INSTALLATION &
OPERATING MANUAL
CONTENTS:
Chapter
Description
1.
Introduction .......................................................... 1
2.
Ratings and Specifications .................................... 2
3.
Product Safety ....................................................... 3
4.
Structure ............................................................... 5
5.
Location Advice ..................................................... 5
6.
Unit ........................................................................ 6
6.
Operating Instructions ........................................
7.
Lamp Replacement ............................................... 8
7.
BioCeptor Unit Sizing Guide ................................
8.
Model Information ............................................. 11
9.
Troubleshooting .................................................. 11
10.
On-Going Machine Requirements ..................... 15
11.
After Sales and Service Support ......................... 15
Chapter 1. INTRODUCTION
Thank you for purchasing Mechline's HyGenikx
installed, and operated in accordance with this Operator Manual, it will provide many years of service.
HyGenikx is an advanced and compact, wall or ceiling mounted steriliser system, proven to eradicate viruses and
bacteria throughout large occupied areas where air movements are minimal.
Utilising a combination of the most effective air and surface sterilisation technologies available - Germicidal Oxidation,
Germicidal Irradiation, Dual waveband Plasma Quatro - HyGenikx provides round-the-clock hygiene and safety
protection, controls odours and has also significantly been proven to prolong the life of fresh perishable foods.
Mechline's HyGenikx system has been through rigorous testing, providing customers with the utmost confidence in its
effectiveness and quality.
INSTALLATION & OPERATING MANUAL
Page
10
15
fan assisted (AF) air & surface steriliser system. When correctly
TM
LEAVE THIS MANUAL WITH THE OPERATOR AFTER INSTALLATION
REVISION: 09/2020 | page 1 of 16
Advertisement
Table of Contents
Related Manuals for MECHLINE HYGENIKX+
Summary of Contents for MECHLINE HYGENIKX+
-
Page 1: Table Of Contents
Germicidal Irradiation, Dual waveband Plasma Quatro - HyGenikx provides round-the-clock hygiene and safety protection, controls odours and has also significantly been proven to prolong the life of fresh perishable foods. Mechline’s HyGenikx system has been through rigorous testing, providing customers with the utmost confidence in its effectiveness and quality. -
Page 2: Ratings And Specifications
Air & Surface Steriliser System Chapter 2. RATINGS and SPECIFICATIONS Region EUROPE HGX-AF-25 / HGX-AF-50 HGX-AF-25-E / HGX-AF-50-E Model numbers HGX-AF-75 / HGX-AF-100 HGX-AF-75-E / HGX-AF-100-E Air purifying technology Nano-titanium dioxide photocatalytic oxidation + UV-C UV-C lamp tube 1 x 18w PLL composite tube UV-C intensity inside chamber 15000 µW/cm UV-C lamp tube life... -
Page 3: Product Safety
In the event of a broken lamp, care must be taken to avoid cuts to hands (the complete unit can be returned to Mechline for this work to be carried out if required) and appropriate protection should also be worn. - Page 4 3.3 PRODUCT CONFORMITY 3.3.1 Mechline’s HyGenikx AF air & surface steriliser system conforms to the essential safety requirements of the Low Voltage Directive (LVD) 2014/35/EU, Electromagnetic Compatibility Directive (EMC) 2014/30/EU and is manufactured in accordance with following standards: EN55014-1:2017, EN61000-3-2:2014, EN610000-3-3:2013, EN55014-2:2015, EN60335-2-65:2003+A1:2008+A11:2012, EN60335- 1:2012+A11:2014.
-
Page 5: Structure
Air & Surface Steriliser System Chapter 4. STRUCTURE HYGENIKX UNIT LAMP Power cable socket UV lamp On/Off switch Quartz part of lamp Air inlet vent End terminal Cover Air outlet vent Aluminium air diffuser plates UV lamp base Lamp holding plate NOTE: The cover needs to be fitted so the... -
Page 6: Installation Instructions
Air & Surface Steriliser System Chapter 6. INSTALLATION INSTRUCTIONS 6.1 MOUNTING INSTALLATION STEPS 6.1.1 Equipment needed: 6.1.2 The following installation steps are for mounting the HyGenikx unit vertically on a wall (recommended). Alternative mounting options include wall mounting horizontally or ceiling mounting. If ceiling mounting the unit this will require four brackets for secure installation. - Page 7 Air & Surface Steriliser System 6.1.5 Measure 2.23 metres AFFL. Then hold the unit in its location and mark the two drill holes through the mounting bracket holes. 6.1.6 Carefully place the unit in a safe place and drill the two mounting holes. 2.23m MARKED MOUNTING HOLES...
-
Page 8: 7.2 Lamp Replacement
Air & Surface Steriliser System Chapter 7. UV-C LAMP REPLACEMENT 7.1 IMPORTANT ADVICE • Do not touch the anodized aluminium air diffuser plates. • Always use disposable gloves (or a tissue) when handling the UV lamp. • Any dirt on the lamp can be cleaned with a dry cloth or soft brush. •... - Page 9 Air & Surface Steriliser System 7.2.3 Unscrew and remove the two finger screws from the lamp holding plate – step below. 7.2.4 Carefully slide OLD LAMP from its socket and lift out (always use gloves or a tissue) – steps below.
- Page 10 It is important to confirm with the site that the unit/power to the area is not disconnected at any point (with units connected to lighting circuits – check turning lights off does not disconnect unit). For technical assistance e-mail technical@mechline.com, quoting the HyGenikx model number. The model number can be found on both sides of the unit.
-
Page 11: Model Information
Unit is working correctly but the room odour remains! 9.1.3 • Check that the unit is the right type and strength for the area. Contact Mechline if you are unsure • Replace/upgrade lamp • If unit previously worked well, clean thoroughly following the manufacturer’s instructions •... - Page 12 9.3.7 Loose connection in power supply to unit or internal wiring • Check all visible connections • If problems persist the unit may need to be returned to Mechline for inspection* 9.3.8 Unidentified fault, suspected part failure • Check lamp, for other parts return to Mechline for inspection* *For technical assistance e-mail technical@mechline.com, quoting the HyGenikx model number.
- Page 13 Air & Surface Steriliser System 9.4.5 Does air need to pass through a unit to be sanitised? No, our technology uses both internal and external processes so although contaminates passing through the unit will be sanitised, it also produces cleaning air which circulates throughout. This is why HyGenikx can cover such a large area.
- Page 14 It is important to understand that units need to be suitably sized to ensure correct operation. how to size the HyGenikx unit please refer to chapter 8, or email technical@mechline.com 9.4.13 What do the numbers and codes refer to on the unit? The numbers represent the square meterage the unit is set up for, (length x width - height is not included in this calculation as the sanitising air will fall to ground level where the highest contamination is present).
-
Page 15: On-Going Machine Requirements
Please have the HyGenikx unit model number to hand. 11.1 WARRANTY Mechline’s air & surface hygiene steriliser system has a one year manufacturer’s warranty from the date on invoice, against defective parts or faulty workmanship. Terms and conditions apply. NOTE: Lamps are basic ‘consumable’... - Page 16 Commercial use of this material may only be made with the express, prior, written permission of Mechline. This includes material provided by any third party, including material obtained through links to other sites from Mechline’s pages or its affiliates and commercial associates. Material and information included are correct at time of print. Intending buyers and users must satisfy themselves as to the suitability and safety of the products for their particular purposes and duties.
