Guarantee

The Kingkraft Rollator (Children's Walker) with it's accessories is

guaranteed in the UK for a period of 12 months from the date of delivery

against defects arising from faulty material, inferior workmanship or

construction.

The result of incorrect handling of the unit shall not be covered by the

guarantee.

In line with the company's policy of continual product improvement, we

reserve the right to carry out improvements to the specification without

notice.

26D Orgreave Crescent, Dore House Industrial Estate, Sheffield, S13 9NQ

Tel: 0114 269 0697 Fax: 0114 269 5145

e-mail: info@kingkraft.co.uk

url: www.kingkraft.co.uk

Table of Contents

Need help?

Do you have a question about the Walker 320 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kingkraft Walker 320

Page 1 Guarantee The Kingkraft Rollator (Children’s Walker) with it’s accessories is guaranteed in the UK for a period of 12 months from the date of delivery against defects arising from faulty material, inferior workmanship or construction. The result of incorrect handling of the unit shall not be covered by the guarantee.
Page 2 USER MANUAL Kingkraft Rollator (Children’s Walker) Models: Walker 320 + Walker 280 Model..... Serial No....Delivery date........ 26D Orgreave Crescent, Dore House Industrial Estate, Sheffield, S13 9NQ Tel: 0114 269 0697 Fax: 0114 269 5145 e-mail: info@kingkraft.co.uk url: www.kingkraft.co.uk CWFR - ISSUE 1 - 02/10...
Page 3 Technical Data Dimensions: Walker 280 Walker 320 Main Frame Width Main Frame Depth Main Frame Height Total Width Total Length Front Wheel Diameter Rear Wheel Diameter Maximum User load 35Kg 35Kg All dimensions in mm Materials: The tubular frame is made from titanium and is powder coated.
Page 4: Table Of Contents
CONTENTS General information Important Safety Advice Important Safety Instructions / Labels User Instructions / Operation Securing the Rollator (Front Castors / Rear Wheels) Rollator Orientation Locking Pin + Folding Handle Options Care and Maintenance Cleaning and Tools Technical data Guarantee / Warranty Information...
Page 5: General Information
Care and Maintenance Like every technical product, the rollator requires regular inspection. Check the unit frequently for signs of damage, breakage, cracks, fatigue, lost parts and/or non functioning parts. Check all nuts and bolts are present and secured. The locking pin must be inserted correctly and only be removed by pressing the end button.
Page 6: Important Safety Advice
The tools required (not supplied-see tools list later) should only be used by competent persons / qualified professionals, for adjustment only, not for removal of items such as the hinged clamp parts.  The Product is intended for use with the correct Kingkraft specified accessories only.
Page 7: Important Safety Instructions / Labels
Option 2: Straight Handles These are intended to be fitted as shown to the main frame at a comfortable height. They can be fitted anywhere along the straight part of the frame. They can be rotated inwards / outwards before tightening the bolts to adust to the width for the user.
Page 8: User Instructions / Operation
User Instructions / Operation The product is to be used as a walking aid for children up to the weight limit of 35Kg. The rollator is designed for use with smaller children. The suitability of the rollator for a particular child is to be determined by individual risk assessment for each child by the therapist.
Page 9 To secure the rollator frame whilst in transit, please follow these steps to secure the main and rear parts together to stop the possibility of trapping or pinching. Hold the tubes together in one hand and insert the pin through the two holes in the rear hinge / clamp part.
Page 10: Rollator Orientation
Rear Wheels The rear wheels are fixed and uni-directional and will not allow the rollator to roll backwards: Movement in this direction (forward) only Rollator Orientation The rollator will only move in a forward direction, or turn left or right when in motion.
Page 11: Locking Pin + Folding
IMPORTANT SAFETY INSTRUCTONS Dear Customer, Thank you for purchasing this high quality Kingkraft product. We ask you to carefully read through this manual before attempting to use the Rollator. (We reserve the right to make technical alterations at any time)
Page 13 General Information The Kingkraft Rollator (Children’s Walker) is for indoor use only, on smooth or carpeted surfaces, in the home and elsewhere. The rollator is shaped to allow maximum stability and room for the user to walk inside the frame.
Page 14: Handle Options
Rear Wheels: All nuts must be tight and not moving or loose: Handle / Accessory Fittings: All bolts securely tightened on any fitted handles / accessory parts. Cleaning: The rollator should be cleaned as required. Wipe down with a warm mild soapy detergent / solution, wipe off to dry.
Page 15 Please see separate cleaning information.  The rollator should be inspected regularly for any damage or signs of faults by a competent person. Advice is available from Kingkraft Ltd.  The Kingkraft Rollator (Children’s Walker) is intended as a walking aid for young children only of a suitable size.
Page 16 Option 3: Curved Handles These are curved so the ends of the handles blend to the frame. They are intended to be fitted to the main frame at a comfortable height. They can be fitted anywhere along the straight part of the frame. These handles must be fitted as shown and not in any other orientation.
Page 17 Foot operation of the brakes: The castor brake is operated using the black lever at the back of the castor: Brake Lever To ‘lock’ the castors, press the rear lever downwards. To ‘release’ the castors, raise the lever. Warning: The brakes only operate correctly on even surfaces.
Page 18: Care And Maintenance
Handle Options A variety of handle options are available to order Option 1: ‘Doughnut’ Frame Hand Stops These are intended to be used if the main frame is at a comfortable height and width for the user and they want to grip / lean into the rollator, instead of using any additional handles.
Page 19: Cleaning And Tools
The rear wheels prevent the rollator from rolling backwards, unless the rear wheels are lifted off the floor. Do not tip or lift the rollator wheels off the floor at any time when in use. Locking Pin and Folding The rollator can be folded for ease of transportation. The main and rear tubes are connected with a hinged clamp component.
Page 20: Technical Data
The locking pin is captured with the use of a tie so it can not be lost / misplaced. The rollator must not be used if this locking pin is missing. Contact Kingkraft immediately. The rollator loosely folded with locking pin removed:...
