Hardstone HS B-PE02 Manual

Multimedia gps interface for citroen c3/c6, peugeot 308/3008/4008
Hide thumbs
1
2
3
4

Advertisement

Quick Links

Download this manual
HS B-PE02 - Multimedia GPS Interface
Manuale dÕInstallazione
HS B-PE02
CITROEN C3/C6
PEUGEOT 308/3008/4008
Interfaccia Video GPS Sistema originale
con schermo capacitivo da 7"- 8" Canbus
Distribuito da:
Ingresso Retrocamera con IPAS - 3 AV
HARDSTONE ITALIA - MILANO ITALY
USB Audio-Video 1080P - Touchscreen
Web: www.hardstone.it - Email: info@hsaudio.com
Leggere attentamente il manuale prima di installare lÕ unitˆ. La non osservanza
8
di tali regole comporta la decadenza della garanzia.

Advertisement

loading
Need help?

Need help?

Do you have a question about the HS B-PE02 and is the answer not in the manual?

Questions and answers

Related Manuals for Hardstone HS B-PE02

Summary of Contents for Hardstone HS B-PE02

  • Page 1 HS B-PE02 - Multimedia GPS Interface Manuale dÕInstallazione HS B-PE02 CITROEN C3/C6 PEUGEOT 308/3008/4008 Interfaccia Video GPS Sistema originale con schermo capacitivo da 7"- 8" Canbus Distribuito da: Ingresso Retrocamera con IPAS - 3 AV HARDSTONE ITALIA - MILANO ITALY USB Audio-Video 1080P - Touchscreen Web: www.hardstone.it - Email: info@hsaudio.com Leggere attentamente il manuale prima di installare lÕ unitˆ. La non osservanza di tali regole comporta la decadenza della garanzia.
  • Page 2 HS B-PE02 - Multimedia GPS Interface ————————————————————————————————————————————————————————— 1 .Applicable car model as below: Car Model: PEUGEOT/Citroen (308,4008,C6) Year: 2016.10-2017 Original System: PEUGEOT/Citroen with capacitor touch monitor, 308 7" monitor, 4008/C6 8" monitor 2 .How to Install the interface Noted ：please detach the parts cautiously for avoiding original accessories in damage. 7.
  • Page 3 HS B-PE02 - Multimedia GPS Interface 4. DIP Switch Description “1”UP “2” UP for 7inch monitor “1” UP “2” Down for 8inch monitor 5. Product connector description 12 .Put the video interface module in a proper place 13. Enter the original radio interface to set AUX 14.
