FEATURES:
• Lateral and pre-ischial
CUSTOM
• Twin-cell, lightweight
• CoolCore
SPECTRUM GEL SPP
INSTALL ATION AND CARE INSTRUCTIONS
shelf contoured, high-
density molded foam
base.
fluid insert under at risk
bony areas.
technology
®
cover standard.
• 4-Way Stretch Poly liner
optional.
• Sizes available - 14"-
24"W x 16"-24"D
Advertisement
Table of Contents
Summary of Contents for Stealth Products CUSTOM
- Page 1 FEATURES: • Lateral and pre-ischial • 4-Way Stretch Poly liner shelf contoured, high- optional. density molded foam CUSTOM base. • Twin-cell, lightweight fluid insert under at risk bony areas. • Sizes available - 14”- • CoolCore technology ® 24”W x 16”-24”D cover standard.
-
Page 2: Customer Satisfaction
Customer Satisfaction Stealth Products strives for 100% customer satisfaction. Your complete satisfaction is important. Please contact us with feedback or suggested changes to help improve the quality and usability of our products. You may reach us at: Stealth Products, LLC... - Page 3 Important Information Important Information! All persons responsible for fitting, adjustment, and daily use of the devices discussed in these instructions must be familiar with and understand all safety aspects of the devices mentioned. In order for our products to be used succesfully, you must: •...
-
Page 4: Introduction
They also contain important safety and maintenance information and describe possible problems that may arise during use. For further assistance or more advanced applications, please contact your supplier or Stealth Products, LLC at (512) 715-9995 or toll free at (800) 965-9229. -
Page 5: Warranty
Any lack or alteration of serial number, where applicable, will automatically void this warranty. Stealth Products, LLC is liable for replacement parts only. Stealth Products, LLC is not liable for any incurred labor costs. No person is authorized to alter, extend, or waive the warranties of Stealth Products, LLC. -
Page 6: Table Of Contents
Table of Contents 1.0 Customer Satisfaction ................. i 2.0 Important Information ................ii 3.0 Introduction ....................iii 4.0 Warranty ..................... iv 5.0 Table of Contents ..................v 6.0 Warning Labels ..................vii 6.1 Warning Labels ......................vii 6.2 Limited Liability ......................vii 7.0 Design and Function ................... - Page 7 Table of Contents 10.0 First-Time Use ..................19 10.1 Dealer Assistance ....................19 10.2 User Testing ......................19 10.3 Conditions of Use ....................19 11.0 Maintenance ................... 20 11.1 Cleaning ........................20 11.2 Disinfecting ....................... 20 11.3 Maintenance ......................21 12.0 Notes .......................
-
Page 8: Warning Labels
Stealth Products, LLC does not hold responsibility for final integration or final assembly of product to end user. Stealth Products, LLC is not liable for user death or injury. -
Page 9: Design And Function
Design and Function Intended Use Stealth Products’ Custom Cushion is designed to provide optimal fitting for individuals requiring solid seats to support minimal deformities or stability needs, and who require moderate postural support, improved trunk or pelvic positioning, or have mild pelvic asymmetries. -
Page 10: Installation Instructions
Installation Instructions... -
Page 11: Preparations
Incorrect installation of the Custom Cushion or its accessories may cause damage to the hardware and/or injury to the user. Tools Use the proper tools to install and adjust the Custom Cushion to the desired position for the user. CAUTION The use of improper tools may cause damage to the device. -
Page 12: Required Tools
Installation Instructions Required Tools Below are the tools needed to complete the installation of the cushion hardware systems: Tool: 5/32” Hex Key CAUTION Tools required to install additional accessories are detailed in the manuals for those accessories. Tools are not provided. Refer to the manuals provided with additional accessories for a list of the tools required to install those accessories. -
Page 13: Hardware System Assemblies
Installation Instructions Hardware System Assemblies When coupled with a seat pan, the Custom Cushion is able to be installed on wheelchairs via three different hardware options. Each hardware option can be ordered to fit on 3/4”, 7/8”, or 1” wheelchair canes. -
Page 14: Hardware System Installation
Installation Instructions Hardware System Installation This section details how to install the cushion to the wheelchair with the three available hardware configurations. Please note that the hardware is functional whether it faces outward (as is pictured) or inward. The amount of space, clearance, and the type of chair are the determining factors in installation compatibility. - Page 15 Installation Instructions Step Two: Using a 5/32” hex key, remove the screws, washers, and nuts from the Hold Down Drop Stop Weldments. Position the weldments just outside the J-clips on the wheelchair cane. Step Three: Use the 5/32” hex key to replace the screws, washers, and nuts from the weldments and tighten firmly.
