- Page 1 Ersatzteilliste Hydraulikhammer EHB 10 Hagen...
-
Page 2: Instructions For Use
INSTRUCTIONS FOR USE This parts manual describes the configuration of the part components of the product and is intended only to assist to order spare parts for maintenance work This manual contains no safety information for operating the product or maintenance work. Please observe the safety instructions described in the relevant operation manual. - Page 3 3. Item: Key number which shows the referring number of the part in corresponding illustration. For a revised part which replaces the old one with same item number, the item is not shown. Item numbers are not always in sequence. +..
-
Page 4: Table Of Contents
EHB10-Rev6/161212 TABLE OF CONTENTS INSTRUCTIONS FOR USE ............................. 2 EHB10 – Product Dimensions ..........................6 EHB10 – Power Cell Ass’y ............................9 EHB10 – Cylinder Ass’y ............................11 EHB10 – Cylinder Bush Ass’y ..........................12 EHB10 – Front Head Ass’y ............................ 13 EHB10 –... - Page 5 EHB10-Rev6/161212 Blank Page - 5 -...
-
Page 6: Ehb10 - Product Dimensions
EHB10-Rev6/161212 EHB10 – Product Dimensions (1/2) Unit: mm (inch) EHB10-BA EHB10-NA - 6 -... - Page 7 EHB10-Rev6/161212 EHB10 – Product Dimensions (2/2) Unit: mm (inch) EHB10-NS - 7 -...
-
Page 8: Ehb10 - Power Cell Ass'y
EHB10-Rev6/161212 EHB10 – Power Cell Ass’y - 8 -... - Page 9 EHB10-Rev6/161212 EHB10 – Power Cell Ass’y ITEM PART NO. PART NAME REMARKS B100-9901 Power-cell Ass’y B100-9801 Cylinder Ass’y B060-9802 Valve Ass’y B060-2001 -Valve B060-2002 -Valve Bush B060-2003 -Valve Plug S8010501 -O-ring [K4] S8010351 -O-ring [K4] B060-9803 Cylinder Bush Ass’y B090-9804 Back Head Ass’y B090-4001 -Back Head...
-
Page 10: Ehb10 - Cylinder Ass'y
EHB10-Rev6/161212 EHB10 – Cylinder Ass’y 103-1 103-2 - 10 -... - Page 11 EHB10-Rev6/161212 EHB10 – Cylinder Ass’y ITEM PART NO. PART NAME REMARKS B100-9801 Cylinder Ass’y A021-0001 Lock Pin AA053-0008 U-Packing [K2] AA053-0007 Buffer Ring [K2] 103-1 -Seal Ring [K2] [D] 103-2 -Back-up Ring [K2] [D] [for Option Seal Only] AA054-0005 Dust Seal [K2] A061-0015 Plug...
-
Page 12: Ehb10 - Cylinder Bush Ass'y
EHB10-Rev6/161212 EHB10 – Cylinder Bush Ass’y ITEM PART NO. PART NAME REMARKS B060-9803 Cylinder Bush Ass’y B060-1003 Cylinder Bush A056-0028 Step Seal [K3] 302-1 -Seal Ring [K3] [D] 302-2 -O-ring [K3] [D] A057-0009 Gas Seal [K3] S8011051 O-ring [K3] - 12 -... -
Page 13: Ehb10 - Front Head Ass'y
EHB10-Rev6/161212 EHB10 – Front Head Ass’y ITEM PART NO. PART NAME REMARKS B100-9805 Front Head Ass’y A021-0001 Lock Pin A031-0003 PU-Sleeve B080-5010 Stop Pin B090-5005 Chisel Pin B100-5001 Front Head B100-5002 Chisel Bush B100-5003 Front Bush B100-5004 Stop Pin S6710052 Grease Nipple BSPT 1/4 - 13 -... -
Page 14: Ehb10 - Seal Kit
EHB10-Rev6/161212 EHB10 – Seal Kit ITEM PART NO. PART NAME REMARKS AB102-0002 Seal Kit [K2+K3+K4] AB102-0003 Piston Lower Part Seal Kit AA053-0008 -U-Packing AA053-0007 -Buffer Ring AA054-0005 -Dust Seal AB102-0004 Piston Upper Part Seal Kit A056-0028 -Step Seal A057-0009 -Gas Seal S8011051 -O-ring JIS G105-HsA90... -
Page 15: Ehb10 - Tools (Chisels)
EHB10-Rev6/161212 EHB10 – Tools (Chisels) TOOL SHAPE TYPE OF TOOL Moil Wedge Moil Point Flat Wedge Flat Wedge Flat End (Pyramid) (Conical) - Vertical -Horizontal (Blunt) (Inline-cut) (Cross-cut) PART NO. B100-6001 B100-6002 B100-6003 B100-6004 B100-6005 TOOL DIAMETER (in.) (3.66) (3.66) (3.66) (3.66) (3.66) -
Page 16: Ehb10 - Bracket Ass'y; Ba
EHB10-Rev6/161212 EHB10 – Bracket Ass’y; BA - 16 -... - Page 17 EHB10-Rev6/161212 EHB10 – Bracket Ass’y; BA ITEM PART NO. PART NAME REMARKS B102-9402 Bracket Ass’y B080-7055 Upper Damper B102-7014 Bracket B102-7028 Lower Damper B040-7064 Wear Plate B090-7027 Shim - 17 -...
