Page 1 EARTH AUGER HYEA5200X Instruction Manual...
Page 2 USING THE MACHINE. Keep for future reference and pass it on if the machine is loaned or sold to another user. This manual has been produced by Hyundai Power Products and should be kept with the product. Please read and understand these instructions before you use your product. Failure to do this may result in personal injury or damage to the product.
Page 3: Table Of Contents
Contents Features.................4 Maintenance And Care..........25-32 Safety...............25 What’s In The Box............4 Maintenance Schedule........26 Symbols On The Machine..........5 Checking Your Machine........27 Repairs.............27 General Safety............6-16 Cleaning............27 Understand Your Machine.........6 Spark Plug............28 Personal Safety..........6-7 Cleaning & Replacing Air Filter......29 Inspect Your Machine........7-8 Gear Box............29 Engine Safety.............8 Replacing Fuel Filter........30 Work Area............9...
Page 4: Features
Features 1 - Fuel Tank 7 - Left Handle 2 - Right Handle 8 - Handle Bar 3 - Locking Pin 9 - Transmission 4 - Drill 10 - Mixing Tank 5 - Starter Cord 11 - Tools 6 - 2-Stroke Engine What’s In The Box •...
Page 5: Symbols On The Machine
Symbols On The Machine We have provided safety messages in this manual and on the lawnmower. This information alerts you to potential hazards that could hurt you or others. Please read these messages carefully. However, we may not have listed all of the possible hazards, you must also use your own judgment.
Page 6: General Safety
General Safety WARNING : READ THE INSTRUCTION BOOKLET THOROUGHLY BEFORE USING THE MACHINE. Keep for future reference and pass it on if the machine is loaned or sold to another user. Understand Your Machine Personal Safety • WARNING! You must read these •...
Page 7: Inspect Your Machine
General Safety • Always keep hands and feet away from all • The manufacturer’s stipulations concerning pinch points. safety, work and maintenance as well as the measurements specified in Technical Data, • Do not touch parts that might be hot must be complied with.
Page 8: Engine Safety
General Safety • Keep the machine in good operating • Do not tamper with the engine in an effort to condition. Operating a machine in poor or get it to run at higher speeds. The maximum questionable condition could result in serious engine speed is preset by the manufacturer injury.
Page 9: Work Area
General Safety Work Area • Do not work in the rain and when there is a thunderstorm or lightning risk. If there is bad weather conditions, do not use the machine. • Make sure you thoroughly inspect the entire work area and remove all objects and anything •...
Page 10 General Safety • WARNING! If something breaks or an • Always secure bore holes, otherwise there is accident happens whilst working, you must a risk of injury. turn off the engine immediately and move the machine away to prevent further damage. If an •...
Page 11: Remaining Risks
General Safety Remaining Risks Remove the clogged material. Inspect for damage and check for any loose parts for The machine has been built according to the repair or replacement. latest technology and recognised safety rules. However, there is still a chance of residual •...
Page 12: Carbon Monoxide
General Safety by leaving the affected area or by opening Carbon Monoxide doors and windows. If safe and practical to do so make sure that the machine is turned off. DANGER DO NOT enter a room you suspect of having carbon monoxide present –...
Page 13 General Safety have contained fuel. • When refilling or draining the fuel tank, use an approved fuel storage container while in • ALWAYS keep the work area tidy. a clean, well-ventilated outdoor area. While adding fuel or operating the unit, do not •...
Page 14: Electrical Safety
General Safety You must advise the medical staff of the type Electrical Safety of acid. DANGER! • Lead/acid battery = dilute sulphuric acid. ELECTRICITY CAN KILL – NEVER WORK ON LIVE/ENERGISED EQUIPMENT. • Nickel/cadmium = potassium hydroxide alkali electrolyte. • Prior to carrying out any maintenance work you MUST identify electrical isolation methods •...
Page 15: Noise
Intended Use long-lasting impact of shocks are considered factors in the formation of white finger. Note The HYEA5200X is a petrol earth auger from the following to reduce the risk of white finger Hyundai. The HYEA5200X is powered by a and carpal tunnel syndrome;...
