Gardner Bender GWL-30HD Operating Instructions

IMPORTANT: RECEIVING INSTRUCTIONS

Visually inspect all components for shipping damage. If you find damage, notify the carrier at once.
Shipping damage is NOT covered by warranty. The carrier is responsible for all repair or replacement costs resulting from damage in shipment.

SAFETY INFORMATION

WARNING
1. Do not use the lamp in the immediate vicinity of inflammable materials or gases.
2. Only use the accessories included with the product .
3. Keep the lamp out of reach of unauthorized persons, especially children.
4. Do not point the light directly in your own or any other person's or animal's eyes.
5. Always check the mains cable before you use the lamp.
6. If the supply cord is damaged, it shall be replaced by a similar qualified person in order to avoid a hazard
7. Secure screw on charging port cover after every charge. Do not use near water while charging.
Figure 1
Operating Instructions
30 Watt Heavy Duty LED Work Light
GWL-30HD

TECHNICAL DATA

LED:
Model:
Lumen:
LED Color Temperature:
Charger Input:
Battery:
Charging Time:
Operation Time :
Lamp output:
IP65 ; IK08
A

PRODUCT FEATURES

D
A. 100% / 50% / 10% ON/OFF Switch
B. USB OUTPUT Socket (charging seperate device)
B
C. LED Indicator
E
D. DC INPUT Hole (charging the battery)
C
E. Fast Lock (swivel change the lighting angle)
F. Power Connector
Figure 2
F
1
30W COB
GWL-30HD
100% 3000lm, 50% 1500lm,10%300lm
Approx 6500K
100-240Vac 50/60HZ Max.0.5A
7.4V 4400mAh 32.56wh Li-ion
4-5 hours
100% switch: 3000LM for 2.5hrs
50% switch: 1500LM for 5.0hrs
10% switch: 300LM for 10hrs
5V Max.2000mA
Charger IP44
When cover is unscrewed
