Summary of Contents for Lean Quad BMD0906
- Page 1 INSTALLATIONANDOPERATING INSTRUCTIONS WARNING: Assembly by an adult . This toy is unsuitable for children under 3 years due to its maximum speed. Executive standard: En71 and En62115 ASTM F963-17 Photos are for reference ONLY.
-
Page 2: Installation Instruction
INSTALLATION INSTRUCTION The illustrations in this instruction are used for easier understanding of the operation method of the product and the product structure. Please note there may be differences between the pictures and the physical item. In order to improve the quality, we may change part of the structure and appearance of the product without an advance notice. - Page 3 96 months Before using the vehicle the child should understand the vehicle controls and safety issues. They must also demonstrate the capability to handle the vehicle and operate its controls. It is the responsibility of the adult to educate the child and supervise the vehicles use.
-
Page 4: Specification
Specification Parts List Name specification PICTURE PICTURE Battery Double drive (12V7AH/12V10AH) Double drive 12V 12V Motor Double drive motor 12V Steering motor 12V A(Rear axle) B(Front wheel) Suitable age 37-96 months Maxweight 30KG Body size 1030*680*730MM Speed D(Wheel cover) 3-6KM/h C(Rear wheel) Hours of use charging8-12hours，using1 to 2 hours... -
Page 5: Installation Steps
Installation Steps S4 S1 step2:Install the rear axle First press and firm the K(rear suspension pivot) into the corresponding position as shown. Then press the A(rear axle) through the hole as shown in figure (Keep the same length on both sides ). S4 S1 step1:Install the front axle A: Use K(M8 spanner) to loosen S4(M8 nut) , one on L(steering yoke), two... -
Page 6: Direction For Use
step7:Power red terminal red terminal step4:Install connection handlebar 1.Find the positive polarity the red port), then Press E(handlebar) into Remove the plastic cover the Q(Steering yoke), use from the red terminal N(screw) and M(nut) to fix (attention: put it at the safe place where far from the it.（Note: place M(nut) on positive polarity... - Page 7 Configuration B 3.Operation guide for Manual control (forward, backward and speed control): After the driver is seated, press the power switch, the car will send out a starting sound (2-5seconds). Put the Forward/Stop/Backward switch into the position of “forward” (Press forward), the hi/lo speed switch into the Mp3 multifuctional player (optional) position of “low speed”, step on the foot switch the car will move forward slowly, loosen the pedal the car will stop.
-
Page 8: Charging Instructions
9.Charging instructions. Trouble elimination methods 1.Yes, the fuse cuts off the power 1. Is the fuse overloaded? automatically by 5-20 seconds, then 2. The pedal switch connector is restart; No, check next reason analysis The motor good? 2.No, repair foot switch ; Yes, check next 3.
