Direct Supply
®
ZERO OPENING
ASSIST DEVICE
Owner's Manual
Please keep and refer to this Owner's Manual.
Thank you for purchasing a Direct Supply
Zero Opening Assist Device from Direct Supply Equipment & Furnishings
.
®
®
Please read this entire guide carefully and keep it for future reference. This guide provides instructions, warnings, warranty
information and other important information about your zero opening assist. Share this information with your housekeeping,
nursing and maintenance staff to help ensure the zero opening assist device is cared for properly.
1-800-634-7328 DirectSupply.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the ZERO OPENING ASSIST and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Direct Supply ZERO OPENING ASSIST

Summary of Contents for Direct Supply ZERO OPENING ASSIST

  • Page 1 Please read this entire guide carefully and keep it for future reference. This guide provides instructions, warnings, warranty information and other important information about your zero opening assist. Share this information with your housekeeping, nursing and maintenance staff to help ensure the zero opening assist device is cared for properly.

  • Page 2: Table Of Contents

    Table of Contents, Description & Intended Use, Capacity Table of Contents Description & Intended Use ....................2 Capacity ..........................2 Warnings ..........................3 Installation ........................4 - 7 Operation ..........................8 Maintenance ........................9 Limited Warranty ......................10 Customer Service ......................11 Description &...

  • Page 3: Warnings

    WARNING: This manual covers the Direct Supply • WARNING: In the event worn or broken parts Zero Opening Assist Device. For warnings and are identified, remove the device from service until instructions related to the bed itself, please see your repairs are made.

  • Page 4: Installation

    1" to 2" by rotating the mounting plate 180 degrees before installation. 16" 18" • Do not use the Direct Supply Zero Opening Assist Device if the slots do not align WARNING: with your bed’s assist device mounting holes.
  • Page 5 3. Determine which direction(s) you want the assist device to pivot (up, right, left). 4. Set the pivot lock by inserting one or two set screws into the pivot lock holes in the back of the assist device mounting plate. See chart below for placement instructions: To pivot to three positions: To pivot to two positions: To use as non-pivoting assist:...
  • Page 6 Installation (cont.) 5. Mount the assist device mounting plate to your bed using the provided bolts, nuts and washers. • Correct order of hardware: Bolt ➔ Assist Device ➔ Bed Deck ➔ Flat Washer ➔ Nut • Using a 19 mm combination wrench or socket wrench and an 8 mm Allen wrench, securely tighten both sets of hardware •...
  • Page 7 7. Before putting the assist device into use, review the installation and overall bed system for functionality and safety: a. Assist device should feel solid and stable. Ensure 50 lbs. of force can be exerted on the assist in any direction without damage or permanent deflection. b.

  • Page 8: Operation

    Operation 1. While pulling handle out, rotate assist device left or right 90 degrees. NOTE: Do not rotate assist device more than 90 degrees. 2. Rotate handle to lock into position. 3. Adjust handle height by removing the release pin or bolt, moving the handle to the desired position, and then reinserting pin or bolt.

  • Page 9: Maintenance

    Maintenance Routine Inspection 1. Review the “WARNINGS” listed in this manual and inspect for compliance. 2. Inspect all components for damage or excessive wear. 3. Visually examine all welds for cracks. 4. Tighten attachment bolts and center pivot screw. 5. Inspect all bolts and fasteners. (Do not overtighten bolts at pivot points.) Cleaning Clean with a mild solution of antiseptic cleaner and warm water.

  • Page 10: Limited Warranty

    Limited Warranty We offer to you, as the original purchaser, a warranty for the Direct Supply Zero Opening Assist. Our warranty applies for the limited warranty period stated below. If any device or device part listed below is defective in material or workmanship during the applicable limited warranty period, we will repair or replace it at our cost.

  • Page 11: Customer Service

    Zero Opening Assist and enjoy outrageous customer service. If you have any questions about the zero opening assist you have purchased or would like to request warranty service, please contact: Direct Supply Equipment & Furnishings at 1-800-634-7328, 7301 West Champions Way, Milwaukee, WI 53223, SalesSupport@DirectSupply.com.
  • Page 12 Distributed by Direct Supply Manufacturing, Inc. 6635 West Champions Way, Milwaukee, WI 53223. © 2020 Direct Supply Manufacturing, Inc. All Rights Reserved. Direct Supply , Panacea , and all associated logos are the registered ® ® trademarks of Direct Supply, Inc., used under license.
