ARE K1 / RS232 Transponderreader for trovanTM transponders for Industrial Applications... -
Page 2: Table Of Contents
TRANSPONDERREADER FOR TROVANTM TRANSPONDERS FOR INDUSTRIAL APPLICATIONS INTRODUCTION TECHNICAL DATA Mechanical characteristics Outline dimensions PCB of the ARE K1 Connection characteristics of the digital inputs Connection characteristics of the relay outputs Pin configuration of the RS 232 interface Antenna cable Pin Configuration of the terminal blocks (for antenna, power lines, etc.) DIP-Switches 2.10... - Page 3 NOTIFICATION OF CHANGES --------------------------------------------------------------------------------3/13--------------------------------------------------------------------------------...
-
Page 4: Introduction
Introduction The reader is designed to read trovan transponders. It is a robust device for industrial applications. It is es- pecially suited for large reading ranges. The adaption to the individual needs can be performed by selection of the most optimal antenna. The wide range of applications for this device includes for example: Production control in car assembly and paint shop, barrel logistics, bin identification, skilift management, etc. -
Page 5: Outline Dimensions
Outline dimensions --------------------------------------------------------------------------------5/13--------------------------------------------------------------------------------... -
Page 6: Pcb Of The Are K1
PCB of the ARE K1 Input power: 24 V(18..30V) Average input current (active antenna AAN FK2 included): 1 A max Stanby input current (antenna not active) 0,07 A PC interface: 2 wire RS 232 Fuse: 1,6 A/250 V inert Number of Inputs (galvanic disconnected): Number of Outputs: Reading time: 50ms using default settings... - Page 7 data shielding of data sync ground make contact of relay QN1 relay QN1 break contact of relay make contact of relay QR1 relay QR1 break contact of relay shielding ground digital input + digital input ground pin configuration of the PCB --------------------------------------------------------------------------------7/13--------------------------------------------------------------------------------...
-
Page 8: Pin Configuration Of The Terminal Blocks (For Antenna, Power Lines, Etc.)
Pin Configuration of the terminal blocks (for antenna, power lines, etc.) a) using LiY-LiYCY-Y 2+2x0,5 (delivered until march 2001) b) using Li2YCY (TP) 3x2x0,34 (delivered from march 2001) data white shield brown sync grey pink green yellow shield Data white Schirm shield of white Sync... -
Page 9: Firmware
Firmware The reader supports ASB (AEG ID standard set of instructions). When delivered the reader´s configuration is set into the operation mode 2 (readings triggered by serial interface). The reader can be set to the operation mode 0 (continuous operation) or to the operation mode 1 (triggered by external input). -
Page 10: Putting Into Operation
Putting into operation Putting into operation for the first time a) Connect the device to a 24 V DC source which is able to provide a minimum of 1 A. Connect the antenna with the device. Connect a Personal Computer or equivalent to the device via the RS 232 interface. Please assure the interface is set to the right baud rate. -
Page 11: Antennas
Warnings and cautions When using the original AEG ID antennas suited for that device, the combination of antenna and reader have the German permission for operation. Please check, if special permissions are required at the place of opera- tion. -
Page 12: Fcc Information
FCC Information Name of Grantee AEG Identifiaktionssysteme GmbH Equipment Class Part 15 Low Power Transmitter Notes RFID Reader FCC Rule Parts FCC IDENTIFIER Frequency Range Model ID No. V7IAREK1-1 0.124 – 0.124 MHz ARE K1 - RS232 9292 Federal Communications Commissions (FCC) Statement 15.21 You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. - Page 13 Copying of this document and giving it to others and the use or communication of the contents thereof, are forbidden without express authority. Offender are liable to the payment of damages. All rights are reserved in the event of the grant of a patent or the registration of a autility modul or design.
