Summary of Contents for Soluciones Electronicas SOLENER
- Page 1 SOLENER Pure Sine Wave Inverter User Manual Version 1.14 June 2020 Soluciones Energéticas S.A. Avenida Real de Pinto, 146 28021 Villaverde Alto, Madrid Telephone +34 91 539 27 00 www.solener.com solener@solener.com...
-
Page 2: Table Of Contents
Inverter User Manual TABLE OF CONTENTS 1.- INVERTER DESCRIPTION 2.- FRONT PANEL INTERFACE 3.- INVERTER OPERATION 4.- INDICATORS AND SETTINGS 5.- INVERTER PROTECTIONS 5.1.- Overload Protection 5.2.- Over Temperature Protection 5.3.- Low and High Voltage Protection 6.- INSTALLATION INSTRUCTIONS 6.1.- Inverter Mounting 6.2.- Wiring 7.- START-UP PROCEDURE 8.- SHUT-OFF PROCEDURE... -
Page 3: Inverter Description
Inverter User Manual 1.- INVERTER DESCRIPTION The SOLENER inverter is a pure sine wave inverter (DC to AC converter), designed for stand-alone photovoltaic applications and controlled by a microprocessor. It has been designed to provide an alternating sinusoidal output voltage of 230 volts, 50 hertz (there are also versions of 120 volts and/or 60 hertz) from an input voltage of 12, 24, 36 or 48 volts provided from electrochemical accumulators. -
Page 4: Front Panel Interface
2.- FRONT PANEL INTERFACE ® The figures shown below are a front view of the three types of SOLENER inverters, showing all the elements of the user interface. These element references will be used throughout this manual. The small model has one multi-color LED that brings together the functions of the seven LED present in rest of the models. -
Page 5: Inverter Operation
Inverter User Manual 3.- INVERTER OPERATION After switching ON the inverter, the unit carries out system checking sequences; if an error is detected the failure cause will be shown on the LCD display and the Load Disconnection LED Indicator will start to flash along with other LED indicators (depending on the failure). -
Page 6: Indicators And Settings
Inverter User Manual When an AC overload is detected, the inverter limits the time that power is supplied to the load (the time that this power will be supplied decreases as the overload increases). Once this time has passed, the inverter output shuts off and the “Load Disconnection”... -
Page 7: Inverter Protections
The inverter is protected against reverse polarity, overload, short-circuit, over temperature and battery voltages out of a reasonable range. Please see below a detailed description of each of the protections. Contact our technical service (tecnico@solener.com) for factory setting of automatic restart after overload or short-circuit. 5.1.- Overload Protection See table in section 12 for overload limits. -
Page 8: Inverter Mounting
Inverter User Manual the preset voltage threshold is not reached, and remains lit after 10 seconds, shutting off the output. Shutdown due to high DC input voltage is intended to protect the inverter against irreversible damages. In both cases, when the battery voltage returns to a value within the acceptable working range, the unit will automatically restart. -
Page 9: Start-Up Procedure
Inverter User Manual Low Voltage Electro-technical Regulation. The ground cable must be in the low voltage circuit breaker distribution board. Connect the negative battery cable to the negative (-) terminal of the battery. • Blow around the positive terminal of the battery to remove any accumulated •... -
Page 10: Maintenance
Inverter User Manual 10.- MAINTENANCE The inverter does not require any special maintenance. Periodic cleaning of the casing with a dry cloth is recommended. If necessary, a dampened cloth with soapy water can be used (never dampen with alcohol or solvents). 11. -
Page 11: Technical Specifications
Inverter User Manual 12.- TECHNICAL SPECIFICATIONS Output wave form ....................... Pure Sine Wave Rated output voltage ..................230 (120 optional) V Rated output frequency ................... 50 (60 optional) Hz Output frequency variations ...................... < 0,1 % Output power variations ........................< 5 % Minimum Input Voltage ...................... -
Page 12: Warranty
SOLUCIONES ENERGÉTICAS, S.A. guarantees that its products comply with all written specifications in this manual. The warranty period of SOLENER products are 2 years, which will begin to take effect from product shipment date from SOLUCIONES ENERGÉTICAS S.A. or, if it is sold to an authorized retailer, from the authorized retailer shipment date to the customer.
