Huaxin 2020X700MG User Manual

Robotic vacuum cleaner
Hide thumbs

Advertisement

Quick Links

Download this manual
ROBOTIC VACUUM CLEANER
USER MANUAL
(Before using this product,please read the safety instructions below and follow all the routine safety precautions)

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2020X700MG and is the answer not in the manual?

Questions and answers

Summary of Contents for Huaxin 2020X700MG

  • Page 1 ROBOTIC VACUUM CLEANER USER MANUAL (Before using this product,please read the safety instructions below and follow all the routine safety precautions)

  • Page 2: Fcc Warning

    FCC warning: Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 4 Wi-Fi Setup Instructions To perfefct the products, we keep the right of updating the APP and the software. The final interface is subject to the actual products, thank you.
  • Page 5 Wi-Fi Setup Instructions To perfefct the products, we keep the right of updating the APP and the software. The final interface is subject to the actual products, thank you.
  • Page 6 Before using this product,please read the safety instructions below and follow all the routine safety precautions. Please read the instructions carefully and keep them for future reference. Any operation that does not conform to the instructions may cause damage to the product. Safety considerations of Main Body and Accessories Warning 01.Do not disassemble,repair or refit the product without authorization;otherwise it may damage...
  • Page 7 09.Before using the product,please remove all vulerable items on the floor,such as glass, lamps,and items such as wires and curtains that may entangle with the side brush and suction passages. 10.When the dust box is full,please empty it before using again. 11.Please do not use the robot to clean the construction waste.
  • Page 8 Warning 01. When skin or clothing is exposed to the battery electrolyte,immediately wash with clean water to avoid inflammation of skin,etc. 02. Do not use the rechargeable battery on other devices.This battery is only suitable for this robot. 03. If the battery’s outer box is found to be deformed and expanded,or leakage of electrolytes is found, do not charge or continue to use to avoid danger.

  • Page 9: Name Of Parts

    3.1Name of Parts Main Body Charging Base 2XAAA batteries Remote Controller Power Adapter High-efficient Filter Side Brushes Accessories of some models may be slightly different and they are subject to the actual received products.
  • Page 10 Main Body 1.Bumper 2.Control Button 3.WIFI Indicator 4.Laser Components Main Body 1.Universal Wheel 2.Electrode Slice 3.Side Brush 4. Battery Cover 5. Side Wheel 6.Suction Port 7.Dust box...
  • Page 11 Main Body 1.Power Switch 2.Dust box/Water tank release botton Dust Box 1. Pre-filter 2.High-efficient filter 3.Filter sponge 4.Dust Box 5. Dust box cover...
  • Page 12 Charging base...

  • Page 13: Process Parameters

    3.2 Product Specification Structure Diameter of the main body 345mm Thickness of the main body 102mm Net weigh of the main body 3.5kg Electronic Voltage 14.4V Battery capacity 5200mAh Main body button type LED button Accessory Dust box capacity 450ml Process Parameters Charging Type Manual/Automatic...
  • Page 14 3.3 Product Characteristics Multiple smart cleaning modes 4 cleaning modes are designed to suit different needs, which can be switched by the remote controller and App, greatly improves the cleaning efficiency and saves 30% of the power. Humanized design It is simple to operate, pressing the Control Button to start cleaning. Follow the Voice Prompt and let the robot start working for you.
  • Page 15 4.1 Attention When it is working, please help to remove the unfriendly obstacles. Put the furniture and home appliances such as tables and chairs in the house neatly, the robot will clean up smoothly to give you a clean new home. If the robot works at the stairway, the edge of the step, or the entrance to the narrow area among the furniture, etc, please place a fence to ensure it is safe and running smoothly.
  • Page 16 Please do not stand in narrow places such as thresholds and aisles to avoid missing sweeping. When the robot is working, please ensure that the object with the thickness less than 1.8 cm is not placed in the cleaning area to prevent the machine from climbing and jamming.

