Eurotops 46317 Instructions

Instruction / Anleitung / Instructions / Instructies
Item No. 46317 Telescopic tripod
Note: Read the instruction manual carefully before using the device and keep it for future reference.
The device is for personal use only and is to be used as described.

FEATURES:

• Quick-disconnect baseplate
• Easy-to-locate Rotational/Elevation Dial Lock
• Quick Height Adjustment with center post
• Finite Leveling with solid cam leg clamps and leveling indicators

PRODUCT SPECIFICATIONS:

Maximum Operating Height： 52 in. / Minimum Operating Height： 18.9 in.
Folded Height： 20 in. / Net Weight： 2.3 lbs. / Maximum Load Capacity： 6.6 lbs.

MOUNTING YOUR OPTIC TO THE TRIPOD

The Pursuit Tripod is designed with a quick-disconnect baseplate for ease of mounting to spotting
scope,binoculars or camera and quick setup/takedown in the field.

ADJUSTING THE HEIGHT AND LEVELING

The height can be adjusted 3 ways：
1. Adjusting the tripod legs using the leg clamps and checking for leveling.
2. Angular adjustment of the legs.
3. For finite elevation changes after leveling, you can adjust the elevation lock to move the center
post up/down.

FINITE ADJUSTMENTS FOR PRECISE VIEWING

4. To make adjustments and lock-in your desired location, you can twist the tripod
rotation/elevation dial counterclockwise to loosen the connection which allows you to tilt the
optics up/down or rotate. To secure the connection, tighten the knob clockwise to retighten.
ATTENTION!!!
The returns will be impossible if products were damaged because of incorrect use.
DISPOSAL：
The packaging material is reusable. Dispose of the packaging in an environmentally friendly way by putting it in
the appropriate recyclable waste collection containers.
Eurotops Versand GmbH
Elisabeth-Selbert-Straße 3
40764 Langenfeld, Germany
If technical support is needed, please call ...
in Germany 0180 . 530 63 63* or info@eurotops.de
