GoerTek GBDA90 Getting Started

GBDA90
The GBDA90 adapter allows you to use an Apple iPod
with your Bluetooth stereo headset. The adapter utilizes
Bluetooth technology to stream stereo music wirelessly.
®
GBDA90 supports your controlling iPod with the buttons
on your Bluetooth stereo headset.
Please note: GBDA90 requires an iPod
®
with a dock
connector. This includes the third generation iPod
® ®
forth generation Click Wheel iPod , iPod Photo, iPod
®
mini, iPod nano, and the fifth generation iPod
Video. GBDA90 works with any of these, and there is no
®
additional software to install on the iPod .
GETTING STARTED
Note: You will need to remove the sleeve, press the
front center of the sleeve lightly and pull it upwards away
from the GBDA90 adapter.

Through Charging and Data Transferring

®
You can charge your iPod through GBDA90 without
®
disconnecting it from iPod . Plug the power adapter or
USB charging cable into USB charging port of GBDA90,
and then you iPod ® can be charged by through GBDA90.
Also you can transfer the data from your computer to
iPod through GBDA90 without disconnecting it from iPod
when you connect GBDA90 with the computer via the
USB cable.

General Use

After the initial pairing, you can restore the wireless
connection between the Bluetooth stereo headset and
GBDA90 with just a few simple steps. Make sure your
®
iPod and the Bluetooth stereo headset are properly
charged then do the following:
1. Power on the Bluetooth stereo headset. (Refer to the
user manual of your Bluetooth stereo headset for
details).
GBDA90
®
Figure 1
®
, the
®
®
with
iPod ® Nano 2G sleeve
iPod ® 30-pin Connector
Disconnect button
USB charging port Indicator Light
GETTING STARTED
2. Connect GBDA90 to the dock connector at the bottom
of your iPod ® (Please make sure the Power on/off button
on GBDA90 is at On position). GBDA90 and iPod® will
power on automatically.
If GBDA90 is already connected to your iPod
®
power on and play your iPod . (GBDA90 will not power
®
on until the iPod has resumed playing.)
After a few moments, the light on GBDA90 will blink
green once every 4 seconds to indicate the wireless
connection with the Bluetooth stereo headset.
You can now control your iPod
button on your Bluetooth stereo headset.(Please refer to
the manual of your Bluetooth stereo headset for details).

Sleeping Mode

GBDA90 will go into Sleeping mode as iPod
Sleep mode, during which indicator light is off. GBDA90
will wake up immediately as soon as PLAY of iPod
pressed.
Note: when you use GBDA90 with other iPod
except of nano 2G, you should take off the sleeve for
mounting.
No charging is required because GBDA90 has not built-
in battery. It uses your iPod® for the small amount of
power supply, so be sure your iPod
GETTING STARTED

Power on/off

When GBDA90 is connected to the dock connector at
the bottom of your iPod
GBDA90 by sliding Power on/off button to the On or Off
position.
You can also remove GBDA90 from iPod
directly.
Note: GBDA90 can not be powered on without connect-
ing to iPod ® because it is powered by iPod
battery.

Pairing

Disconnect button
Pairing is a one-time task that allows GBDA90 and the
Bluetooth stereo headset to recognize each other for
future use.
Power on/off switch
DO NOT MODIFY OR DISMANTLE
Do not attempt to open GBDA90. Doing so may expose
you to electric shock and serious injury. There are no
user-serviceable parts inside. Any attempt to alter or
repair the module will void the limited Warranty. Users
are not permitted to make changes or modify the device
®
, simply
in any way. Changes and modifications void the user's
authority to operate the device.

TROUBLESHOOTING

No audio is heard on the Bluetooth stereo
headset
For GBDA90 to work properly, it must be correctly paired
with the Bluetooth stereo headset. (See section titled
®
wirelessly with the
Pairing, for instructions in performing this one-time task.)
If pairing was successful and you still can't hear music,
try the following:
1. Make sure the iPod
GBDA90
2. Make sure Power on/off button on GBDA90 is at the
®
enters
On position
3. Check the volume level on both your iPod
®
is
Bluetooth stereo headset.
GBDA90
®
products
To pair GBDA90 with the Bluetooth stereo
headset

CHARGING

If you have other Bluetooth devices, be sure they are
powered off before proceeding
1. Connect GBDA90 to the dock connector at the bottom
®
is fully charged.
of your iPod
on GBDA90 is at On position). The indicator light on
GBDA90 will blink Red->Amber->Green, and then turn to
solid Red. (Figure 1)
®
, you can power on or off
2. Please turn your Bluetooth stereo headset to pairing
status.(Please Refer to the user guide of your Bluetooth
stereo headset for details).
®
to power off it
When pairing is successful, the indicator light on
GBDA90 will flash green ten times rapidly and then blink
® built-in green once every 4 seconds, ready for use.
After GBDA90 and the Bluetooth stereo headset have
been successfully paired, they will automatically connect
when both are powered on and placed within 100 meters
of each other.
Cannot pair with the Bluetooth stereo head-
set
When attempting to pair, make sure no other nearby
Bluetooth devices are in paring mode or discoverable
mode, and ensure that all previously paired Bluetooth
devices are powered off.
If you need further help, please contact us:
GoerTek Technology Co.,Ltd.
http: //www. goertek. com
e-mail: service@goertek. com
Customer Service Hotline: 86-532-88999318
The copyright and brand name are owned by the register. All information in
®
is playing and fully seated into
this manual is subject to change without prior notice.
GoerTek has the authority to explain the above information.
For more information, please visit GoerTek Website:
http: //www.goertek.com
® and the
GETTING STARTED
®
(Please make sure the Power on/off button
TROUBLESHOOTING
SUPPORT
