iWantit Composite AV Instruction Manual

1.8m AV Cable
for iPad, iPod & iPhone
with a 30-pin connection
Use the Composite AV Cable to connect your iPod, iPhone,
or iPad to the composite video port and analogue audio
ports on your TV, home theatre receiver, or stereo receiver.
The Composite AV Cable has a USB connector that you
can plug into a power source, such as a computer or a USB
Power Adapter.
Before you begin connecting components, turn off the
power to all your components. Remember to make all
connections firmly to avoid humming and noise.
Important: Never force a connector into a port. If the
connector and port don't join with reasonable ease, they
probably don't match. Make sure that the connector
matches the port and that you have positioned the
connector correctly in relation to the port.
To use the Composite AV Cable to connect
iPod, iPhone, or iPad to your TV or receiver:
1 Plug the yellow video connector into the video
input port on your TV or receiver.
2 Plug the white and red audio connectors into the left and
right analogue audio input ports, respectively, on your TV
or receiver.
3 Plug the iPod Dock Connector into your iPod, iPhone,
iPad, or Universal Dock.
4 Plug the USB connector into your computer or a
USB Power Adapter to keep your iPod, iPhone, or iPad
charged.
5 Turn on iPod, iPhone, or iPad and your TV or receiver to
start playing.
MCOMP12_IB.indd 1
Not compatible with Lightning to 30-pin
adapter.