Page 16: Personal Protective Equipment
General Safety Personal Protective Equipment Appropriate Personal Protective Equipment (PPE), MUST be worn at all times when operating or repairing the machine. No protective equipment can ensure 100% protection. When selecting PPE, make sure it’s CE marked and it suits the user in terms of size, fit etc. If more than one item of PPE is worn at the same time, make sure they can be used together, e.g wearing safety glasses may disturb the seal of a respirator, causing air leaks.
Page 17: Getting Started
If any part is extreme care and in a well ventilated area. damaged or missing, you must not use the machine. Contact HYUNDAI Power Products NOTE - Images may vary depending on immediately. You must keep the packaging model.
Page 18: Assembly
Assembly Unboxing & Assembly Video: Go to youtube.com and type in Hyundai HYEA5200X assembly. YOU MUST read and understand the instruction manual first. Inserting The Earth Auger STEP 1 Place the motor casing on a work bench. Place the earth auger on the drive shaft, ensuring that both holes are aligned.
Page 19: Preparation
Preparation STEP 3 Mixing 2-Stroke Oil Unscrew the fuel tank cap and carefully add Fuel Type : Use fresh unleaded petrol the fuel / 2-stroke oil mixture as in the step mixed 40:1 with semi-synthetic 2-stroke above. Only pour the fuel mixture into the fuel oil or aspen2 pre-mixed fuel.
Page 20: Starting Procedure
Starting Procedure CAUTION - For OUTDOOR use ONLY. CAUTION Petrol machines produce carbon monoxide – a poisonous, colourless and odourless gas that • Always start slowly with half throttle and can cause serious injury or death. Petrol is keep a firm grip on both handles of the auger highly flammable, always handle with extreme at all times.
Page 21 Starting Procedure STEP 2 CAUTION - Do not pull out the starter cord more than approx. 50cm, and let it recoil slowly by hand. For efficient starting, it is important to pull the starter cable quickly and powerfully. STEP 5 2Prime the fuel pump (B) by pressing primer bulb several times until you can see fuel in the bulb and pipes.
Page 22: Stopping Procedure
Stopping Procedure CAUTION - The engine and exhaust will remain hot for a while after use. Ensure the engine and exhaust has cooled before carrying out any maintenance, refuelling or storage. After Each Use • Examine the machine for damage. •...
Page 23: Troubleshooting
Troubleshooting Problem Possible Cause Possible Solution Starting difficulty - no spark 1. Carbon deposit between 1. Clean the spark plug. electrodes of the spark plug. Adjust the gap to 2. Defective ignition coil, 0.6~0.7mm. Replace the flywheel magneto too weak. spark plug.
Page 24: Specifications
Specifications NOTE - All machines are tested and inspected so there may be some residual oil left in the machine so please fill with caution. Model HYEA5200X Engine Type 2-Stroke Air-Cooled Engine Size 51.7cc Max. Engine Power At 9600rpm 1.45kW / 2hp Max.
Page 25: Maintenance And Care
Maintenance & Care Maintenance Safety IMPORTANT - Routine and accurate All protective and safety equipment must maintenance is essential for maintaining be re-attached immediately after original machine safety and performance completing repairs and maintenance. The levels. machine’s safety devices must not be removed or made unstable.
Page 26: Maintenance Schedule
Maintenance & Care Maintenance Schedule Before Each After Each After 20 After 100 After 300 Hours Hours Hours Check Machine. See page 27. Air Filter. Clean Replace* See page 29. Spark Plug. Check Replace See page 28. Fuel Filter. See page 30. Gear Box.
Page 27: Checking Your Machine
Maintenance & Care Checking Your Machine Cleaning CAUTION - DO NOT use a hose pipe or When checking your machine, we recommend you : pressure washer to clean the engine. Water can damage the engine or contaminate the • Check for worn or damaged parts. fuel system.
