Scosche IPBTT Quick Start Manual

BOTTOM DOCK BLUETOOTH TRANSMITTER FOR IPOD
Congratulations on your purchase of the IPBTT. This unit incorporates the latest Bluetooth
technology for seamless integration with most Bluetooth A2DP enabled products. Before
using, please read this manual carefully.

FEATURES/SPECS

Lithium-ion 10 hour Rechargeable Battery (450mAh capacity)
Designed with 30-pin iPod bottom dock (All iPods EXCEPT Shuffle, Gen 1, Gen 2)
Wireless Range: Up to 30 Feet (10 Meters)
Bluetooth V1.2
®
Transmitter Power < 3dbm
Receiver Sensitivity: -78+4dm
Supported Profiles: Advanced Audio Distribution Profile (A2DP) / Audio Video Remote
Control Profile (AVRCP)
Frequency Range: 2.4Ghz - 2.4835Ghz
Dimensions: 55x40x10mm
Weight: 16 grams
Certifications: FCC

IPBTT OVERVIEW

Dual RED/BLUE
LED Indicators
Power Button
This device complies with FCC Rules Part 15. Operation is subject to the following two conditions:1) This device may not
cause interference, and 2) this device must accept any interference that may be received, including interference that may
cause undesired operation. The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modification to this equipment. Such modification could void the user's authority to operate the equipment
If you have any further questions, call our TOLL FREE number:
TECHNICAL HELP LINE 1-800-361-3695 Ext.3
IPBTT
IPBTT
®
®
1
NOTE:
Before using the IPBTT for the first time, charge the battery a full 3 hours.
The IPBTT will also charge your iPod battery through the IPBTT power port.
1. Plug the Mini Connector on charger into the charging jack as shown in illustration.
®
2. Connect USB Cable to an available PC or Laptop USB port.
3. Charge Battery for 3 hours (LED will illuminate RED when charging)
4. The RED LED will turn off when charging is complete. Unplug the IPBTT
and enjoy up to 10 hours of use.
5. Purchase wall and car adapters to charge at home and/or on the road.
(IPPWR / IP2IN1 - Sold Separately)

PAIRING THE TRANSMITTER WITH BLUETOOTH DEVICES

SCOSCHE
UBR/UBRH
(Not Included)
PAIRING NOTES:
The IPBTT transmitter must be paired with a Bluetooth receiving device before use.
*
It is designed for AUTO-Pairing functionality. (Passcode = 0000)
*
Keep the IPBTT and Bluetooth receiving device within a distance of 3ft. (1 Meter)
*
during pairing.
Compatible devices must be Bluetooth V1.2 supporting A2DP profile.
*
1. Power up your Bluetooth
Scosche Bluetooth
Bluetooth
Bluetooth
2. While the Bluetooth
IPBTT for 3 seconds. The Blue LED indicator light will flash indicating the unit is in
pairing mode.
3. Initial pairing can take a few minutes. If pairing is successful, the IPBTT's LED will switch
from flashing quickly to flashing slowly.
4. Test the connection by plugging the IPBTT into your iPods bottom dock connection with
an audio selection playing. You should hear the audio through your Bluetooth
device.
5. If pairing is not successful, repeat steps 1-4 above. Make sure both
devices enter pairing mode at or near the same time. Power off any other Bluetooth
device that you do not intend to pair with the IPBTT as these units may interfere or
prevent pairing of other nearby devices. If you still cannot successfully pair two devices,
call Tech Support at (1-800-621-3695 Ext.3)

CHARGING THE BATTERY

Mini Connector
Charging Dock
IPBTT
®
®
receiving device (such as Scosche wireless headphones or
®
receiver) to place it into pairing mode. If needed, consult your
®
products manual for information on pairing or discovering other
®
devices.
®
receiver LED is flashing, press and hold the power button on the
®
2
®
SCOSCHE
UBHP
(Not Included)
NOT TO SCALE
®
receiving
®
®