- Page 16 Installation Instructions Trouble Free Hardware Installation: The Trouble Free hardware attaches to a wheelchair in two-point or four-point options. The following instructions are for the two-point option. In order to install the four-point option, simply repeat the following steps for the two remaining hardware sub-assemblies.
- Page 17 Installation Instructions Step Two: Join the Female/Male Tube Stop Clamps around the wheelchair canes. When the clamps are positioned correctly, use a 5/32” hex key to tighten the screws through the tube stop clamps.
- Page 18 Installation Instructions All-Purpose Hardware Installation: The All-Purpose hardware attaches to a wheelchair in a two-point or a WC20- approved four-point option. The following instructions are for the four-point option. Step One: Using a 5/32” hex key, slightly loosen the three screws in the base of each knob’s clamp, pictured below.
- Page 19 Installation Instructions Step Three: Turn the knobs counterclockwise to loosen them and expose the knob’s center screw. Step Four: Place the seat pan assembly onto the knob assembly. Ensure the seat’s L-brackets are flush with the knobs’ exposed center screws.
- Page 20 Installation Instructions Step Five: Turn the knobs clockwise to firmly tighten them against the L-brackets. Step Six: In order to comply with the provisions and requirements of WC20, the provided locking pins must be inserted in the through-holes of each L-bracket, as illustrated below.
-
Page 21: Wc20 Information
WC-20 approved. CAUTION The WC20-approved All-Purpose hardware and Custom Cushion should only be used as detailed in these instructions, and only meet WC20 requirements when used in conjunction with a WC20-approved back and wheelchair. -
Page 22: Belt Placement
WC20 Information DANGER The WC20-approved All-Purpose hardware has been designed to accommodate the proper use of vehicle-anchored belt restraints and the ratings of the seating systems, with regard to a) ease of properly positioning vehicle-anchored belt restraints on the wheelchair passenger, and b) the degree to which proper positioning of belt restraints can be achieved. - Page 23 WC20 Information CAUTION Belt restraints should be adjusted to fit as snugly as possible, consistent with user comfort. SAFETY Belt restraints should not be worn twisted or in a manner that reduces the area of contact of the belt webbing with the occupant.
- Page 24 WC20 Information Both pelvic-belt and shoulder-belt restraints that comply with RESNA WC-4:2012, Section 18 and/or 4.6, 5.2, 5.3 or RESNA WC-4:2012, Section 19 should be used to limit occupant movement in a crash and reduce the likelihood of occupant ejection from the vehicle and/or injurious contact of the occupant with the vehicle interior.
-
Page 25: User Safety
WC20 Information Trays Wheelchair-mounted rigid trays that are not specifically designed for use during travel in motor vehicles should be: • removed and secured separately in the vehicle; or • secured to the wheelchair so they will not break free in a crash; •... - Page 26 WC20 Information (Note: Dimensions in pictures measured in millimeters.) When mounting the WC20-approved All-Purpose hardware to your wheelchair, refer to the installation instructions starting on page 3. DANGER The WC20-approved All-Purpose hardware is designed only for use with wheelchair frames that have been successfuly crash-tested to the frontal impact requirements of RESNA WC-4:2012, Section 19 WARNING The WC20-approved All-Purpose hardware must be used on a wheelchair...
-
Page 27: First-Time Use
User Testing 10.2 It is important that the customer be fully aware of the installation of the Custom Cushion, including how to use it and how it can be adjusted to fit the client comfortably. As a dealer, proceed as follows: •... -
Page 28: Maintenance
Maintenance 11.0 Cleaning 11.1 • Use a soft cloth to clean the hardware and seat pan. • Ensure all cleaners are approved for finished steel, aluminum, plastic, and upholstered surfaces. • To wash the cover, remove from the foam. Do not get the foam wet. •... -
Page 29: Maintenance
Check all mounting hardware before using the cushion, making sure each fastener is properly tightened. CAUTION Do not smoke while using the Custom Cushion. CAUTION Ensure that safety belts, if used, are properly installed. Replace or repair parts as needed. -
Page 30: Notes
Notes Notes 12.0 12.0... - Page 31 Notes 12.0...
- Page 32 STEALTH PRODUCTS, LLC stealthproducts.com 104 John Kelly Drive Burnet, Texas 78611 (800) 965-9229 P149D620 REVISION DATE: 2019 -12-17...
