System Design
• Do not create ST touch panel switches that could possibly endanger the safety
of equipment and personnel. Damage to the ST, its I/O unit(s), cable(s), and
other related equipment can cause an output signal to remain continuously ON
or OFF and possibly cause a major accident. Therefore, design all monitoring
circuits using limit switches, etc. to detect incorrect device movement. To pre-
vent accidents related to incorrect signal output or operation, design all switches
used to control vital machine operations so they are operated via a separate
control system.
• Do not create switches used to control machine safety operations, such as
an emergency stop switch, using a ST touch screen icon. Be sure to install
these switches as separate hardware switches, otherwise severe bodily in-
jury or equipment damage can occur.
• Please design your system so that equipment will not malfunction due to a
communication fault between the ST and its host controller. This is to pre-
vent any possibility of bodily injury or material damage.
• Do not use the ST unit as a warning device for critical alarms that can cause
serious operator injury, machine damage or production stoppage. Critical
alarm indicators and their control/activator units must be designed using stand-
alone hardware and/or mechanical interlocks.
• The ST is not appropriate for use with aircraft control devices, aerospace
equipment, central trunk data transmission (communication) devices, nuclear
power control devices, or medical life support equipment, due to these de-
vices' inherent requirements of extremely high levels of safety and reliability.
• When using the ST with transportation vehicles (trains, cars and ships), di-
saster and crime prevention devices, various types of safety equipment, non-
life support related medical devices, etc. redundant and/or failsafe system
designs should be used to ensure the proper degree of reliability and safety.
• After the ST backlight burns out, unlike the ST's standby Mode, the touch
panel is still active. If the operator fails to notice that the backlight is burned
out and touches the panel, a potentially dangerous machine operation error
can occur. Therefore, do not use ST touch switches for the control of equip-
ment safety mechanisms, such as Emergency Stop switches, etc. that pro-
tect humans and equipment from injury and damage. If your ST's backlight
suddenly turns OFF, use the following steps to determine if the backlight is
actually burned out.
1)If your ST is not set to Standby Mode and the screen has gone blank, your
backlight is burned out.
2)Or, if your ST is set to Standby Mode, but touching the screen does not
cause the display to reappear, your backlight is burned out.
Installation
• Do not modify the ST unit. Doing so may cause a fire or an electric shock.
• Do not use the ST in an environment where flammable gasses are present,
since operating the ST may cause an explosion.
Wiring
• To prevent an electric shock, be sure to confirm that the ST's power cord is
not connected to the main power when connecting any cords, cables or lines
to the ST.
• Do not use power beyond the ST's specified voltage range. Doing so may
cause a fire or an electric shock.
Maintenance
• The ST uses a lithium battery for backing up its internal clock data. If the battery is
incorrectly replaced, the battery may explode. To prevent this, please do not
replace the battery yourself. When the battery needs to be replaced, please con-
tact your local ST distributor.
WARNINGS
E-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Digital Electronics Corporation ST Series

  • Page 1 WARNINGS System Design • Do not create ST touch panel switches that could possibly endanger the safety of equipment and personnel. Damage to the ST, its I/O unit(s), cable(s), and other related equipment can cause an output signal to remain continuously ON or OFF and possibly cause a major accident.
  • Page 2 CAUTIONS Installation • Be sure to securely connect all cable connectors to the ST. A loose con- nection may cause incorrect input or output. Wiring • Ground the ST's FG line separately from other unit FG lines. Locating FG lines too close may cause an electric shock or a unit malfunction. Be sure to use a grounding resistance of 100Ω...
  • Page 3 • Do not store or use the ST where chemicals (such as organic solvents, etc.) and acids can evaporate, or where chemicals and acids are present in the air. Corrosive chemicals: Acids, alkalines, liquids containing salt Flammable chemicals: Organic Solvents •...
  • Page 4: Ul/C-Ul Application Notes

