During measurements, you can
display these 4 usual signal/indices
on the touch screen :
You must avoid saturation in single signals.
FRF_R, FRF_G,
- exceed 4300
- be under 20
You have to adapt the « measurement range » to:
1/ diameter of the aperture of Multiplex.
2/ level of chlorophyll of the plant you are measuring
3/ in field or in greenhouse measurements
For more explanations, see MxUserGuide_Firmware.pptx.
Slide 6 : Cfg screen.
FRF_B,
FRF_UV
Check Multiplex every day you measure with
the
blue
(and
the sheet 'Multiplex checking'.
must not :
Multiplex use
red
for Mx 330) standard : use
Mx 330: use black
glove to measure
