Summary of Contents for ShareVgo SRM2000
- Page 1 Smart Home Rowing Machine Model: SRM2000 Item# M1S1 FCC ID: 2AWJJ-RM2000 Email: support@sharevgo.com Last Modified: June 5, 2020 Owner’s Manual...
-
Page 2: Before You Begin
ShareVgo Smart Rowing Machine safely so that you and your loved ones do not get hurt. Let’s review the safety notes and warnings now. If you have any questions, please contact support@sharevgo.com... - Page 3 M1S1 ShareVgo Smart Home Rowing Machine FCC Statement and Important Labels CAUTION: The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 4: Part Drawing
M1S1 ShareVgo Smart Home Rowing Machine Part Drawing... -
Page 5: Part List
M1S1 ShareVgo Smart Home Rowing Machine Part List Description Spec. Description Spec. Main Frame Washer φ13*6.5*1.5 Front Base Tube Bolt M6*16 Rear Base Tube Bolt 10*95*M6*25 Sliding Track Pull Pin ∮7.8*108*98 Handlebar Bolt M6*16*5# Washer Φ16*Φ8.5*1.5 Sensor Wire Square Head Bolt... - Page 6 M1S1 ShareVgo Smart Home Rowing Machine Components For Assembly STEP 2 STEP 1 Components Components STEP 3 STEP 4 Components Components STEP 6 Components STEP2 STEP1 M8x55 M8x55 STEP4 STEP3 STEP5 #5 1PC #6 1PC inch Hardware Pack & Manual...
-
Page 7: Step 2 - Pedals Assembly
M1S1 ShareVgo Smart Home Rowing Machine Step 1 – Front Base Tube Assembly Attach the Front Base Tube, with two wheels (2) facing out, onto the Main Frame (1) and secure it by using 2 Bolts (7), and 2 Washers (9), and 2 Nuts (60). - Page 8 M1S1 ShareVgo Smart Home Rowing Machine Step 3 – Seat and Sliding Track Assembly Slide the Seat (53) onto the Sliding Track (4). Be sure to slide from the end that does not have the Rubber Stopper. Insert the Pin (44) with the Stopper (35) through the hole near the end of the Sliding Track (4).
- Page 9 M1S1 ShareVgo Smart Home Rowing Machine Step 5 – Connect Sliding Track to Main Frame Lift up the u-shaped open end of the Main Frame (1) and the front end of the Sliding Track (4). Insert the front end of the Sliding Track into the u-shaped open end of the Main Frame (1).
- Page 10 M1S1 ShareVgo Smart Home Rowing Machine Step 6 – Tablet Holder Assembly 6-1: Install 2 AAA batteries into the slot at the back of Monitor (49). 6-2: Remove the 4 pre-installed Screws (68) from the back of the Monitor (49).
- Page 11 M1S1 ShareVgo Smart Home Rowing Machine To Move or Fold Rowing Machine To move rowing machine, simply lift the rear base frame tube until the wheels at the front base frame tube touching the floor and then move the machine to your desired location .
- Page 12 M1S1 ShareVgo Smart Home Rowing Machine Monitor Operation & Function Function buttons: MODE: 1. Press to select functions for display. 2. Press and hold 3-5 seconds to reset time, distance, and count values to zero. SET: 1. Press to set target functions for time, distance, and count.
- Page 13 Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by SHAREVGO is under license. Google Play and the Google Play logo are trademarks of Google LLC. App Store is a service mark of Apple Inc., registered in the U.S. and other countries.
-
Page 14: Maintenance And Storage
M1S1 ShareVgo Smart Home Rowing Machine Maintenance and Storage Inspect all parts and make sure all nuts, bolts, and screws are completely tightened before each use. To clean, wipe this equipment with a damp cloth. DO NOT use abrasive cleaners or solvents. -
Page 15: Product Warranty
Product Warranty 90-day Limited Warranty ShareVgo, LLC. warrants that this product will be free from defects in materials and workmanship for a period of 90 days from date of purchase when purchase of the product is from an authorized retailer and is used for the purpose intended, under the conditions that it has been installed and operated in according to ShareVgo’s Owner’s Manual.
