RC weather station with BBQ Weather display and Outdoor Sensor
Thank you for purchasing this high quality product.
Unpacking and checking
1. Remove the weather station from the packaging, remove all protective films and keep the packaging
materials out of the reach of children.
2. Dispose of the materials separately according to type.
3. Check that all the items that should be included in the delivery are present and whether the weather
station displays any damage.
Items included in the delivery
• The weather station, consisting of base station and wireless sensor
• 3 batteries – LR6 type (AA) / 1.5 V
(base unit)
• 2 batteries – LR6 type (AA) / 1.5 V
(wireless sensor)
• Operating instructions
Product functions
Weather station
• 12- or 24-hour display
• Date, time and day of week display
• 2 alarms can be set, with snooze function
• Indoor temperature display in °C/°F
• Indoor and outdoor humidity display
• Outdoor temperature display in °C/°F with up to three wireless sensors at different measurement sites
(delivery includes one wireless sensor)
• Minimum/maximum display for temperature and humidity
• Humidity and temperature trend display
• Outdoor temperature alert
• Frost warning
• Weather forecast symbols
• Moon phase display
• Sun rise / sun set times display
• Tide display
• Location display
• Air pressure reading with trend
• Air pressure history
• Air pressure unit in hPa and inHg
• Absolute and relative air pressure selectable
• Low battery indicator
Advertisement
Table of Contents
Related Manuals for AOK TX2056A
Summary of Contents for AOK TX2056A
- Page 1 RC weather station with BBQ Weather display and Outdoor Sensor Thank you for purchasing this high quality product. Unpacking and checking 1. Remove the weather station from the packaging, remove all protective films and keep the packaging materials out of the reach of children. 2.
- Page 2 • Wall mounting bracket Wireless sensor • Temperature display in °C/°F • Humidity display • Range of up to 100 meters (in open area) • Low battery indicator • Wall mounting bracket Overview the Weather Station...
- Page 3 Hour Indoor temperature trend Alarm symbol Stored outdoor maximum and minimum values Snooze symbol Frost warning Minute Indoor temperature Radio controlled indicator Outdoor temperature trend Daylight saving time (DST) Outdoor temperature Second Low battery indicator (receiver) Day of week Indoor symbol Weather icon Low battery indicator ( outdoor sensor) Tide...
- Page 4 Operating elements and parts of the base unit Operating buttons Button SNOOZE/LIGHT * Illumination backlight * Activate snooze function MODE Button * Display alarm time * Activate settings mode * Save changes to settings Button * Set values (increase) * Display stored MAX and MIN values Button * Set values (decrease) * Switching outdoor temperature alert and frost warning on/off...
-
Page 5: Wireless Sensor
RESET Button * Restart the weather station Alarm 2 on/off switching button Alarm 1 on/off switching button HISTORY Button * Display air pressure value of previous hours ( 0 ~ -12 hours) * Activate air pressure setting mode * Save changes to settings Button CITY * Activate city setting mode... -
Page 6: Initial Setup
Initial setup Follow the instructions in the order described and first put the batteries in the wireless sensor. This is the only way for the weather station to function without any problems. Do not press any buttons while switching the device on. Wireless sensor 1. -
Page 7: About The Time Signal
Information : The device will lose all information when switching it on again. Radio frequency connection After the device turns on, radio frequency symbol will flash on the display and it will start to receive RF signal from wireless sensor for 3 minutes, the corresponding outdoor temperature and humidity values will be displayed. -
Page 8: Setting The Time And Date Manually
Restarting radio signal reception Manually restart the radio signal reception by pressing and holding the buttons together for 2 seconds. Turn off Radio signal permanently MODE Manually turn off the radio signal reception permanently by pressing and holding the buttons together for 2 seconds, the symbol will be constantly displayed. -
Page 9: Alarm Function
General The base unit and wireless sensor exchange information over a radio frequency. For this reason, the location is important for the range of the wireless connection. Note: • The maximum distance between the base station and wireless sensor is 328 ft ( meters). -
Page 10: Stopping The Alarm
On ALARM 1: • switch ON: on the display, A1 is activated • switch OFF: disappear, A1 is deactivated On ALARM 2: • switch ON: on the display, A2 is activated • switch OFF: disappear, A2 is deactivated Stopping the alarm You will be woken by the alarm at the set time, and the sound will become more and more intense as the alarm continues. -
Page 11: Selecting Location
Selecting location CITY Press and hold button to set your country and city, 150 cities can be selected. Use the buttons to select. CITY Press the button to confirm. Sun rise and sun set times After setting your country and city, the weather station will display the approximate times for sun rise and sun set. -
Page 12: Weather Forecast
Outdoor temperature alert and frost warning Keep pressing the button to turn on/off the temperature alert and frost warning. • press once: the temperature alert is activate • press again: the frost warning is activate • press again: temperature alert and frost warning are both activated •... -
Page 13: Air Pressure
After setting up initially, the weather forecast can not be used for about 12 hours, as the weather station needs this time to collect and evaluate the weather data. The weather forecast is a result of the collected data and the measured changes in air pressure. The forecast refers to the area around the weather station with a radius of about 30 to 50 km for the next 12 to 24 hours. - Page 14 Languages of day of week The language options are German (GE), English (EN), Italian (IT), French (FR), Spanish (SP), Dutch (DU), Danish (DA) and Russian (RU). DST function Weather station will adapt to winter / summer time automatically. Summer time: the second Sunday of March at 1:59 59’ AM changes to 3:00 00’ AM. Winter time: the first Sunday of November at 1:59 59’...
-
Page 15: Resetting The Weather Station
Resetting the weather station RESET Use a sharp object to press button to restart the weather station. Troubleshooting Problem Possible cause and remedy - Check the chosen location Device cannot receive WWVB - Start radio reception manually if necessary signal for the time. - Set the time manually Display screen not working. -
Page 16: Fcc Statement
Resolution: 0.1°C Accuracy: 0~40°C +/-1°C; other +/-2°C Humidity measuring range: 20 % to 95 % relative humidity Resolution: 1 % Accuracy: 30~80% +/-5%, other +/-8% Wireless sensor Model no.: AOLD-2056A Batteries: 2 x LR6 (AA) 1.5 V Temperature measuring range: - 20°C ~ 50°C (-4°F ~ 122°F) Protection type: IPX4 Transmission frequency: 433 MHz... - Page 17 • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio / TV technician for help.