  • Page 17: Remote Controller Instruction

    4.2 Remote controller instruction Power On/Off Display Screen Plan Cleaning Return for Auto Charging (Smart Cleaning) Confirm Direction Clock Setting Suction Setting Schedule Setting Spot cleaning When the robot is in the vicinity of the charging base and the virtual protection wall, it may not be able to distinguish the instructions issued by the remote controller.
  • Page 18 Back Button /- Press this button and robot will rotate 180 degrees in situ. In the modes of Schedule Setting and Clock Setting, press this button will decrease the number. Left Arrow At the standby mode, press this button to continue turning left, and release it to return to standby mode.
  • Page 19 4.3 Operating Instructions Placement of the Charging Base Place the charging base against the wall,leaving the safety distance left and right each 1 meter and front 2 meters. Warning: don’t put it close to the mirror ,avoid direct sunlight. Switch on the robot, then the Control button will turn on the white light, and enter the Selected mode.
  • Page 20 Charging modes Press Return for Auto charging button on the remote controller or Press Recharge icon on App to auto dock the Robot with the charging base. Automatic Recharge This product conforms to European ERP energy consumption standard When Cleaning is completed or the battery is too low,the robot will automatically start finding the charging base to charge itself.
  • Page 21 Charging instruction 01. For the very first operation, please let the robot run out of power. 02. Please charge the robot for 12 hours for the first time of operation. When the charge is done, the Control button light turns off. 03.
  • Page 22 Pause The pause function is to switch the robot from the operating mode to the selected mode, and the robot can be paused by the following operations: 01.Press the “ ” button on the robot to pause the robot. 02.Press the power on/off button on the remote controller to pause the robot. Notice: After the machine is paused, the machine can be re-operated.
  • Page 23 Schedule Cleaning You can set the current local time on your robot by pressing the Clock Setting ☆ Once the power switch is turned off, all schedule will be canceled. ☆ Once the schedule setting is succeeded,the robot will start working at the scheduled time everyday Press the"Schedule Setting"...
  • Page 24 ☆ At the Schedule Setting mode,follow the voice prompts to confirm all your operations. 1.Press the Schedule Setting button to enter the Schedule Setting mode and set the schedule on the remote controller or APP. 2.If you need cancel the schedule,just press the Schedule Setting button for 3 seconds.
  • Page 25 Cleaning Modes Plan Cleaning ( S shape Cleaning ) The robot will perform the plan will clean along the cleaning in S shape according to the room environment. Setting Forbidden Area Only available by App control, After setting the forbidden area, the robot will not enter the forbidden area of the room.
  • Page 26 Relocation by LDS Location A Location B During cleaning, when pause the robot and take it to a new area ,then restart it to resume cleaning, the robot will begin relocation and move to its previous place. Spot cleaning The robot will take its current position as the center and clean a specific spot of your home according to a spiral route.
  • Page 27 5.1 Side brush cleaning and replacement Check the side brush condition from time to time to see if it has been damaged or wrapped with foreign objects. Clean the side brush with a cleaning tool or a rag. When the side brush is damaged and cannot be used, please replace it in time, L and R side brush should be corresponding.
  • Page 28 Open dust bin cover, and dump garbage Remove the primary filter...
  • Page 29 Open the high-efficient filter cover, and remove the high-efficient filter and filter sponge. It is not recommended to wash the high-efficient filter with water. Please put off the debris carefully. Wash the dust box and pre-filter.
  • Page 30 1. Dry the dust bxo and filter components. Keep them dry to ensure a longer service. 2. After the pre-filter is used for 15-30 days, it should be washed once. 3. The maximum service life of the high-efficient filter is 3 months. 1.
  • Page 31 Cover the dust box and fix it into the main body. 5.3 Maintenance of Rolling Brush Components Open the rolling brush components...
  • Page 32 Remove the rolling brush and clean off all debris and hair. 5.4 Maintenance of Other Components lectrode slice ensor Use the cleaning tools or a dry soft cloth to periodically clean the electrode slice of robot chassis and the sensor window.
  • Page 33 Charging terminal Use a cleaning tool or soft cloth to clean the charging terminal...
  • Page 34 6.1 Faults Description Faults Possible Reasons Solutions The electrodes between the main body Make sure that the electrodes between and the charging base are not the main body and the charging base contacted properly. are properly contacted. The robot can not be charged.
  • Page 35 6.2 Replaceable Modules Glass Panel Laser head dumper component Top cover Left Side Wheel Universal Wheel Component Components ground detection Right Side Wheel Component mechanical induction switch Fan Components side brush component main brush component side brush Bottom case battery component bottom cover dustbin component Application:...
