This manual elaborates on installation and safety use information for PV power generating
modules (hereinafter referred to as module) of DualSun SAS (hereinafter referred to as
DualSun). Please abide by all safety precautions in this guide and local regulations.
Installation of modules requires professional skills and knowledge and is to be carried out
by qualified personnel. Please read this manual carefully before installing and using this
module. Installation personnel shall get familiar with mechanical and electrical requirements
of this system. Please keep this manual properly as reference for future maintenance or
upkeep or for sales and treatment of modules.
If you have any doubts, please contact DualSun global quality and customer service
department for further interpretation.
Installation Manual for DualSun
PV Modules
Regular Photovoltaic Modules
DualSun xxxM-60-0BBP
Safety Notes
1 / 17
Installation Manual for DualSun PV Modules
Advertisement
Table of Contents
Summary of Contents for DUALSUN M-60-0BBP Series
- Page 1 Please keep this manual properly as reference for future maintenance or upkeep or for sales and treatment of modules. If you have any doubts, please contact DualSun global quality and customer service department for further interpretation.
-
Page 2: Table Of Contents
The third party grounding devices ....................16 Operation and maintenance ........................16 Cleaning .............................. 16 Module appearance inspection ....................... 17 Inspection of connectors and cables ....................17 The list of the modification ......................17 2 / 17 Installation Manual for DualSun PV Modules... -
Page 3: Introduction
If patent rights or the third party rights are infringed by use of modules, DualSun will not take any responsibility. DualSun reserves the rights for modifying product manual or installation manual without notice in advance. -
Page 4: Regular Safety
Figure 1Module Section Structure and Components Regular safety DualSun module is considered to be in compliance with IEC61730 only when the module is mounted in the manner specified by the mounting instructions below. When the module is installed on roof, it is necessary to take the overall fire rating of the finished structure as well as later overall maintenance into account. -
Page 5: Electric Performance Safety
Electric performance safety The application level of DualSun module is Application Class A , w hich can be used in systems operating at greater than 50 V DC or 240 W, where general contact access is anticipated; In case of no connected load or external circuits, modules can also produce voltage. Please use insulation tools and wear rubber gloves when operating modules in the sunlight. -
Page 6: Fire Safety
Please consult local laws and regulations before installing modules and abide by requirements on building fire protection. Fire rating of DualSun modules is Class C according to IEC 61730-2. The roof shall be coated with a layer of fireproof materials of such rating for roofing installation and make sure that the back plate and the mounting surface are fully ventilated. -
Page 7: Selection Of Tilt Angles
PV module installer. DualSun suggests that module installation tilt angle be no less than 10° so module surface dust can be washed away easily by rainfall and times of cleaning can be reduced. And it is easy for ponding to flow away and avoid water print on the glass due to long time of water ponding which may further affect module appearance and performance. -
Page 8: Way Of Installation
Make sure that back plate of modules will not contact bracket into the module or building structures, especially when the module surface is imposed by pressure. DualSun Modules have been certified for a maximum design static load on the back of the Modules of up to33.4 lb/ft (i.e. - Page 9 Make sure that the clamp will not produce shading effect. Drain holes can not be sheltered by the clamp. Clamp B At least 2 Clamp A At least 2 Bracket PV module Clamp B Clamp A Mounting rack 9 / 17 Installation Manual for DualSun PV Modules...
- Page 10 The modules have been evaluated by TUV according to IEC61215 for a maximum testing loadof below112.78lb / ft2 (+5400Pa,-2400pa)------- design load(+3600pa,-1600pa)*1.5; Frame Way of Installation ML（≤） ounting hole ﹢5400pa Use 4 Mounting -2400pa holes(outside) 10 / 17 Installation Manual for DualSun PV Modules...
-
Page 11: Electric Installation
If modules are connected in series, the total voltage is equal to the sum of individual voltages. The recommended max. N= System voltage / (1.25*Voc) Where No modules in series 11 / 17 Installation Manual for DualSun PV Modules... - Page 12 2, there shall be an overcurrent protection device on each strand of module. See Figure 5. 12 / 17 Installation Manual for DualSun PV Modules...
-
Page 13: Cables And Connecting Lines
Bypass diode DualSun module connecting box contains bypass diode which is in parallel connection with the cell strands. If heat spot occurs locally with the module, the diode will come into operation to stop the main current from flowing through the heat spot cells with the view to restrain module heating... -
Page 14: Grounding
If the diode is found or doubted to get out of order, the installer or system maintenance supplier shall contact DualSun. Please do not try to open the module connecting box on your own. Currently, DualSun modules are equipped with bypass diodes in the junction box. The diode type is 20SQ045（for SUNTER, Rated current is 15A, peak reverse voltage is45V）;... -
Page 15: Grounding By Unoccupied Mounting Holes
3. Put grounding lines through the grounding clamp and grounding wire material and dimension shall meet requirements in local national and regional law and regulations. 4. Fasten bolts of grounding lines and installation ends. 15 / 17 Installation Manual for DualSun PV Modules... -
Page 16: The Third Party Grounding Devices
Figure 7 Way of Installation The third party grounding devices The third party grounding device can be used for grounding of DualSun modules but such grounding shall be proved to be reliable. Grounding device shall be operated in line with stipulations of the manufacturer. -
Page 17: Module Appearance Inspection
Max. power (tolerance 0,+5) [W]: Maximum system voltage [V] 1000 1000 1000 1000 Series Fuse Rating [A] DualSun SAS Address: 2 rue Marc Donadille 13013 Marseille France TEL: +33 4 13 41 53 71 17 / 17 Installation Manual for DualSun PV Modules...
