- Page 1 Operating Manual Model 954v2 Ionising Airgun...
-
Page 3: Table Of Contents
Products shown in this document may be covered by one or more patents, patents applied for and/or registered designs and/or trade marks. For further information please refer to our Head Office or visit www.meech.com. © Meech Static Eliminators Ltd., 26.10.17... -
Page 5: Introduction
The Meech 954v2 Ionising Air Gun is an upgraded model, that provides exceptional performance when neutralising static charges and removing dust and contamination on a wide range of industrial processes. The 954v2 has many improvements over its predecessors due to innovations in engineering. These include the use of additive manufacturing that make the 954v2 60% faster and 40% lighter than the previous version. -
Page 6: Unpacking And Inspection
Unpacking and Inspection The Model 954v2 Ionising Air Gun has been carefully packed at the factory in a container designed to protect it from accidental damage. Nevertheless, we recommend careful examination of the carton and contents for any damage. If damage is evident, do not destroy the carton or packing material and immediately notify the carrier of a possible damage claim. -
Page 7: Installation
A typical operating pressure for the 954v2 is 3.5 bar / 50 psi. The gives a good balance of ionisation and cleaning performance. However, depending on the application, higher or lower pressures may be required. -
Page 8: Technical Specification
Technical Specification Model 954v2 Max pressure 6.8 Bar/100PSI Recommended pressure 3.4 Bar/ 50PSI Operating voltage 7kV from Meech 904 power unit Max Temperature 85°C. Construction Gun handles – cast aluminium Nozzle body - Nylon Weight 300 g approx Cable 3 metres of H.T. cable supplied as standard, longer lengths can be specified when ordered. -
Page 9: Maintenance
To remove the emitter, insert a 3mm nut spinner into the end of the nozzle and unscrew it counter-clockwise. The nut spinner Meech uses is a BAHCO (BE-7803) Once removed, the pin can be cleaned. A toothbrush is deal for this. - Page 10 The exterior of the nozzle can be wiped down with a damp cloth. Should you have any additional questions regarding the maintenance of Meech equipment please contact Meech International directly or your local Meech distributor.
-
Page 11: Fault Finding
Should such an event occur, disconnect immediately and return equipment to the manufacture for water damage assessment. The 954v2 ionising air gun forms parts of a system, comprising 954v2 ionising air gun and a Model 904 power supply. If after following the cleaning instruction, the system is believed not to be working... - Page 12 If the green neon indicator is not illuminated, consult the operating manual for the 904 for further troubleshooting information. For further help consult your local Meech distributor, or contact one of our worldwide offices. Contact details are available on the Meech website: www.meech.com...
-
Page 13: Repairs And Warranty
Repairs And Warranty The 954v2 is warranted by Meech Static Eliminators Ltd to the original purchaser against defects in material and workmanship for one year after purchase. Should any malfunction occur, please return the bar directly to Meech Static Eliminators or your local distributor. -
Page 16: Meech Static Eliminators Ltd
Meech International Meech Static Eliminators USA Inc Meech Elektrostatik SA Meech CE 2 Network Point 2915 Newpark Drive Kaiserbaracke 166 Gábor László utca 2 Range Road, Witney Norton, OH 44203 B-4780 St.Vith Budapest 1041 Belgium Hungary OX29 0YN, UK Tel: +44 (0)1993 706700 Tel: +1 330 564 2000 / 1 800 232 4210 Tel.: +49 (0)6555 3733 399...
