Page 1 USER MANUAL 2AMIN637WPS SUBJECT INDEX: DESCRIPTION TECHNICAL SPECIFICATION DEVICE POWER SUPPLY AND CONNECTION TO THE LOAD PUSH 1 AND PUSH 2 OPERATION WIFI MODE FACTORY RESET IOTLIGHT - User Manual 2AMIN637WPS...
Page 2 Protection against accidental contact with live parts is garantied by the enclosure. - Cross-section of cables 14-30 AWG (0.05-2.08 mmq). - Controllable with Android/iOS app IoT Light Smart. - Input Controls: Not insulated Push button x2, Wifi x1. - Storage Temperature Min: -40 Max: 60 C. Degrees.
Page 3 CODE INPUT (MAX) OUTPUT CONTROL CASE DIMENSION VOLTAGE CURRENT INPUTS 2AMIN637WPS 110-240V AC 2A RMS for channel Not insulated Push 40x80 button x2 h 24.45 Wifi x1 IOTLIGHT - User Manual 2AMIN637WPS...
Page 4 DEVICE POWER SUPPLY AND CONNECTION TO THE LOAD 2AMIN637WPS CONNECTION DIAGRAM - FIGURE N. 1 The 2AMIN637WPS dimmer has to be powered according to the polarity showed in FIG. 1 In particular: - connect the power source to the Input L and N terminals...
Page 5 Once the device is joined to wifi network PUSH 1 and PUSH 2 can be used to control separately LOAD 1 and LOAD 2 or other loads within the Newlab System (see Newlab IOT videoguide, topic devices, endpoints, groups) IOTLIGHT - User Manual 2AMIN637WPS...
Page 6 THE BLUETOOTH LE CONNECTION DOES NOT REQUIRE PAIRING PROCEDURE Device 2AMIN637WPS requires a WIFI connection type B or G, configure your router / access point to support at least one the two connection type indicated. Example configuration: (Mode B / BG / BGN...
Page 7 FACTORY RESET In order to perform a factory reset, Press and hold the PUSH 1 button for at least 20 sec (see wiring diagram), switch off the device and turn on it. Last Manual Update 23/06/2020 IOTLIGHT - User Manual 2AMIN637WPS...
