Enttec PHERO 30 White Manual

Back Panel

Box Contents

ENTTEC PHERO 30 White (73905 or 79006)

Mounting brackets

This user manual


Features

30 independently controllable WHITEx3 Pixels

2700K, 4000K and 6500K High CRI leds

Can produce any combination of the 3 white

colour temperatures per pixel
Flexible, light and slick design

In-built Power Supply

Compatible with Pixelator family and Pixie driver

Plink data bus allows to daisy-chain up to 11 units

Standard Cat6 wiring allows up to 300m distances

Mains power through Powercon connectors for

convenient installation
50,000+ hours expected LED life

Up to 90 DMX channels through Pixelator

Over voltage input protection

1

Safety

Mains voltages inside, please never intend to open it

when mains connected
Do not expose the ENTTEC Phero to rain or moisture,

doing this will void the warranty
Do not remove the cover, there are no serviceable

parts inside
This unit is intended for indoor use only

Ensure proper earth connections


Basic Setup

Connect the ENTTEC Phero to a Plink enabled device

such as ENTTEC Pixelator using a cat5/6 cable
Power up the unit using the blue powercon

connector. The power LED should light up
Feed some data through your Plink enabled device

Phero 30 W Manual
50878
For latest version visit:
www.enttec.com
ID: 568660
