- Page 1 Smart Outlet Instruction Manual OUTLET A Instruction.indd 1 3/8/17 3:31 AM...
- Page 2 24/7 DAYS DIGITAL TIMER WITH RANDOM AND SUMMER TIME This device is a plug-in timer switch designed to control the electric power to household appliances to save energy. It has a built-in battery to operate the clock and help you set the timer. Before operation, please plug the unit into an outlet to recharge for about 5 - 10 minutes if the device is out of charge and shows nothing on the display.
-
Page 3: Initial Setup
1. Initial Setup 1.1 Reset the timer Use a paper clip to press the ‘RESET’ button to clear all settings. The LCD will display information as shown in ‘Figure 1’ and automatically enter the ‘Clock Mode’ as shown in ‘Figure 2’; 1.2 Charge the timer If the screen is blank, plug the timer into any outlet for 30 minutes to charge the internal battery... - Page 4 2. Set the Digital Clock When in the Clock Mode, LCD shows day, hour and minute. For example, set the time as 9:30AM Tuesday To adjust the WEEK DAY, simultaneously press the ‘CLOCK’ and the ‘WEEK’ button; To adjust the HOUR, simultaneously press the ‘CLOCK’...
-
Page 5: Daylight Saving Time
3. Daylight Saving Time 3.1 To switch between Standard Time and Daylight-Saving Time (DST) First: Press and hold the ‘CLOCK’ button. Then: Press the ‘ON/AUTO/OFF’ button. There will be a ‘SUMMER’ on the LCD. And the time will become the Daylight-Saving Time(DST). OUTLET A Instruction.indd 5 3/8/17 3:31 AM... -
Page 6: Set The Timer
4. Set the Timer Press the ‘TIMER’ button to enter the setting mode: You will see 1 to the left of the display For example, set TURN ON at: 8:30AM on every weekday morning. Step 1: Press the ‘WEEK’ button to choose the group of days you wish to switch the appliance on. - Page 7 Step 5: Press the ‘TIMER’ button to set 1 time. Repeat steps 1 - 4. Step 6**: Press the ‘CLOCK’ button to exit the setting mode. 4.5 Press the ‘TIMER’ button to advance to the next on/off setting position. Repeat steps 1-6. * Setting mode will exit if no button is pressed within 30 seconds.
-
Page 8: Manual Operation
5. Manual Operation Press the ON/AUTO/OFF can manually turn on and off the timer. OFF: Press ON/AUTO/OFF button unit screen shows OFF. In this status, timer always has no output. The blue LED output indicator is off. ON: Press ON/AUTO/OFF button unit screen shows ON. - Page 9 IMPORTANT When the timer is reverted back from Manual ON/OFF option to AUTO mode, the Manual ON/OFF option will remain effective until the nearest upcoming on (off) schedule arrives. For instance, we have a program like this: MO TU WE TH FR SA SU, 7:00AM, ON | MO TU WE TH FR SA SU, 7:00PM, OFF It's Tuesday 9:00pm and the timer is OFF in the AUTO mode.
- Page 10 6. Anti-theft Random Function This feature only works with programs set between 6:31PM and 5:30AM next morning. In the RANDOM mode, the timer will randomly come on and go off up to half an hour earlier/ later than the assigned on/off setting.
-
Page 11: Special Technical Data
7. Special Technical Data Installation: Plug-in Type Voltage: 120V~/60Hz Rating: 120V~ AC / 15A /1800W Operating Temperatures: -14°F ~ +104°F Accuracy: ± 1 Minute per Month Battery: NIMH1.2V>100 Days Notes: The timer has self-protection function, it will automatically reset in any of the following situation: 1. - Page 12 UKOKE Corp. +1 909 734 6812 235 W. Grove St, Pomona, CA 91767 www.UKOKE.com facebook.com/UKOKELife info@Ukoke.com OUTLET A Instruction.indd 12 3/8/17 3:31 AM...
