- Page 1 19770 Bahama St Northridge CA 91324 V: 818.898.3380 F: 818.898.3360 sales@dnfcontrols.com MODEL No. SW1X8 RS422 SWITCHER User Manual...
-
Page 3: Table Of Contents
OPERATION WITHOUT GANG FUNCTION .......... 6 OPERATION WITH GANG FUNCTION ..........7 SPECIFICATIONS ................8 FRONT PANEL / REAR VIEW ............11 XII. CONNECTION DIAGRAM..............11 XIII. DNF CONTROLS LIMITED WARRANTY ..........12 Manual Version:…………….……………….. 2.41 051606 Document No. …………..….. SW1X8_User_Manual.doc SW1X8, RS422 Switcher Page... -
Page 4: Revision History
REVISION HISTORY 010604 Rev. 2.2 Company header information revised. Added DNF Controls Limited Warranty. Reformatted. 030804 Rev. 2.3 SPECIFICATIONS section, Rear Panel, 1 External Select: Changed no. of pins from 9 to 25. 081805 Rev. 2.4 Changed description of Tally Outputs. -
Page 5: Introduction
2. Select a Group of VTRs 3. Gang Roll (Common Roll) all 8 VTRs B. 1XN Expansion Port 1. Connects two or more SW1X8 RS422 Switchers to control more than 8 VTRs. 2. Create 1 x 16, 1 x 24, etc. configurations. -
Page 6: Permanent Gang Option
PERMANENT GANG OPTION When the PERMANENT GANG Software option is included in the SW1X8, the following functionality is changed as follows: When a gang is created, it is Permanent (until the operator clears the gang). Example: Gang Outputs [1], [2] and [3]. -
Page 7: Installation
To control more than 8 VTRs from a single controller: A. Follow the instructions in the INSTALLATION section for first 8 VTRs. B. Connect the RS422 INPUT connector on the second SW1X8 to the 1 X N EXPANSION PORT connector on the first SW1X8, using a standard 9-pin RS422 cable, with all 9 pins wired one to one. -
Page 8: Nx8 Expansion Port Installation
B. Using “Y” connectors, connect each VTR to the appropriate OUT connector on every SW1X8. Example: In a 3 x 8 configuration, connect VTR#1 to OUT1 on SW1X8 #1, SW1X8 #2 and SW1X8 #3 C. Connect one end of a standard RS422 cable 9-pin D-type male to male cable with all 9 pins wired one to one into the NX8 Expansion Port on the SW1X8. -
Page 9: Operation With Gang Function
2. The Switch number 1 indicator will blink (it is the default Status VTR). All other switch indicators, 2 through 8, will light. Example: To Gang Roll (Common Roll) VTRs 1 through 8, press GANG. The indicator for each VTR will turn on. SW1X8, RS422 Switcher Page... -
Page 10: Specifications
25-Pin D-Type Female 1 Power Connector 9-Pin D-Type Male C. RS422 Input Connector 9-Pin D-Type Female Pin# Description Frame Ground Transmit A Receive B Transmit Common Spare Receive Common Transmit B Receive A Frame Ground Page SW1X8, RS422 Switcher... - Page 11 OUTPUT 8 ON (Active Low) GROUND G. 1XN Port Function Description When the 1 X N Expansion Line is active, all SW1X8s with the Expansion/Normal jumper set to Expansion will turn off all of its OUTPUTS. SW1X8, RS422 Switcher Page...
- Page 12 When #5 is selected ) ____ panel selector OUT6 tally When #6 is selected ) switch LED. OUT7 tally When #7 is selected ) Low when OUT8 tally When #8 is selected ) LED is ON. Page SW1X8, RS422 Switcher...
-
Page 13: Front Panel / Rear View
FRONT PANEL / REAR VIEW XII. CONNECTION DIAGRAM SW1X8, RS422 Switcher Page... -
Page 14: Dnf Controls Limited Warranty
DNF Controls, at its option, will repair or replace the defective unit. DNF Controls will return the unit prepaid to the customer. The method of shipment is at the discretion of DNF Controls, principally UPS Ground for shipments within the United States of America.
