- Page 1 ® MVT MVT GPS Vehicle Tracker GPS Vehicle Tracker User Guide V 1.0 Copyright © 2012 Qube Inc. All rights reserved. Page...
-
Page 2: Table Of Contents
2. Product Function and Specifications ..................... < 3 > 2.1 Product Function ........................ < 3 > 2.2 Specifications ........................< 4 > 3. Qube GPS Tracker and Accessories ....................< 5 > 4. View .............................. < 5 > 5. Before Using .............................< 5 >... -
Page 3: Applications
Low Battery Alarm o Report when backup battery’s voltage is below 3.5V. Speeding Alarm o Report when Qube GPS Tracker speeds higher than the pre-set values. Impact Alarm o Alarm when Qube GPS Tracker detects impact or crash. Tow Alarm o Alarm when the tracker trembles for a period of time. -
Page 4: Specifications
Latest GPS SIRF-Star III chipset GPS Sensitivity -159dB Positioning 10 meters, 2D RMS Accuracy 5 Digital Input ( 2 positive triggering and 3 negative triggering) 2 Analog Input Detection 5 Output 1 USB port Copyright © 2012 Qube Inc. All rights reserved. Page... -
Page 5: Qube Gps Tracker And Accessories
PCB. connectors on PCB. Replace the cover and screw it in. Replace the cover and screw it in. Copyright © 2012 Qube Inc. All rights reserved. Page... -
Page 6: Charging
Qube GPS Tracker is connected to the GSM network Flashing/Blinking (1 second on and 2 seconds off) Flashing/Blinking (1 second on and 2 seconds off) Qube GPS Tracker Unit is not connected to the GSM Qube GPS Tracker Unit is not connected to the GSM network Copyright ©... -
Page 7: Track By Calling
5.4 Track by Calling Make a call to Qube GPS Tracker, drop after 1-2 rings, wait for SMS reply, be sure your SIM card has not run out of credit. Example of SMS Reply: Now, 120620 15:25,A,23,40Km/h,56%, http://maps.google.com/maps?f=q&hl=en&q=14.612531,121.033403 &ie=UTF8&z=16&z=16&iwloc=addr&om=1 Content... -
Page 8: Installation
10 Bits Resolution Analog Inputs. 0~6V DC Detection. It can be used to connect with temperature/fuel sensor etc. 15(GND) Black Ground. It can be used to connect with temperature/fuel sensor etc. 16(POWER) DC In (power source). Input voltage: 9V~36V. 12V suggested. Same as PIN8 Copyright © 2012 Qube Inc. All rights reserved. Page... -
Page 9: Power/Gnd (Pin7/Pin8)
Digital Input (PIN1/PIN2/PIN3 Negative Triggering) Digital Input (PIN1/PIN2/PIN3 Negative Triggering) QUBE 6.1.3 Digital Input (PIN4/PIN5 Positive Triggering) Digital Input (PIN4/PIN5 Positive Triggering) Qube 6.1.4 Output (PIN9/PIN10/PIN11/PIN12/PIN13) Output (PIN9/PIN10/PIN11/PIN12/PIN13) Qube Copyright © 2012 Qube Inc. All rights reserved. 2012 Qube Inc. All rights reserved. Page... -
Page 10: Install Gps/Gsm Antenna
Qube 6.4 Mount the Qube GPS Vehicle Tracker unit If mounting required, there are 4 screw holes on the Qube GPS Tracker, 2 along either side that act as fixing points to the vehicle. For More information and other features...
