- Page 1 1 DATECS LineaPro 7 UHF User Manual...
- Page 2 LEGAL NOTICE THE INFORMATION IN THIS DOCUMENT CANNOT BE REPRODUCED IN ANY MECHANICAL, ELECTRICAL OR ELECTRONIC WAY AND UNDER ANY CIRCUMSTANCES WITHOUT THE WRITTEN CONSENT FROM DATECS LTD. Address: 4 Datecs Street, Sofia 1592, Bulgaria Phone: +359 2 816 55 50 Fax: +359 2 816 55 65 E-mail: export@datecs.bg...
- Page 3 1 DATECS LINEAPRO 7 UHF USER MANUAL REVISION HISTORY Version Data Change description 1.0.0 07.04.2020 First Release Added notice in section “GETTING STARTED” while is using RF 1.1.0 28.05.2020 function UM 07.01.18/v1.1.0...
-
Page 4: Table Of Contents
TECHNICAL SPECIFICATIONS ..............................6 GENERAL VIEW ..................................9 GETTING STARTED ................................. 11 ..............................12 ATTERY INDICATIONS ATTACHING APPLE DEVICE TO LINEAPRO 7 UHF ........................13 OPERATION MODES ................................14 ................................14 CANNING BARCODES HF C ............................. 15 ONTACTLESS CARDS READING UHF C .......................... -
Page 5: Regulatory
2. This device must accept any interference received, including interference that may cause undesired operation. Any change or modification to the product not expressly approved by Datecs Ltd could void the user's authority to operate the device. This device complies with portable RF exposure requirements in accordance with FCC rule part 2.1093 and KDB 447498 D01 UM 07.01.18/v1.1.0... -
Page 6: Technical Specifications
1 DATECS LINEAPRO 7 UHF USER MANUAL TECHNICAL SPECIFICATIONS Two Scan buttons Keyboard and Buttons Battery status button Reset device button Supports: ISO/IEC 14443 Type-A/MIFARE - MIFARE MINI - MIFARE CLASSIC-1K, MIFARE CLASSIC-4K - MIFARE ULTRALIGHT, ULTRALIGHT-C - MIFARE PLUS 2K/4K... - Page 7 1 DATECS LINEAPRO 7 UHF USER MANUAL Composite codes, Data Matrix (ECC200), Passport MRZ (OCR-B), Maxi Code (mode 2~5), MicroPDF417, Micro QR Code, PDF417, QR code Apple 9 pin connector Connectivity Pass-through sync through USB type-C SAM card holder (Optional)
- Page 8 1 DATECS LINEAPRO 7 UHF USER MANUAL Use only original equipped DATECS cable USB-A to USB-C (Z05C000000-05) for charging Apple device. Use only UL approved USB adapters. The minimum requirements of USB adapter is 5V/2.1A! Waste Electrical & Electronic Equipment...
-
Page 9: General View
1 DATECS LINEAPRO 7 UHF USER MANUAL GENERAL VIEW UM 07.01.18/v1.1.0... - Page 10 1 DATECS LINEAPRO 7 UHF USER MANUAL 1. Barcode engine 7. Volume buttons of Apple device 2. On/Off button of Apple device 8. Back Cover 3. Left and Right scan buttons 9. RFID HF Reader 4. USB type-C connector 10. Battery status button and LED indication 5.
-
Page 11: Getting Started
USER MANUAL GETTING STARTED LineaPro 7 UHF has rechargeable Li-ion battery. Can be charge from USB port or Charging pads. Before first use, battery must be fully charged. If the device is fully discharged, charging time to fully charged would be approx. -
Page 12: Battery Led Indications
1 DATECS LINEAPRO 7 UHF USER MANUAL Battery LED indications For checking battery level, can be pressed status button. LED 1 is lights – battery level is between 1 -25% LED 1 and 2 LED are light – battery level is between 26 - 50% LED 1, LED2 and LED3 are light –... -
Page 13: Attaching Apple Device To Lineapro 7 Uhf
1 DATECS LINEAPRO 7 UHF USER MANUAL ATTACHING APPLE DEVICE TO LINEAPRO 7 UHF Take LineaPro 7 UHF and lift the back cover, insert the iPhone 7 and close the back cover as shown on picture below: UM 07.01.18/v1.1.0... -
Page 14: Operation Modes
For turn On LineaPro 7 UHF press one of the scan buttons and unlock Apple device screen. Scanning barcodes LineaPro 7 UHF can scan 1D and 2D barcodes. To scan barcode first, activate the scanner (by pressing and holding the scan button). Then position the scanning engine to the center of the barcode by aiming and the illumination box is over the outer edges of the barcode, as shown on the picture below. -
Page 15: Hf Contactless Cards Reading
USER MANUAL HF Contactless cards reading The LineaPro 7 UHF has a contactless card reader. Contactless card reader is located on the bottom side. Contactless card must be placed there (showed on the picture below). For list of supported standards, please refer to sections “TECHNICAL SPECIFICATIONS”. -
Page 16: Transferring Data Between Apple Device And Pc Or Mac
- 500mA (Default) - 1000mA LineaPro 7 UHF can charge Apple device from his own battery. Only is need to be activated function “Automated Charge”, to be start charging battery level of LineaPro 7 UHF must be above 20%. Updating Firmware Firmware of LineaPro 7 UHF can be update with newer version. -
Page 17: Care, Maintenance And Warranty
FCC RF Exposure Information and Statement the SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types: LineaPro 7 UHF has also been tested against this SAR limit. This device was tested for typical body-worn operations with the back of the device kept 10mm from the body.
