Steel Hand Crank Hose Reel
Instruction Manual
WARNING:
Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety
rules and other basic safety precautions may result in serious personal injury.
Save these instructions in a safe place and on hand so that they can be read when required.
Keep these instructions to assist in future servicing.
REV 02/25/19
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for JobSmart 1363310
Summary of Contents for JobSmart 1363310
- Page 1 Steel Hand Crank Hose Reel Instruction Manual WARNING: Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Save these instructions in a safe place and on hand so that they can be read when required. Keep these instructions to assist in future servicing.
- Page 2 GENERAL SAFETY REGULATIONS WARNING: The warnings, cautions, and instructions discussed in this instruction manual cannot cover all possible conditions or situations that could occur. It must be understood by the operator that common sense and caution are factors that cannot be built into this product but must be supplied by the operator.
- Page 3 TECHNICAL DETAILS Hose Capacity Item No. Max Pressure Inlet/Outlet Material I.D. Length 1363310 300Psi (20Bar) Flexible Hybrid Polymer 3/8”(9.50mm) 75ft/22.80m 1/4" 12.99"/330mm 10.24"/260mm 13.33"/338.5mm SAFETY PRECAUTIONS 1. Make sure incoming pressure does not exceed the rated pressure. 2. Use the proper eye protection when assembling and using the hose reel.
- Page 4 4. Carefully disconnect hose from swivel joint on side of reel, or male fitting in axle center and remove old hose. 5. Feed new hose through guide and opening in drum, and connect to swivel. Re-install two hose clamps, on inside and outside of drum flange. 6.