    UL/c-UL Application Notes The ST400-AG41-24V/ST401-AG41-24V/ST402-AG41-24V/ST403-AG41-24V units are UL/c-UL listed product. When applying for UL approval for a product that includes one of these ST units, please be sure to pay special attention to the fact that all products with built-in ST units require UL inspection of the combination of the ST and the product.
  • Page 5: Ce Marking Notes

    CE Marking Notes The ST400-AG41-24V/ST401-AG41-24V/ST402-AG41-24V/ST403-AG41-24V are CE marked, EMC compliant products. These units also conform to EN550011 Class A, EN61000-6-2 directives. For detailed CE marking information, please contact your local ST distributor. Revision Information Use the metallic label attached to the rear of the GP to identify your unit’s revision code.
  • Page 6: Part Names

    Part Names A : Display B : Touch Panel C : Function Switches (F1 to F6) D : Power Lamp E : Power Plug F : RS-422 Interface (X) G : RS-232C Interface (Y) Front A, B H : RS-485(MPI) Interface (X) I : RS-422 Interface (Y) J : Ethernet Connector (X) K : RS-232C/RS-422 Interface (Y)
  • Page 7 Dimensions The ST unit dimensions are follows. 118[4.65] Unit:mm[in.] 41[1.61] 130[5.12] 5[0.20] Right Side Front The following drawing shows the ST unit with installation fasteners. Unit:mm[in.] 129[5.08] 64.5[2.54] 41[1.61] 139[5.47] 5[0.20] Front Right Side...
  • Page 8 Interfaces ST400-AG41-24V Serial Interface RS-422 Interface (X) Pin Connection Pin No. Signal Signal Name Direction Receive data A Input Receive data B Input Send data A Output Enable receive A Output Ground Clear send B Input Send data B Output Clear send A Input Enable receive B...
  • Page 9: Serial Interface

    ST402-AG41-24V Serial Interface RS-485(MPI) Interface (X) Pin Connection Pin No. Signal Signal Name Direction No connection No connection LINE(+) Line (+) In/Output Request Send Output Ground Output 5V External Output No connection LINE(-) Line (-) In/Output No connection *1 When providing power via the Seimens Co.'s Profibus connector, power cannot be connected to the Device/PLC.
  • Page 10: Ethernet Interface

    ST403-AG41-24V Ethernet Interface This is the Ethernet Interface of 10 BASE-T. LED lights up or blinks according to the status. LE D C ontents W hen the pow er s upply is on, LE D lights up. orange W hen s ending or rec eiving, LE D blinks . green W hen linking, LE D lights up.
  • Page 11: Installation

    Installation Confirm the Installation Gasket's Positioning It is strongly recommended that you use the gasket. It absorbs vibration in addition to repelling water. Place the ST on a level surface with the display panel facing downward. Check that the ST’s installation gasket is seated securely into the gasket’s groove, which runs around the perimeter of the panel’s frame.
  • Page 12 Attach the Installation Fasteners from Inside the Panel 1. Refer to the following drawing when inserting installation fastener hooks in the ST unit's right side (2) and left side (2) installation fastener holes. Insertion Slots Left Right As shown in the following figure, attach the Installation Fastener in the right position.
  • Page 13 Wiring WARNINGS • To avoid an electric shock, prior to connecting the ST's power cord confirm that the ST's power supply is completely turned OFF, via a breaker, or similar unit. • The ST400-AG41-24V/ST401-AG41-24V/ST402-AG41-24V / ST403-AG41-24V units are designed to use only DC24V input. Any other power level can damage both the ST and the power supply.
  • Page 14 Connecting the ST Power Cord When connecting the power cord, be sure to follow the procedures given below. 1. Confirm that the ST's power cord is unplugged from the power supply. 2. Remove the power plug from the ST unit. 3.
  • Page 15: Power Supply Cautions

    Power Supply Cautions Please pay special attention to the following instructions when connecting the power cord. Use the power plug and connects to the ST power connector. • Between the line and the ground, be sure to use a low-noise power supply. •...
  • Page 16 Note Be aware that the Digital Electronics Corporation shall not be held liable for any real or estimated damages or losses, or third party claims resulting from the use of this product. ©2005 Digital Electronics Corporation E-16...
