S TA BLE G R AZE R ®

G E NE R AT I ON II

OW N E RS M A NUA L

Product and Warranty Information

Patent No. 7,055,459

The Stable Grazer is a unique, programmable,

automatic feeder designed to dispense flake hay

from one to six times a day. Both you and your

horse will benefit from a regular, frequent feeding

schedule made easy with the Stable Grazer.

Stable Grazer

PO Box 6206

Beaverton OR 97007

1-800-732-1654

Table of Contents

Need help?

Do you have a question about the GENERATION II and is the answer not in the manual?

Questions and answers

Summary of Contents for STABLE GRAZER GENERATION II

Page 1 OW N E RS M A NUA L Product and Warranty Information Patent No. 7,055,459 The Stable Grazer is a unique, programmable, automatic feeder designed to dispense flake hay from one to six times a day. Both you and your horse will benefit from a regular, frequent feeding schedule made easy with the Stable Grazer.
Page 2 Both you and your horse can now benefit from a regular, frequent feeding schedule made easy with your new Stable Grazer. Neither Stable Grazer manufacturers, nor anyone associated with Stable Grazer in any way, either by impli-cation expression, intends Stable Grazer to take the place of human caretakers of any animal.
Page 3: Table Of Contents
Table of Contents Power Source Programming the Timer Loading the Feeder 9-10 Care and Maintenance Trouble Shooting 12-13 Warranty Information 14-15 Warranty Claim Policy Page 3...
Page 4: Power Source
Power Source Feeder Battery The feeder requires one 6 volt lantern battery (included). To install it, remove the two 10-32 screws hold-ing the Control Panel. Tip the Control Panel towards you to reveal the back side. Loosen the two 10-32 screws holding the Battery Clamp until you are able slip a 6 Volt battery (included) into the Battery Clamp.
Page 5: Programming The Timer
Introduction You will find there are several possible feeding options for your horse with the Stable Grazer. First, you need to decide how many times per day you would like to feed. We recommend a minimum of three feedings a day (more is even bet- ter) because we believe that frequent, consistent feedings best simulate grazing and are most beneficial for your horse.
Page 6 Programming the Timer the bottom loaded feed shelf to feed. It is also important to know that this is a 24 hour timer. It will repeat the same program every day. So, for example, if you want to feed four times a day you would program timer number 1 thru 4 with your feeding times and set the run time to :02 seconds.
Page 7 Programming the Timer or DOWN button until the time says 12:00pm. Next press the SET button again to display RUN-TIME SEC- ONDS. Press the UP or DOWN button until it shows :02 seconds. Press the SET button to display  TIMER 3.
Page 8 Programming the Timer TIME SECONDS. Press the UP or DOWN button until it shows :00 seconds. This will deactivate TIMER 6. In the above example the feeder would feed four times in a 24 hour period at 6:00am, 12:00 noon, 6:00pm and 12:00 midnight.
Page 9: Loading The Feeder
Loading the Feeder Instructions You will need to decide how much of your horse’s diet will be hay forage. Again, we recommend feeding a mini- mum of three times a day for optimal health. If this is what you choose, the next step is to divide the amount of hay forage you want to feed each day by the number of feedings.
Page 10 (2, 4, or 6 feedings). The Stable Grazer can be loaded after an odd number of feed- ings; the cam shaft will simply need to be retimed and each shelf will need to be loaded.
Page 11: Care And Maintenance
Care and Maintenance Cleaning and Care The stable Grazer requires very little cleaning. The dry hay fines and dust that will inevitably accumulate inside the feeder should present no problems for the operation of the feeder. However, it is best to clean out the excess matter periodically because when the dust and hay fines become damp from humidity or rain and snow, problems can arise.
Page 12: Troubleshooting
Troubleshooting Problem Possible Cause/Solution Bottom feed shelf will not lock Feeder cam shaft is out of time. into position while loading feeder. See page 10. Foreign object between cam shaft Cam shaft does not rotate. and door channel. See pg. 11 and note “Caution.”...
Page 13 Troubleshooting Problem Possible Cause/Solution Feed shelf does not drop Feed door side bent in. Straighten completely. bent side. Build up on chute bottom. Scrape Feed hangs up in chute. clean. See care and maintenance on pg. 11. Feed shelves do not snap into Build up of excess hay fines in feed door channel.
Page 14: Warranty Information
God. Stable Grazer assumes no responsibility for failure of the unit to operate properly due to improper installation, assem-bly, or user’s accidental damage to the unit in any way. The Stable Grazer is designed to be used for dispensing hay to individual ani-mals. Stable...
Page 15 NEGLIGENCE OR OTHER-WISE SHALL NOT EXCEED THE RE- TURN OF THE AMOUNT OF THE PURCHASE PRICE PAID BY PUR- CHASER AND UNDER NO CIRCUMSTANCES SHALL Stable Grazer BE LIABLE FOR SPECIAL, INDIRECT OR CONSEQUENTIAL DAM- AGES. THE PRICE STATED FOR THE EQUIPMENT IS A CONSIDERA- TION IN LIMITING THE SELLER’S LIABILITY.
Page 16: Warranty Claim Policy
4. Seller’s Address: The defective part should be shipped only after making arrangements with Stable Grazer Systems by calling 1-800-732-1654, and receiving shipping authorization and instructions. NOTE: The above policies are subject to change without notice.
