counter setting offers the possibility to display all the daily counters in the statistic menu or not. ● If “yes” is set, all available daily counters will be displayed.

  • Page 21: Bus Configuration Menu

    Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 12.2.4 Bus configuration menu This menu is only of interest to you, if you owned a network (HE- LIOTEX or DELTA XL) or you need a connection to SkinControl. If you want to set up a network, please read the instructions, which are included with the particular software. to call with: to quit with: Therefore the DIP switch no. 3 must set on “on”. pull out chip...

  • Page 22: Chip Card Revalue

    Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 Chip card revalue 13.1 Personnel revalue mode to call with: to quit with: The menu is left automatically, if longer than 15 seconds no acti- on is implemented or the RESET button is pressed. insert chip card pull out chip card The re-value mode offers the possibility, in pre-adjusted steps by type 73 type 73 the owner, to revalue or cancel chip cards type 11, 14 or 15. The revaluing is possible in every operation of the DUO, even during an expiring main time.

  • Page 23: Statistics

    Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 Statistics 14.1 Explaining the statistics values ● Daily card impulse counter ● Total EMP revalue impulse counter* Counter f or t he d educted a mounts f rom t he c hip c ard t ype 1 1.

  • Page 24: Enquiring The Statistic Values In Operation Mode "Timer

    Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 14.2 Enquiring the statistic values in operation mode “Timer” When you are in the normal mode, by inserting a chip card type 33, you reach the statistic menu (the chip card type 43 can, of course, also, be used. With it, it is possible to cancel the counter reading). With the OK key you reach the next menu item. You leave the menu by removing the chip card. to call with: to quit with: insert chip card...

  • Page 25: Cancelling The Statistic Values

    Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 14.4 Cancelling the statistic values To leave the menu, remove the chip card. The total operating When you are in the normal mode, you can change to the stati- stic menu by inserting the chip card type 43. DIP switch Nr.3 must hours counter can be pre-set to a starting value by the RESET be at "on" (up). With the OK button you can choose the counter, and PLUS button. If both buttons are pushed at once the starting value will be cancelled.

  • Page 26: Readout The Code

    Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 14.6 Readout the code 14.7 Cancelling the failure statistics Call up see under 14.5 “Enquiring the failure statistics”. After When you are in the normal mode, you can change to the stati- advertisement of the error messages, go along with “OK” button. stic menu by hold pressed PLUS button and insert chip card type 43. Unhand the PLUS button. With OK button you change to the The code is advertised: error message which should be deleted. Press the PLUS and RESET button at once, the selected error statistic is cancelled.

  • Page 27: Remote Indications Incl. Connection Possibility In Duo With Or Without Remote Start

    Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 15.9 Remote indications incl. connection possibility in DUO with or without remote start The remote indication is an additional device with LED display, which shows the client the remained time, locally parted from the DUO. The remote indication is with or without remote start but- ton. If your DUO has been ordered with a remote start button you can find on the SB frame, on the inside of the back of the device, an additional circuit board, which needs to be connected to the remote indication as following: Connection to the XL with 4-pol. installation cable (shielded, The needed connection cable is not included by delivery. screen on one side presented) maximum conduit length 12 m.

  • Page 28: By Malfunctions

    Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 By malfunctions If your DUO does not behave as you would like, try to help your- self with the following list. If you cannot repair the problem your- self, then the trader is, of course, there to help. Malfunction Cause Possible remedy Fuse with continuity tester to meter, ch- fuse damaged ange fuse The display is black no operating voltage test the mains voltage DUO wrongly installs test the connection The DUO functioned, but the attached de- vice does not functioned. fuse of the switched phase defectively change the fuse of the PCB...
  • Page 29 Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 Malfunction Cause Possible remedy The display shows error message E06 EEPROM-Speicher defekt send DUO to repair The display shows error message E12 DIP switch no. 3 is on “OFF” set DIP switch no. 3 on “ON” maximum time is adjusted smaller than the adjust the maximum time or change the The display shows error message E14 main time main time the deletion is with this type of card not The display shows error message E14 put in chip-card type 43 possible The display shows error message EEPROM memory is defect send DUO to repair E18 or E19...

  • Page 30: Index

    Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 Index Symbole 3 digits main time General at programming 10 General details 5 Autom. summer time Autom. Summertime Hours/Minutes 14 HQL time 14 Basic programming for operating mode Timer Baudrate Illustration of electronic 6 Illustration of the devices 5 Bonus amount Bonus Step Internal short time impulse 26 Brightness Bus configuration menu Key switch for free use 26 cancel button Cancelling the failure statistics...
  • Page 31 Holtkamp Electronics DUO 8600XL techn. stand 05.2016 4033_05.2016 V01.2021 Safety notices Service hours counter 1 Service hours counter 2 Service hours counter 3 Service interval Setting the channel on the EMP 800.00 v 6 Setting the channel on the EMP 800.00 v 6 Specifications Statistics Statistics values Switch time Tariff Test mode Time/price menu Timer operating Time stop Token counter Token daily pulse counter 6 Token impulse counter Total card impulse counter Total cash impulse counter Total customer impulse counter Total EMP bonus impulse counter Total EMP revalue impulse counter Total operating hours impulse counter Total revalue impulse counter Total token impulse counter - 31 -...
  • Page 32 For technical information during our business hours: Monday - Thursday 8.00 a.m. - 16.00 p.m. and Friday 8.00 a.m. - 13.00 p.m. choose: +49 541 97120-0 or visit our homepage: www.holtkamp.de Technical Stand 09.2019 / We reserve the right to technical changes in the production and technical developments. Südstraße 40, D-49084 Osnabrück Phone: +49 541 97120-0 info@holtkamp.de...