Page 28: Spark Plug
Maintenance & Care The Spark Plug STEP 6 The spark plug gap should be 0.70mm to 0.80mm. Check the gap by using a feeler STEP 1 gauge. Adjust as necessary by carefully You MUST allow the engine to cool down bending the side electrode to achieve the before carrying out any maintenance.
Page 29: Cleaning & Replacing Air Filter
Maintenance & Care Air Filter STEP 3 CAUTION - A dirty air filter will restrict the air flow to the carburettor, which will reduce engine efficiency. When using the earth auger in very dusty areas you must clean or replace the air filter more often.
Page 30: Replacing Fuel Filter
Maintenance & Care Replacing Fuel Filter Storage The fuel filter can become clogged. It is CAUTION - When storing the machine, recommended to replace the fuel filter once make sure it has been cleaned properly. See every 100 hours in order to ensure sufficient cleaning section.
Page 31: After Storage
Maintenance & Care 8. Once all work above is carried out store the After Storage machine in a clean, cool and dry place away from sources of ignition and varying changes 1. Remove spark plug in temperature. DO NOT store a machine that has not been given time to fully 2.
Page 32: Recycling And Disposal
Maintenance & Care Recycling And Disposal This symbol means you should ‘Reduce - Reuse - Recycle’ We do not offer a takeback scheme for the recovery of We are a Member of the VALPAK Waste Electrical Electronic National Compliance Scheme and our Equipment (WEEE) &...
Page 33: Spare Parts
Spare Parts Only use original spare parts: The use of non-original and/or incorrectly fitted parts will jeopardize the safety of the machine, may cause accidents or personal injuries for which the Manufacturer is under no circumstance liable or responsible. Part Part Number Spark Plug HYEA5200XSPARKPLUG...
Page 34: Our Product Range
Our Product Range Generators Mini Dumpers Leisure Inverter, Petrol, Diesel And Built-In 4-Wheel Drive Mini Dumper / Power Barrow Motorhome Generators Yard Sweeper Pressure Washers Self Propelled Yard Sweeper Power Brush Petrol, Diesel And Electric Pressure Washers Water Pumps Scarifiers Submersible, Clean And Dirty Water And Petrol Lawn Scarifier And Aerator Professional Chemical Water Pumps...
Page 35: Useful Information
Go to www.hyundaisupport.co.uk or search ‘Hyundai Power Products’ in YouTube. Warranty Proof of purchase will be required before you make a warranty claim. Full warranty terms and conditions can be found on the HYUNDAI POWER PRODUCTS website: www.hyundaipowerproducts.co.uk Manual Updates Our manuals are constantly being reviewed and updated.
Page 36: Notes
Notes...
Page 37 Notes...
Page 38: Contact Us
Need Help? Talk To Our Experts Contact Us Our friendly aftersales team will be more than happy to help you. Phone Call our team on 01646 687880, open Monday-Friday 8.30am-5pm. Email aftersales@hyundaipowerproducts.co.uk Online Live Chat Go to www.hyundaipowerproducts.co.uk Live chat is open Monday-Friday from 8.30am-5pm. Post Genpower Limited, Isaac Way, Pembroke Dock, Pembrokeshire, SA72 4RW, UK.
Page 39: Declaration Of Conformity
51.7cc 106.28dB(A) 107dB(A) 1.45kW Product Details: Brand: Hyundai Model: HYEA5200X Description: Petrol Earth Auger Name and address of technical documentation holder and EU distributor: Genpower Ltd, Isaac Way, Pembroke Dock, Pembrokeshire, SA72 4RW, UK. Signed by: Roland Llewellin, Managing Director...
Page 40 Importer: GENPOWER LTD Isaac Way, London Road, Pembroke Dock, UNITED KINGDOM, SA72 4RW T: +44 (0) 1646 687 880 F: +44 (0) 1646 686 198 E: info@hyundaipowerproducts.co.uk www.hyundaipowerproducts.co.uk Imported/Distributed by Genpower Ltd for The United Kingdom & Ireland Licensed by Hyundai Corporation, Korea...
