Specifications / Features - CommTech FASTCOM IG232/2-PCI Hardware Reference Manual

4
SPECIFICATIONS:
UART
BAUD RANGE
BUFFERING
INTERFACE
BUS
POWER
REQUIREMENTS:
ADDRESS
REQUIREMENTS:
INTERRUPT
REQUIREMENTS:
FEATURES:
Isolation
Designed to comply with VDE isolation requirements
3000 Volt Opto Isolator breakdown
3700 Volt transformer breakdown
Both channels are fully isolated from each other
High performance 16C850 UARTS
Standard on the Fastcom: IG232/2-PCI, no extra charge
All standard PC baud rates up to 115.2 Kbps
128 byte FIFOs for improved through-put
User programmable baud rate
Comprehensive Hardware and Software Documentation
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
16C850
All standard PC baud rates up to 115.2 Kbps
Transmit - 128 bytes
Receive - 128 bytes
RS-232C
TXD, RXD, RTS, CTS
PCI
+5 600mA (Typical)
PCI Controller 128 bytes
UARTs 16 bytes
Control Registers 4 bytes
1 (per board)