-
Page 18: Ehb10 - Bracket Ass'y; Na
EHB10-Rev6/161212 EHB10 – Bracket Ass’y; NA - 18 -... - Page 19 EHB10-Rev6/161212 EHB10 – Bracket Ass’y; NA ITEM PART NO. PART NAME REMARKS AB102-0043 Bracket Ass’y AB102-0044 Bracket B102-7037 Guide Block B090-7043 Locate Block B060-7192 Side Bolt B082-7020 Side Bolt Washer S4413641 Hex. Cap Nut - 19 -...
-
Page 20: Ehb10 - Bracket Ass'y; Ns
EHB10-Rev6/161212 EHB10 – Bracket Ass’y; NS - 20 -... - Page 21 EHB10-Rev6/161212 EHB10 – Bracket Ass’y; NS ITEM PART NO. PART NAME REMARKS AB102-0001 Bracket Ass’y B090-7040 Bracket B090-7043 Locate Block B090-7044 Guide Block B060-7192 Side Bolt B082-7020 Side Bolt Washer S4413641 Hex. Cap Nut - 21 -...
-
Page 22: Ehb10 - Mounting Adapter And Hoses
EHB10-Rev6/161212 EHB10 – Mounting Adapter and Hoses ITEM PART NO. PART NAME REMARKS B090-7011 Mounting Adapter B082-0607 Adapter Fasteners Set S0170663 -Hex. Head Bolt M20x2.5XL90-10.9T S5101113 -Spring Washer M20(Type 1) S4013143 -Hex. Nut M20x2.5-10T B080-9950D0 Mounting Pin Set B080-9951Do -Bracket Pin B080-9952Do -Spacer B080-9953Do... -
Page 23: Ehb10 - Gas Charging Kit
EHB10-Rev6/161212 EHB10 – Gas Charging Kit ITEM PART NO. PART NAME REMARKS A090-0052 Gas Charging Kit Excl. item 9 A092-0005 Pressure Regulator KS B4603 A062-0043 Adapter A062-0041 Minimess Coupling BSP 1/4 A082-0016 Exhaust Valve BSPT 1/8 A012-0002 Cap Nut KS B6214, W23-14 A062-0018 Coupling KS B6214... -
Page 24: Ehb10 - Maintenance Tool Kit
EHB10-Rev6/161212 EHB10 – Maintenance Tool Kit 3, 4, 5, 6 1, 2 7, 8, 9 11, 12, 13, 14 21, 22, 23, 24, 25 15, 16, 17 18, 19, 20 26, 27, 28, 29, 30 31, 32 33, 34, 35 36, 37 41, 42, 43 48, 49... - Page 25 EHB10-Rev6/161212 EHB10 – Maintenance Tool Kit Standard Tool Kit Option Tool Kit ITEM PART NO. PART NAME B082-0609B Tool Kit B082-0610B Tool Kit 2199-9005 Tool Box T6550007 L-Wrench 6 T6550009 L-Wrench 8 T6550013 L-Wrench 12 T6550015 L-Wrench 14 T7050003 Screw Driver( ─...
