SmartOne 70-600000-001 Installation Instructions

Remote releasing module

Advertisement

Quick Links

control unit
installation,
part number
operation and
Maintenance Manual
part number
FenwalNET 6000:
74-600000-001
06-236529-001
74-600000-510
06-236529-001
ARIES:
76-600000-004
06-236530-001
FenwalNET 8000-ML:
74-800100-001
06-237041-001
74-800101-002
06-237041-001
74-800200-001
06-237041-001
74-800201-002
06-237041-001
74-800102-001
06-237041-001
74-800202-001
06-237041-001
ARIES NETLink:
76-800100-001
06-237058-001
76-800101-002
06-237058-001
76-800200-001
06-237058-001
76-800201-002
06-237058-001
76-800102-001
06-237058-001
76-800202-001
06-237058-001
This device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) This device may not cause any harmful interference, and (2) This device must
accept any interference received, including interference that may cause undesired operation.
TM
KIDDE-FENWAL INC.
400 MAIN STREET, ASHLAND, MA 01721
TEL: (508) 881-2000 FAX: (508) 881-8920
configuration
software
user's Guide
part number
06-236529-002
06-236529-002
06-236530-002
06-237042-001
06-237042-001
06-237042-001
06-237042-001
06-237042-001
06-237042-001
06-237059-001
06-237059-001
06-237059-001
06-237059-001
06-237059-001
06-237059-001
This literature is provided for informational purposes only.
KIDDE-FENWAL,INC. assumes no responsibility for the
product's suitability for a particular application. The product
must be properly applied to work correctly.
If you need more information on this product, or if you have
a particular problem or question, contact KIDDE-FENWAL
INC., Ashland, MA 01721. Telephone: (508) 881-2000
©
06-236636-001
Rev. AD
2016 Kidde-Fenwal, Inc.
Remote Releasing Module
installation instRuctions

DescRiption

The Remote Releasing Module (RRM) is a UL Listed, FM Approved
smartone
Field Device. The RRM provides the ability to remotely activate
®
extinguishing-system control devices. Connection is via the smartone com-
patible control panel's Signaling Line Circuit (SLC). The module is field-pro-
grammable using the control panel keypad or Hand-Held Programmer.
The RRM provides internal supervision of communication with the control
unit, connections to external power supply, and memory status.
Solenoid release circuits are power-limited and supervised for short circuit
by using an In-line Releasing-Circuit Device (P/N 06-220023-001). In the
event of a ground fault, open, short or a relay contact failure, the device
will transmit a trouble status to the control unit.
A status LED is mounted on the RRM and indicates the module's status:
Normal is indicated by a flash every 9 seconds; Output Activity is indicated
by the LED on continuously (no flashing); Trouble is indicated by the LED
being OFF.
The RRM is intended for indoor dry location use, and is available in two
models, one for mounting in a standard electrical box and a second model
for mounting in suitable UL-864 Listed cabinets.
p/n 70-600000-001: standard Mounting
North American 4-11/16 in. electrical box with a double gang plaster
ring (Rayco Model 841 or equivalent), 1/2 in. raised
4 in. square, 2-1/8 in. deep electrical box
p/n 70-600000-002: in-cabinet Mounting
Any suitable UL-864 Listed enclosure with no other electronics.
The module terminal block will accept #12, #14, #16 and #18 AWG wire
(4.0 mm
, 2.5 mm
, 1.5 mm
and 1.0 mm
2
2
2
minimum requirement. The use of solid wire is recommended.
Effective: October 2016
TM
respectively). Size #18 being a
2
