AI7688H User Manual
3.2 Update bootloader
USB drive must be in FAT file system or the file cannot be recognized by the AI7688H
development platform.
# Save the bootloader file (lks7688.ldr) in the root directory of a USB drive and name it
lks7688.ldr.
# Plug the USB drive to AI7688H.
# Press the WiFi and MPU (Reset) button at the same time, then release the MPU Reset
button but hold the WiFi button for at least 20 seconds.
# After 20 seconds Wi-Fi LED will turn on. Release WiFi button.
The board will start to read the bootloader (WiFi LED blinks fast) and perform the
bootloader upgrade process (Wi-Fi LED blinks slowly). It takes about 2 seconds to finish
the bootloader upgrade process
3.3 Build F/W from Source
The following operations are performed under a Ubuntu LTS 14.04.3 environment. For a
Windows or a Mac OS X host computer, you can install a VM for having the same
environment:
 Install prerequisite packages for building the firmware:
$ sudo apt-get install git g++ libncurses5-dev subversion libssl-dev gawk
libxml-parser-perl unzip
 Download OpenWrt CC source codes:
$ git clone git://git.openwrt.org/15.05/openwrt.git
 Prepare the default configuration file for feeds:
$ cd openwrt
$ cp feeds.conf.default feeds.conf
